Humidity Cum Temperature Controller (Model 201 RHT)
1 Piece (MOQ)
Brand : Artech
Model : 201 RHT
Power Supply : 230V, 50Hz AC
Dimension : 96x96x110mm
Panel Cutout Size : 92x92mm
Model 201 RHT is a relative humidity cum Temperature controller designed for highly accurate humidity and temperature measurement. It receives digital output from Artech RS485 transmitter. It has two four digit LED displays to indicate RH (%) and TEMPERATURE (0C). 201 RHT provides alarm indication with two relay action for RH and TEMPERATURE, Two LED for RH alarm and two for TEMPERATURE indicating low and high alarm. It provides control action using relay with indication on the front panel. Control action provides for humidifier and dehumidifier logic for RH control and heating and cooling logic for TEMPERATURE control. The 201RHT provides a Modbus RS485 output for PC communication. It also provides industrial Isolated 4 to 20 mA output for the given range.
DTH-966 Temperature Humidity Controller
Features : Microcontroller based design. Elegant appearance, easy to operate and compact in size. Highly accurate and sturdy in operation. Dual display for simultaneous indication of T and RH. Field proven Algorithm, tested successfully for various HVAC control applications.
Humidity Controller
1,500 - 3,200 Per piece
1 piece (MOQ)
Country of Origin : India
Type : Humidity Controller
Material : Plastic, Stainless Steel
Certification : ISO 9001:2008
Application : Industrial
Color : Grey
Feature : Accuracy
Voltage : 12/24vdc
Condition : New
Warranty : 1 Year
Operating Temperatyre : 50-100D/C
Type : Capacitence
Warranty : 1YEAR AGAINST MANUFACTURUING DEFECT
Brand : RSPSPL
Humidity Controller
300,010,000 Per Container
Type : Humidity Controller
Material : Cast Iron, Plastic
Certification : ISO 9001:2008
Application : Industrial
Feature : Accuracy, Digital Water Meter Display, Lorawan Compatible, Spiral Water Meter
Voltage : 220V
Condition : New
Country of Origin : India
Product : Humidity Indicators/Controller
Input : From HGumidity/Temp Transmitter, Contact factory for dry / wet bulb Input
Range : 0-100%
Resolution : Relative Humidity : 0.14 RH ; Temp Control : One Relay for Cooloing (Compressor / Blolwer) ; Humidity Control : One relay for humidification second relay for dehumidification
IM3507 Temperature Humidity Controller
IM3700 Series Temperature Humidity Controllers are Micro controller based highly versatile controllers for combined control of Temperature and Humidity. Controller is available with PID control action. Control parameters are user configurable on site. Controllers can accept input from different type of Humidity sensors as well as RTD sensor for Dry Bulb Wet Bulb measurement technique.The major area of application can be pharmaceutical industry, environment chambers, green house rooms etc.
Temperature & Humidity Controller
Material : Metal
Voltage : 380V, 440V
Condition : New
Application : Industrial
Automatic Grade : Automatic
Feature : Digital Water Meter Display, Lorawan Compatible, Spiral Water Meter
Warranty : 2 Years
We have carved repute as a prominent Manufacturer & Supplier of Temperature & Humidity Controllers in Maharashtra, India. We are supported by a group of personnel who make use of the finest material for their production and compiled them in line with industry standards. Owing to our smart network, timely delivery of the placed order is what we always execute. Our Temperature & Humidity Controllers are obtainable at the modest prices!
Humidity Controller
Display : Four digit LED display for parameter indication and 4 digit for set point indication.
Features : Micro controller based Digital Circuitry. Dust proof membrane keypad for programming. High Low relay alarm outputs optional.
Input : RTD Pt100 / Thermocouple/4-20 mA / 0-10 V (factory set)
Control Output : 4-20 mA or 0-10 V
Size : 96 x 96 x 150 mm. (DIN standard).
Output : 4-20 mA
Accuracy : 0.1 C / 0.2 C +/- 1 digit (range 199.9 / 399.9)/1 C +/- 1 C for thermocouple
Digital Humidity Controller
Country of Origin : Made in India
Display : Dual 4-digit,0.5''/0.4'' Seven-segment Red LED Display
Brand Name : ASHE
Response Time : Less than 200 mS
Model Number : AH-74
Dimensions : 96 x 96 x 80 mm [W x H x D]
Power Supply : 90 V to 270 V AC,50 Hz
Calibration : 000.0 to 100.0% RH
Scale Range : -999 to +9999
Humidity Controller
Water Tank Capacity : 6.5 Liters
3 in 1 - Dehumidifier, Air - Purifier and Dryer,Energy Efficiency Grade 1,Moisture Removal (Running Temperature): 13 L (26.7℃ 60%RH) 22 L (30℃ 80%RH),Power Controls : LCD Display Touch Control,Recyclable Materials for Environmental Conservation,Voltage Frequency (VoltsHz) : 220 - 240V, 50Hz.
Temp Humidity Controller
14,000 Per Piece
Display : Four digit LED display
Model : IM 3509
Input interface : PT 100 RTD for temperature
Humidity sensor Input : 4-20 mA, 0-10 V or 0-3 V
Control Relay : 230V / 5A (resistive)
Connectivity : RS 232 Serial Interface for PC or Serial Printer (
Humidity Controller
Temperature Range : -199.9 to +199.9 / 399.9 Degree C
Output Supply : 5 V / 12 V / 24 V optional
Resolution : 0.1 C
Accuracy : 0.1 DegreeC
Relay : 230 V/5A (resi)
Memory : 8k / 32k / 64k
Size : 96 x 96 x 150 mm
We are supplier and exporter of this product.
Humidity Controller
Libratherm offers various models of Digital and Microprocessor based Temperature and Humidity Indicator / controller. The model HTC-3000 and HTC-3003 are specially designed for Environmental test chambers, however, they can be used for any HVAC applications, where simultaneous and accurate control of desired temperature and humidity is required.The controller accepts input signal from direct RH sensor for humidity control and / or RTD (Pt-100) sensor for temperature control. The controller gives three dc pulse outputs for controlling Air heater for dry heat, Boiler heater for humidity and Compressor for low temperature control. The 4th output is also optionally available for dehumidification. The control action is PID or On/Off for heaters and On/Off with built in programmable time delay for compressor. The compressor can be operated in Auto, On or Off mode as per control temperature requirement - above ambient, below ambient or below zero. Each channel loop parameters like PID, Set and hysterisis can be programmed from the front keyboard. The additional facility of built in real time clock, RS-485 or RS-232 PC interface, data storage and printer output for 80-column dot matrix printer (CENTRONIX output - suitable for EPSON model LX-300+ or equivalent ) is also provided for analysis of temperature and humidity behaviour date and time wise.The Controller has the built in non-volatile memory for the retention of the programmed values in case of power failure and on resumption of power the control will resume from the last value. To suit the control system, the special interlocking of the compressors and heaters are incorporated to enhance the performance and safety of the entire control system, which is achieved by switching off the compressor, if the air heater temperature exceeds certain preset value.The model DTH-100 is a digital temperature/humidity indicator. The single and two set point on/off control outputs in the form of relay contacts are also available for simple control applications.
digital humidity controllers
The ASHE Series AHT range of microcontroller based Digital Humidity and Temperature Controllers are compact, rugged and reliable instruments designed for accurate measurement and control applications. The Indicators accept the Humidity and Temperature signal from the ASHE HTP-1 Probe as their input and display Relative Humidity and Temperature parameters on a 4-digit seven-segment LED digital display. Up to four relay outputs are available as control options, each of which can switch a load of up to 10 Ampere rating.
Microprocessor Based Humidity Controller
rh controller
Temp Humidity Controller
Temperature Humidity Controller
