Capacitor Oil Impregnation Plant
Get Price Quote
Overview Deepak Vacuum Technologies Pvt Ltd, an ISO 9001: 2008 certified company, is engaged in manufacturing of Vacuum Oil Impregnation Plant that is designed to manufacture all types of capacitors and condensers. The vacuum oil impregnation plant has the qualitative features of superior performance and longer service life. Salient features: aluminium valves which is 100% leak proof; good volume leak rate; equipped with rotary oil sealed pump or combustion of roots; rotary pumps to achieve 0. 001 torr with loading; impregnation chamber is round or rectangular in shape; and cost effective. The Plant comprises of: Vacuum System. R. O. S. T. (Raw Oil Storage Tank). P.O.S.T. (Process Oil Storage Tank). Oil Storage Tank. Oil Filter Machine. Oil Filling System. Heating System Internal Air Circulation Control Panel
Vacuum Impregnation Plant
100,000 - 10,000,000 Per Piece
1 Piece (MOQ)
Driven Type : Electric, Hydraulic, Mechanical, Pneumatic
Color : Black, Blue, Grey, Light Green, Light White
Condition : New
Automatic Grade : Automatic, Fully Automatic, Manual, Semi Automatic
Power : 1-3kw, 3-6kw, 6-9kw, 9-12kw
Application : Vacuum Impregnation Drying
Voltage : 220V, 380V, 440V
Type : Vacuum Impregnation Plant
Weight : 1000-2000kg, 2000-3000kg, 3000-4000kg, 4000-5000kg, 5000-6000kg, 6000-7000kg, 7000-8000kg, 8000-9000kg, 9000-10000kg
Warranty : 1year
After-Sales Service Provided : Yes
Country of Origin : India
Best Deals from Impregnation Plant
Vacuum Pressure Impregnation Plant
105,000 Per Piece
1 Piece (MOQ)
Voltage : 380V AC 415V AC
Brand Name : SGEI
Power Consumption : 2HP to 10 HP
Production Capacity : 1KL TO 10KL
Motor Speed : 40RPM
Dimension : 2500
Made in : India
Capacitor Drying and Impregnation Plantt
Get Price Quote
Manufacturer & Supplier of Capacitor Drying and Impregnation Plant. Our product range also comprises of Vacuum Drying Plant, Transformer Oil Filtration Plant and Vapour Phase Drying Plant. It is useful for Power capacitors and fan condensers, It consists of rectangular or cylindrical impregnation chamber, degassing column, processed oil storage tank, Raw oil storage tank, oil treatment plant with filtering unit, with PTFE seat valves.. As a leading business name, we are engrossed in the arena of presenting to our customers an extensive consignment of Capacitor Drying And Impregnation Plant. These are extensively appreciated in the industry owing to their high functionality, reliability and exceptional finish. In addition to this, these could be purchased form us at highly affordable rates that too in bulk orders..
Vacuum Impregnation Plant
Get Price Quote
VPI is a process in which resins, varnish is forced into integrate parts of its winding to achieve void the insulation. The impregnation vessels are available in different options such as top loading and front loading. This can be offered depending on the application and handling facility available at work station. 1. ResinVarnish Vacuum Pressure Impregnation (for electrical insulation application) 2. CastingMetal Impregnation (for porosity removal and surface finish application) 3. Special Applications viz Silver Nitrate
Vacuum Pressure Impregnation Plant
Get Price Quote
We are instrumental in offering our reputed clients the finest range of Vacuum Pressure Impregnation Plants. Our Vacuum Pressure Impregnation Plants are used in the treatment of various electrical products. We manufacture our Vacuum Pressure Impregnation Plants from the best quality components and other raw materials which guarantee efficient long term usage. The Vacuum Pressure Impregnation Plants that we offer demand low maintenance and are economic too. Used For Wind turbinesPower capacitorInsulation material of cableDry type transformersH.V motors and generatorsH. T coils for automobile industries Suitable For Motor WindingsTransformers Specifications Operating pressure : 0 - 10 kg/sq cm2Chamber Size range : Dia 500 mm to 3000mm.(As per customer requirement) Type of Clamping Manual ClampingBayonet Clamping AccessoriesSafety valvePressure relief valveVacuum breakerSight and light arrangementStirrer Storage Tank Storage tank specially designed to store varnish, oils or liquids as per customer need or varnish manufacturer specified Heating system to maintain temperature ranging from 25 C to 80 CCooling system for to maintain temperature of 0 c to 25 C100 mm rock wool insulation used to avoid heat transferA stirrer with 3 nos aerofoil shaped blades is provided in order to reduce temperature gradient of varnish between side walls and a center of tankStirrer speed - 70 rpmBearing housing and stool provided in order to reduce friction, noise and for ease operation Pressure system For pressure either the line can be taken from existing compressor unit or will be provided us as per customer requirement. Make : CGL , ELGI , Ingersol Rand / Atlas capco. Moistue separatorSafety devicesPressure regulator Control Panel Control panel will be provided as per customer requiredmentManually operated. photosPLC based. photos
Vacuum Impregnation Plant
Get Price Quote
Vacuum Impregnation Plant The Vacuum Impregnation Plants can be designed as per clients’ requirements and is provided with the following specifications. IMPREGNATION CYCLE:It is designed as per the schematic diagram attached and is used for varnish impregnation to be carried out in following steps: Pre-heating the jobs in either Impregnation Chamber or Oven.Evacuation of Impregnation Chamber (after putting the jobs) to make the voids in the jobs clear and drying of jobs for specific time & required temperature / vacuum.Induction of impregnant (Varnish) in the Impregnation Chamber from impregnant Tank to submerge the jobs in it.Pressurize the Impregnation Chamber with dry air or nitrogen to fill the voids with impregnant.Return the varnish to impregnant Tank.Evacuate the Impregnation Chamber and cure the jobs either in impregnation Chamber or in Oven for specific time. Impregnation chamber specifications:Working Volume: 100 Ltrs to 5000 Ltrs. constructed from M.S. plates, bars, structural etc.Working Pressure: @ 4 kg/ cm2 & Vacuum: As per process requirement.Lid Opening: Screw Davit type for quick opening & closing.Chamber Dimensions: as per job Size and Quantity.Added provisions are Oil Heating / cooling Jacket, Quick Clamping bolts, Stirrer, Neoprene Gaskets, Sight glass, Illuminating Lamp, Pressure Safety Valve, Vacuum & Pressure gauge.
Vacuum Impregnation Plant
Get Price Quote
the vacuum impregnation plants can be designed as per clients’ requirements and is provided with the following specifications. impregnation cycle it is designed as per the schematic diagram attached and is used for varnish impregnation to be carried out in following steps: pre-heating the jobs in either impregnation chamber or oven. evacuation of impregnation chamber (after putting the jobs) to make the voids in the jobs clear and drying of jobs for specific time & required temperature / vacuum. induction of impregnant (varnish) in the impregnation chamber from impregnant tank to submerge the jobs in it. pressurize the impregnation chamber with dry air or nitrogen to fill the voids with impregnant. return the varnish to impregnant tank. evacuate the impregnation chamber and cure the jobs either in impregnation chamber or in oven for specific time. impregnation chamber specifications : working volume: 100 ltrs to 5000 ltrs. Constructed from m.s. Plates, bars, structural etc. working pressure: @ 4 kg/ cm2 & vacuum: as per process requirement. lid opening: screw davit type for quick opening & closing. chamber dimensions: as per job size and quantity added provisions are oil heating / cooling jacket, quick clamping bolts, stirrer, neoprene gaskets, sight glass, illuminating lamp, pressure safety valve, vacuum & pressure gauge
Vacuum Impregnation Plant
Get Price Quote
vacuum impregnation plant the vacuum impregnation plants can be designed as per clients’ requirements and is provided with the following specifications. impregnation cycle:it is designed as per the schematic diagram attached and is used for varnish impregnation to be carried out in following steps: pre-heating the jobs in either impregnation chamber or oven.evacuation of impregnation chamber (after putting the jobs) to make the voids in the jobs clear and drying of jobs for specific time & required temperature / vacuum.induction of impregnant (varnish) in the impregnation chamber from impregnant tank to submerge the jobs in it.pressurize the impregnation chamber with dry air or nitrogen to fill the voids with impregnant.return the varnish to impregnant tank.evacuate the impregnation chamber and cure the jobs either in impregnation chamber or in oven for specific time. impregnation chamber specifications:working volume: 100 ltrs to 5000 ltrs. Constructed from m.s. Plates, bars, structural etc.working pressure: @ 4 kg/ cm2 & vacuum: as per process requirement.lid opening: screw davit type for quick opening & closing.chamber dimensions: as per job size and quantity.added provisions are oil heating / cooling jacket, quick clamping bolts, stirrer, neoprene gaskets, sight glass, illuminating lamp, pressure safety valve, vacuum & pressure gauge.
Vacuum Impregnation Plant
Get Price Quote
NACH addresses questions of the coil winding industry and assists setting up equipments in the coil winding industry. NACH pressure-vacuum units for impregnation systems have ensued economical solutions in motor manufacturing and repairing shops in form of flood impregnation. Understanding that the need of rotary machine manufacturing and repair shops is distinct, NACH offers a variety of customized solutions designed to suit different sectors of application.
Vacuum Pressure Impregnation Plants
Get Price Quote
8-10 Set(s) (MOQ)
as applicable : as applicale
Vacuum pressure impregnation is a special process designed to impregnate the motor coils or some castings that are used in critical applications. Vacuum pressure Impregnation often called the VPI process impregnates the coils or metal castings under vacuum. Impregnation under vacuum prevents advent of external moisture that may be accumulated in the voids of the coil or may be absorbed in insulation. Vacuum impregnated coils are free of moisture that result good electrical properties. In case of metal impregnation, vacuum impregnation results good adhesion of the chemical with the surface. Metal impregnation process that involves impregnation of castings is often accompanied by additional processes like cleaning of castings jobs, chemical treatment for better adhesion etc. Often epoxy is used for porosity sealing of the castings. In a vacuum pressure impregnation plant, there are two tanks, one is the impregnation chamber and the other is the storage tank used to store the varnish/resin. In resin impregnation system, often storage tanks require cold storage of level up to 10 Deg C to 15 Deg C. Alternately a epoxy impregnation system demands hot storage, since the curing of epoxy occurs at room temperature. Distinct manufacturers for epoxy like Alantas (formerly Dr Beck), Huntsman (formerly CIBA), Von Roll, Vantico Ltd. suggest methods for vacuum pressure impregnation with indication of different processes like vacuum, soaking, maintaining pressure, amount of pressure etc for better results.In a typical vacuum pressure impregnation system for motors, preheated coils are kept in the impregnation tank and vacuum is drawn.
Vacuum Impregnation Plant
Get Price Quote
1 Piece(s) (MOQ)
We are offering Vacuum Impregnation Plant for Varnishing &resins. Application and use in the manufacturing process of transformers and Electrical motors.
vacuum impregnation plants
Get Price Quote
vacuum impregnation plants, Vacuum Drying Ovens
Vacuum Pressure Impregnation Plants
Get Price Quote
Vacuum Pressure Impregnation Plants, oil degassing plant
Vacuum Impregnation Plant
Get Price Quote
Vacuum Impregnation Plant, Transformer Evacuation System, Varnish Dip Tank
Vacuum Impregnation Plant
Get Price Quote
Vacuum Impregnation Plant, Epoxy Mixing Casting Plants
