RF Level & Position Switch
Process Temperature : -20...80°C
Process connection : ½ “ BSP/ NPT
Probe Insulation : PTFE
Housing : Stainless Steel
Ambient Temperature : -20...60°C
Protection : Weather proof
Installation : Top/ Side mounting
Connection Cable : 1.5 meter , 3 wire
Cable gland : PG7
Input supply : 12...30 V DC, 15 mA max
Power – up time : 2 sec.
Hysteresis : ± 1 mm
Repeatability : ± 1 mm
Reaction time : 0.2 sec. Type
Output (Active) Protectd : Max.100 mA,short–circuit
Output Type : PNP standard
Fail Safe : High/ Low selectable
