Lead Cabinet X-ray System
Get Price Quote
Fully lead enclosed cabinet type Xray inspection system with multi axis manipulator to handle various jobs upto 60Kgs weight. The complete system is especially designed for aluminum die cast components manufacturers. The system gives real time feed back to the operator to improve the process and also confirms quality of the product.
Details :
Cabinet On Legs :
H.V generator and cool era replaced beneath the cabinet.
Dismountable (reduced space for transportation).
Control console with integrated control rack
Minimal floor space required
Easy installation
Compact,ergonomic design :
Cabinet weight only 4.0t or 4.5t (XL)
Cabinet size only 2500x2200x2720mm (WxDxH)
Control console, cabinet, sample, lead glass window inline.
Ergonomic control console :
Best fit 17” monitor -(3times eye-screen distance/screen diagonal)
Use of only 2 joy sticks -Ability to concentrate on the X-ray image only
External manipulator travel :
Fast manipulation
Ergonomical height for loading
Easy to use in practice
Practical proven manipulation speed :
Upto15m/min(49'/min), earlier systems 2-3m/min (8'/min)
Adaptable for each inspection position
Increased through put by using simple sample fixtures
Programmable inspection sequence
Experience of more than 100 installed systems
Diagram of allowed/safe travel distances
Collision protection by software & hardware greater travel distances.
Quick remote PCNC service
Plug-in connection for safe and quick installation
Compact footprint with back-to-back setup and easy maintenance access
Batch wise testing for smaller samples.
Faster inspection by easy loading and un-loading.
Can be customized to CONVEYER based X-ray inspection to meet production criteria.
No special/ strong fixture for sample needed.
No adaptation of magnification necessary.
High sample weight
24/7 Support on X-ray machine
100% quality control is simultaneously making sure automobile manufacturers' strict specifications are being complied with, and without forfeiting quality
