Fanless Cooling Tower Dealers (41 products available)

We are offering Tower Tech India – Manufacturer and exporters of Fanless cooling tower, Natural draft cooling tower and Fill Less Cooling Tower.

• Type: Fanless Cooling Tower
• Material: FRP
• Weight: 400-500kg
• Warranty: 5years
• Gauge Thickness: 10-15mm
• Features: water saving and pollution free, safety with environmental protection

The FRP/ Natural traditional Cooling Towers are called as Fanless or Fill less Cooling Towers because in this model no fan or fill is used to cool the water.    In Timber atmospheric / Fan less Cooling tower , treated wooden louvers were used as the side wall of the Cooling Tower to restrict the water spillage and allow the outside wind passage to go inside the Cooling Tower and act as the Cooling media. Simply says, in Fan less Cooling Towers the Hot water will be sprayed in the top of the Cooling Tower with spray nozzles into small droplets like mists and the droplets are crossed with the atmospheric wind flow to get the water cooled. The same technique is used in FRP Fanless / Natural Draft / Fill less Cooling Towers. Instead of costly timber louvers, FRP louvers are used. This Fanless cooling towers are very economically operating Cooling Tower. Since there is no fan or electric motor, there is no huge operating or maintenance cost involved in this Cooling Tower. And also in Energy efficiency point of view, this is the best Payback Cooling Tower when comparing with other models.    And also very low noise operated Cooling Tower. The noises of other model cooling towers are due to Fan, Motor, Gear box and Drive shaft and its vibrations only. Since these models of Cooling Towers are not having Fan, motor, Gear boxes, this equipment has no trouble-some of noise and vibration.

• Type: Natural Draft Type
• Material: FRP
• Temperature: 37 TO 33 Deg C
• Gauge Thickness: 10-15mm
• Brand Name: JE
• Capacity (Litre/sec): 15 tr - 1000 tr
• Application: Industrial
• Tower Design: Cross Flow
• Tower Type: Natural Draft
• Cooling Capacity (in tons): 1 TR

We are engaged in manufacturing a quality range of Fanless Filless Cooling Towers, which is working under jet principle and are manufactured using advance technology. In our range, kinetic energy of water is converted into kinetic energy of air with the help of specially designed ejection nozzles. Our range of fanless filless cooling towers is one of the most energy saving cooling towers. Advantages Without Motor : No Power ConsumptionWithout Fan : No BreakdownWithout Packing : No Future ReplacementWithout Clogging : No difference in performanceMinimum Evaporation : No difference in percentage of loss. Material of Construction Louvers : FRPStructure : MS Hot Dip GalvanizedNozzles : PP Non-Clog type Nozzle of Virgin QualityLadder : MS Hot Dip GalvanizedHeader Pipe : GI Pipes

Based on the cutting-edge technology, the Fanless Cooling Tower, which we offer, is manufactured as per the set industrial standards. We offer the best Fanless Cooling Tower at the market leading rates to the clients. We are a dependable Manufacturer, Supplier and Exporter of Fanless Cooling Tower. Highlights Power consumption : No fan, higher head required; equivalent total power consumption with traditional water cooling towerSilent design : No fan, motor, reducer, rotating machinery with noise lower than the ultra-low noise cooling towerCooling method : Cooling water spray kinetic ventilation without external power sourceSuspension means: No vibration, no shock absorbers neededOperating and maintenance costs : Composed of static components made of corrosion-resistant materials.No wear and tearLow maintenance charge Working Principle of Fanless cooling tower : Natural Type Cooling Towers are nothing but the water is cooled with natural atmospheric air travelling and the water is sprayed with the help of Spray nozzles and covered with louver covers. This method saves the operating cost because it has no mechanical fans. These cooling towers are called as atmospheric cooling tower or Fanless and fillless cooling tower. (Available range is from 7.5 TR to 100 TR) Splash loss and dust prevention capacity : Five-fold water blocker installed at the air vents of the tower top for liquid-water separation. In addition to dust prevention, the water splash loss is between 0.001~0.009% (as per spray pressure). Reduce more than 90% water splash loss than the traditional tower and reduce the transmission of Legionella bacteria Material of Construction Structure : Is made from lined with FRP for corrosion resistance with heavy M.S.Angle/Tee/Channel sections and hot dipped galvanised orLouvers : Are made from fibreglass reinforced plastics which ensures corrosion resistance and good mechanical properties.Water Distribution Headers : Are made from �c� class galvanised pipe.Nozzles : Are made from nylone-6 to give good corrosion resistance.Nuts& Bolts : Are made from nylone-6 & M.S. Electroplated.

We are offering fanless cooling tower is massive in demand due to its use in high temperature and low temperature applications. Fanless cooling tower provided by us is constructed using wood and frp. The range of fanless cooling tower is tested on certain quality parameters before delivered in the markets. This fanless cooling tower is obtainable at highly competitive rates. features no requirement of fill or fanslow power consumptionminimal maintenancereliable performancelonger service lifedurable available in 5tr of any capacity

The products are strictly packed and dispatched safely to the clients stated address and that too in the committed time span. Rely on us for premium quality of the products as we make use of the finest grade raw material for preparing them. Also, we procure it from the reliable places after complete quality satisfaction.

• Driven Type: Electric
• Power: 1-3kw

The Fanless, Filless Induced Draft design has been developed after a detailed research and analysis of the engineering design. This design allows a substantial saving in Power Consumption. Also, the common problems of breakdown and maintenance of Cooling Tower are eliminated to a large extent with this design..

Cooling Towers is working on the principle of evaporative cooling. In which hot water comes directly in to contact with ambient air and cooling is achivead mainly by small portion of water gets converted to vapour, thus caring away the latent heat of By which water gets cooldown and air gets heated, saturated and also caring away some sensible heat from water.

• Temperature: 4°C To 30°C

Wooden Single Flow and Double Flow induced Draft Cross Flow Direct Drive System. Reduction Gear Box Drive Suystem. Counter Flow Square Rectangular Induced Forced Draft Towers. Packaged Wooden Double Single Flow Induced Draft Cross Flow. Fan-less Induced Draft Wooded Cooling Tower [ Atmospheric Natural Draft Cooling Towers]. Re-Inforced Concrete Cooling Towers. Spares For any Type and Make of Cooling Systems.

Fanless Filles Cooling Towers The Name “Fan Less Fill Less” Says It All. Devoid Of Either The Fan Or The Fill Media These Towers Are Guaranteed For 100% Savings In Power & Maintenance Down Time. The Hot Water From The Heat Source Is Circulated To The Inlet Header Of The Cooling Tower. The Inlet Header Pipes Have Branches And Sub Branches Covering The Internal Area Of The Cooling Towers. The Non Clog Nozzles Are Connected At The Outlets Of The Sub Branch Pipings. At A Inlet Pressure Of 1 – 1.5 Kg/cm’ To The Cooling Tower. The Hot Waters Are Atomized To A Mist State. The Nozzles Are Self Designed To Create More Pressure Thereby Converting Water Into Minute Atomized Particles. From The Four Sides Of The Louvers, Plenty Of Fresh Air Is Automatically Circulated By The AeroDynamic Designed FRP Louvers.   Waters Are Directed By The Special Aero Dynamic Louvers Towards The Collection Sump. The Louvers Ensure That The Water Do Not Spill Out Of The Towers. The Hot Waters, That Are In A Mist State, Comes Directly Into Contact With The Ambient Air And The Cooling Is Achieved Mainly By The Portion Of Water, That Gets Converted To Vapors, Thus Caring Away The Latent Heat Of Evaporation. Therefore, Water Gets Cooled And In This Process.

The name "FAN LESS FILL LESS"says it all. Devoid of either the fan or the fill media these towers are guaranteed for 100% savings in power & maintenance down time. The special aero dynamic designed FRP GI louvers minimize spillage and evaporation losses. The Hot Dipped Galvanized structural and S.S. fasteners increase the life periods of the towers. Their unique non clog nozzle atomizes water to fine mist state to ensue efficiencies of the towers and are easily maintained even during operations These Cooling Tower are designed on the principle of evaporative cooling in which, hot water comes directly in to contact with the ambient air and the cooling is achieved mainly by portion of water that is atomized to a mist state, which is then converted to vapors, thus caring away the latent heat of evaporation. In this process, water gets cooled and the air gets heated saturated thereby caring away some sensible heat from water.

The FRP/ Natural traditional Cooling Towers are called as Fanless or Fill less Cooling Towers because in this model no fan or fill is used to cool the water.  In Timber atmospheric / Fan less Cooling tower , treated wooden louvers were used as the side wall of the Cooling Tower to restrict the water spillage and allow the outside wind passage to go inside the Cooling Tower and act as the Cooling media. Simply says, in Fan less Cooling Towers the Hot water will be sprayed in the top of the Cooling Tower with spray nozzles into small droplets like mists and the droplets are crossed with the atmospheric wind flow to get the water cooled. The same technique is used in FRP Fanless / Natural Draft / Fill less Cooling Towers. Instead of costly timber louvers, FRP louvers are used. This Fanless cooling towers are very economically operating Cooling Tower. Since there is no fan or electric motor, there is no huge operating or maintenance cost involved in this Cooling Tower. And also in Energy efficiency point of view, this is the best Payback Cooling Tower when comparing with other models.  And also very low noise operated Cooling Tower. The noises of other model cooling towers are due to Fan, Motor, Gear box and Drive shaft and its vibrations only. Since these models of Cooling Towers are not having Fan, motor, Gear boxes, this equipment has no trouble-some of noise and vibration.

Fanless Cooling Towers is a design in which the flow is directed perpendicular to the water. The air continues through the fill and thus past the water flow into an open plenum volume. A fan forces the air out into the atmosphere. Air flow enters one or more vertical faces of the cooling tower. Water flows through the fill by gravity. Specifications Fanless Cooling Towers designs are popularly associated with nuclear power plants. The same kind of cooling towers are often used at large coal-fired power plants. Some instead cool their heat exchangers with lake, river or ocean water. Applications : Fanless Cooling Towers leaves its dissolved salts behind in the bulk of the water which has not been fanless, thus raising the salt concentration in the circulating cooling water. Advantages : Fanless Cooling Towers absorbs heat from the hot process streams which need to be cooled or condensed, and the absorbed heat warms the circulating water.

The Fanless, Filless Induced Draft design has been developed after a detailed research and analysis of the engineering design. This design allows a substantial saving in Power Consumption. Also, the common problems of breakdown and maintenance of Cooling Tower are eliminated to a large extent with this design.Features Eliminates fill media and hence maintenance Eliminates motor fan and hence power consumption Used for high temperature applications Used for industries having polluted waters

The FRP Timber Natural traditional Cooling Towers are called as Fanless or Fill less Cooling Towers because in this model no fan or fill is used to cool the water. In Timber atmospheric Fan less Cooling tower , treated wooden louvers were used as the side wall of the Cooling Tower to restrict the water spillage and allow the outside wind passage to go inside the Cooling Tower and act as the Cooling media. Simply says, in Fan less Cooling Towers the Hot water will be sprayed in the top of the Cooling Tower with spray nozzles into small droplets like mists and the droplets are crossed with the atmospheric wind flow to get the water cooled. The same technique is used in FRP Fanless Natural Draft Fill less Cooling Towers. Instead of costly timber louvers, FRP louvers are used. This Fanless cooling towers are very economically operating Cooling Tower. Since there is no fan or electric motor, there is no huge operating or maintenance cost involved in this Cooling Tower. And also in Energy efficiency point of view, this is the best Payback Cooling Tower when comparing with other models.

Fanless Cooling Towers are manufactured in best quality standard to meet internationally quality standard.

Our fan less cooling towers design does not required any fan are fills, no maintenance like other cooling towers, non clock nozzle are easy to cleaning reduce spillage and evaporation loss. Hat dip galvanized structural and S.S fasteners increase the lifetime as well as the efficiency of the cooling tower it can be installed for any range of cooling application.
