Ferrule Printing Machine Dealers

As part of our commitment of continual support for products we sell to our customers, we also supply the various consumables required for the Ferrule Printers like PVC Ferrules, Ink Ribbon, Marking Tapes which passes through strict quality checking procedure.

Printing Method Thermal transfer Resolution 300dpi Printing Speed Tubes: High: 25mmsec. Standard: 18.5mmsec. Low: 12.5mmsec. Labels: High: 25mmsecs. Standard Low: 12.5mmsec. Output Rate High Mode: 35pcs.min. Standard Mode: 30pcs.min. Low Mode: 21pcs.min. (Printing 20mm tubes, 5 full-size characters, consecutive print mode, half-cutting) Ink Ribbons Exclusive cassette Black: 100m White: 85m Character Sizes 2mm, 3mm, 6mm (full-width, half-width available for each) Input Modes Alphanumeric, symbol input Display LCD Graphic (160 x 64 dots)

Electronic Ferrule Printing Machines and Label & Sign Printing Machine , Consumables from MAX Co. Ltd, Japan are the main products offered by Barcodebazar. The max letatwin products are Max 390A Ferrule printing machine & Letatwin 380E Ferrule printing machine, ink ribbons, pvc tapes, pvc tubes etc. Barcode bazar also offers the service and repair for the Ferrule printing Machines.

description indian barcode corporation providing you the best range of letatwin lm550a/pc-ferrule printing machine, portable ferrule printing machine. technical specification 1. Printing method-thermal transfer method 2. Display-lcd dot matrix 64x160 pixel (backlit) 3. Printing speed-40mm/s (std.) 20mm/s (low temprature mode) 4. Max printing length- tube-20m, tape-5m, 5. Maximum no. Of characters to input-5,000 characters per file 6. Character size-1.3,2,3,6mm height 7. Usable tube-1.5mm dia ~ 8.0mm dia(pvc tube) 2.0mm dia ~ 6.5mm dia (heat shrinkable tube) 8. Usable tape- width 5,9,12mm (max genuine tape) 9. Tube cutting method-auto half cut, manual full cut 10. Internal memory-250,000 characters (max 50 files) 11. External memory- usb memory 12. Power supply- dc12v, 3.0a 13. Operating environment-10 to 35 degree centigrate features brand/makemindwaremodel/typeletatwin lm550a/pccapacity5,000 characters per file letatwin lm550a/pc-ferrule printing machine features : 1. Fastest speed 2. Versatile printing capability 3. Connect to your pc with a usb cable or usb flash drive comes with plastic carry case large and backlit lcd display the pitch can be set up to maximum 60mm. maximum 250,000 characters built in large memory easy access from your pc with usb

LM 380EZ is Economical version of Indomax Ferrule Printing machine from MAX Japan. It does the best marking job and has a high volume memory as it is developed for a heavy use. The large backlit LCD display and the large character memory along with a continuous printing function makes this machine a very sought after product for all your marking needs.

Ferrule Printer used in preparation of self-adhesive labels and ferrules used for control panels. Alphabetical/Numerical characters can be printed on both the tubes (sleeves) and self adhesive tapes with desired adjustment in character size, space and width. This machine has a nice LCD backlit display for viewing the matter to be printed and also has a very important advantage of accepting data directly from PC, which will save the operational time and labour cost. One can directly connect the machine to the PC and after giving the print command, print ferrules from the PC directly. One can also use the USB external memory stick for transferring the data from PC to LM machine.
