Profile Controller Dealers

Profile Controller is designed to act as a Process Controller for controlling process parameter with respect to time. With the help of extensive instruction set, user can program the profile as per process requirement. Unit supports instructions like jump, loop, loop with count apart from ramp and soak control. To operate external controls like valve or hooter etc. unit has provision of auxiliary relays.

This ampere hour meter is designed to control rectifier during battery formation process. IM2508 ampere hour profile meter is a programmable step profile type device. In the process of the battery formation, the battery has to be charged at different ampere hour capacity in steps. To list some special features of IM2508 are short circuit monitoring, starting current control and bar forming timer.

Libratherm offers field proven models of microprocessor based multiple Ramp Soak programmable PID temperature controller PRC-300 & PRC 309 which are designed to improve reliability, accuracy and control in all temperature control applications. It features Ramp and Soak functions (the capability to control the temperature and its rate of change over a predetermined time span). One to ten different patterns each of sixteen rampsoak steps can be programmed into the memory with the user friendly membrane keyboard. Separate displays are provided to monitor simultaneously the Process temperature, Set temperature and the Program number. It can also be used as single set point control when the profile control is not desired. Inputs can be either Thermocouple, IR Thermocouple or RTD Temperature Sensors, or Voltage or Current Signals.It offers both switching outputs in the form of SSR or relay to drive external load contactor and continuous control outputs in the form of (4-20)mA or (0-20)mA or (0-5)volt or (0-10)volt which can be used to control heater power through Thyristor power pack (for electrical heating system) or to control the position of a modulating motor valve (for oil or gas fired heating systems). The analog outputs can be directly connected to Libratherm make single phase three phase SCR phase angle fired power controller which is ideally suitable for both resistive and inductive heating load. Additional 2 relays are also provided for time or temperature dependent event outputs as per the system requirement. The programmed profile and other parameters are retained in the non volatile memory in the event of power failure. Two types of rampsoak programming facility is available, one by programming end set points and time between the two set points and other by directly programming the rate of heating or cooling i.t.o. oC per hour and soaking time. Libratherm offers ready use control panel of small to large size incoportaing above controllers with thyristor, ssr and other panel accessories.PRC- 2000 IS Upgraded version of PRC 300 for Temperature 0.1 to 2000.0 oC.Application Heat Treatment cycle control in metal industry.Investment casting in jewellery industry (for wax burn-out furnaces).Environmental test Chambers.Furnace Oven control.

Single PC can monitor multiple MPC-03 controllers on a single party line, this enables viewing status of all chargers simultaneously. Large LED display for viewing status, programs from longer distance Keyboard for selection and editing of program, execution control Multiple program storage Configurable for wide range of current in three ranges In cycle display of actual current and elapsed time Memory retention: Automatic continuation of execution after power interruption Loop command available for intermittent charge/discharge with time base in sec. Automatic data output issued in charge, discharge and pause for external data logger Additional data logging events can be generated with Data and EOF commands for external data logger Terminal Voltage monitoring at display Ampere / Hour measurement and display Windows Based PC Software for viewing program, step command, actual current, voltage, AH, programmed step time. Facilities through PC to edit, download to MPC-03, start, stop and interrupt the programs. Maximum 250 number of MPC - 03 on one PC. Maximum 31 number of MPC - 03 on one party line. Party line can be extended by putting repeaters. Salient Features: Multi Drop Profile Controller is programmable current controller system suitable for battery manufacturing. Programmable current and time for charging, discharging and pause Direct 75mV shunt interface for actual current feedback Built in PI close loop adjusts the current reference output to set current

Input: :Universal [All type of thermocouple and PT100‚ Cu50 (RTD)‚ linear voltage‚ linear current‚ MV‚ 2 wire transmitter input] Program: 50 steps (TUTC-P50); 30 steps (TUTC-P30); event  output :Relay‚ SSR‚ Linear voltage‚ linear current‚ Output range limit Control algorithm: AI PID / AI MPT; heating / cooling dual output with 2 sets of PID; auto tuning; Set point: Set point range limit; dual set point switch; remote set point Alarm: High‚ low‚ high deviation and low deviation, Communication: RS 485‚ RS 232 (Modularized Installable)Re transmission O/P: Linear current or voltage (SV OR PV), Power supply: SMPS 100~240VAC/DC‚ 50 Hz OR 24 V DC ,Accuracy: 0.2%FS Display resolution: 0.001° C (Selectable), Operating ambient: Temp.: 10°C~60°C‚ humidity:

The Selec PR502 Profile controller are advanced, 4 digit auto-tuning controllers with up to 2 outputs which are designed for control of temperature or processes in a wide range of industrial applications. The controllers operate from a range of thermocouple or 2/3 wire PT100 (RTD) input sensors, or from a millivolt, 0-5Vdc, 0-10Vdc or 0/4-20mA process signal. Versions are available with relay, SSR or analogue outputs which can be configured as 1 on/off or PID control and up to 2 alarm outputs, or as 2 on/off or PID controls (heat/cool) and 1 alarm output. The temperature controllers are housed in a compact square enclosure which panel mounts, and are auxiliary powered from 85 to 270VAC. Features In depth Ramp / Soak control Dual display, 4 digit, 7 segment LED LED status indicator: Relay ON, Tune, Alarm, Manual 4 front panel control buttons TC / RTD input, Analog input ON / OFF, PID, PID auto tune (°C / °F selectable) 10 Programs, 16 steps each Alarm at each step, Memory retention, Two set points

T Profile Controller, PID Temperature Controller, Wave Chiller Controlle

Profile Controllers, Counters, Thermoelectric Coole

Profile Controller, Orp Controllers, Electrochemical Analyzer, Scada Syste

Profile Controller, Drive Controller, Microprocessor Controller Uni

Profile Controller, Steam Distribution Headers, Weighing Controlle

Profile Controller, USB Data Logger, Water Level Controlle

Profile Controllers, Heavy Duty Industrial Connector, Din Rail Mounted Timer

CNC Profile Cutting Controller, CNC Oxy Plasma Cutting Machin

Profile Controllers, Device Programmer, Digital / Analog Time Switc

Profile Controller, Scada Software, Strip Chart Recorder, Spindle Moto

Profile Controller, Airflow AC Axial Fan, Blind Temperature Controlle

The Fuzzy Logic plus PID Microprocessor base Profiling Controller series incorporate two bright, easy to read 4-digit LED Displays indicating Process value & set point value

Profile Controller, Micro Ohm Meter, Non Contact Infrared Thermomete
