Rotary Microtome Dealers

• Type: MANUAL
• Brand Name: WESWOX
• Application: PATHOLOGY LABS
• Model Number: MT-1090A
• Place of Origin: India

We are offering senior rotary microtome, automatic feed release with automatic safety device : total feed excursion is 28mm when the limit of the feed is reached, a safety device automatically disengages the feed mechanism to eliminate jamming and possible damage to the feed screw. Critical accuracy : with every complete revolution of the counter balanced drive wheel, the feed pawl engages precisely into the teeth of the ratchet wheel which moves forward and advances the object holder through a cone and inclined plane mechanism is such precise increments that specimens can be sectioned down to even 1 micron in thickness. Front-positioned feed indicator with latest cam drive system : the feed indicator, graduated in microns is conveniently located at front of the instrument and feed setting from 1 to 50 microns in steps of 1 micron each is controlled by a knurled knob at the back of the microtome. The strudy knife holder in addition to knife elevating and levelling adjustments provides lateral movements for complete use of knife edge. The angle adjustable up to 300 is indicated on a reference scale. A streamlined 'weswox' razor 120mm made from highest quality fine grain tool steel which is heat treated for micro structure is furnished with the instrument. Technical data: feed adjustment 1-50 microns (in steps of 1 micron each) opening of object clamp (ball and flange type) 37x27 mm total feed excursion 28mm overall size 16"x10"x9" and approx. Weight 27kg. In cardboard box or 60kg in wooden case. Special features : surface grinding on base, horizontal, vertical and inclined slide for smooth and accurate motion ratchet wheel, cam and cam weight are made of gun metal axel and catcher made from special steel made on imported machine. Standard accessories : 120mm razor wit

• Type: Rotary Microtome
• Brand Name: Radical
• Condition: New
• Warranty: 1 Year
• Model: RMT-30
• Feature: Good Quality

Radical Senior Precision Rotary Microtome Model Rmt - 30 Is The Most Precise And Uniform Sectioning Equipment For Use In Medical Colleges, Universities, Research Laboratories, Hospitals And Educational Institutions. The Internal Mechanism And Knife Holder Rests On A Heavy-Duty And Rigid Base To Render A Shake Proof Operation. The Protective Aluminium Cover Is Hinged To The Base And Swings Back So That The Interior Parts Are Completely Exposed For Convenient Setting, Cleaning, Lubrication Etc. Feed Mechanism Is Dependent Upon The Vertical Movement Of The Object Block. With Every Complete Revolution Of The Counter Balanced Drive Wheel, The Feed Pawl Engages With The Teeth Of The Ratchet Gear Which Moves Towards And Advances The Object Holder Through A Cone Inclined Plane Mechanism In Precise Increments So That The Tissues Can Be Sectioned Even To A Thickness Of One Micron. When The Limit Of The Feed Reaches At The End, A Safety Device Automatically Disengages The Feed Mechanism To Prevent Jamming And Avoid Damage To The Feed Screws. The Feed Indicator Is Graduated In Microns, Is Conveniently Located In The Front For Instant References And Its Setting Is Controlled By A Knurled Knob At The Back Of The Microtome. The Sturdy Knife Holder, In Addition To Knife Elevating And Leveling Provides Lateral Movement For Complete Use Of Knife Edge. The Angle, Adjustable Up To 30o, Is Indicated On A Reference Scale. The Knife Supplied With The Microtome Is Fabricated From High Carbon Fine Grain Tool Steel Which Is Heat-Treated For Proper Temper & Tested For Micro Structures. A Lever Is Provided To Lock Counter Balanced Drive Wheel And Specimen Block Is Stopped At The Top Of Its Excursion, Providing Ample Clearance Space For Safety Insert And Removal Of Knife And Block Holders. A Quick Flip Of The Lever Releases The Drive Wheel.

Jindal precision manual rotary microtome is the most advanced sectioning equipment for medical colleges, universities, research laboratories, hospitals and educational institutions. The internal mechanism and knife holder rest on a heavy and rigid base to render a shake proof operation. We are leading manufacturer and suppliers of Manual Rotary Microtome. The latest designed light weight protective cover is hinged to the base and swings back so that the interior parts will be completely exposed for convenient cleaning, lubrication & setting etc. The feed mechanism is dependent on the vertical movement of the object block. With every complete revolution of the counter balanced drive wheel, the feed pawl engages precisely on to the teeth of the ratchet gear which moves forward and advances the object holder through a cone, inclined plane mechanism in such a precise increments that tissues can be sectioned even in one micron thickness. Well designed features for precise and accurate serial sectioning, with feed setting visible from front, improved locking device and counter balanced wheel. Feed is adjustable from 1 to 50 microns in steps of 1 micron. Free up and down movement of object clamp. Automatic restricted total excursion of 28 mm by disengaging the feed mechanism to prevent jamming.   Ball and flange object clamp provides flexible orientation of object piece. It takes specimen up to 32×27 mm on stem of block holders. Knife holder allows for 120 mm on 180 mm long knife. Cutting angle is adjustable through 30 degrees. Two levers release knife holder for resetting angles and a third lever releases the entire assembly for movement on slide way to adjust horizontal distance from object.Latest cam system eliminates the conventional cord system for feeding, resulting in better section cutting and improved efficiency of the machine. Supplied complete with one knife 120 mm long with back and handle in wooden box, 2 block holders, One bottle of lubrication oil, dust cover      Spare Accessories Special Alloy Steel Knife Size :- 120 mm, 150 mm, 180 mm, 200 mm Stainless Steel Back for Knife Block Holder/Specimen Holder Size :- 37 mm, 25 mm, 20 mm Embedding Moulds made of S.S. L × W × D Size :- a. 16 × 16 × 12 mm b. 22 × 22 × 12 mm c. 32 × 25 × 12 mm L-Moulds made of brass Size :- a. 37 × 25 × 15 mm pair b. 50 × 25 × 15 mm pair c. 75 × 30 × 19 mm pair Disposable Embedding Ring

Technical Data: Section Thickness : Section Thickness Setting range 0.5mm-90mm.Setting Values :from 0.5mm – 1mm in 0.5mm increments.from 1mm – 99 mm in 1mm incrementsTrimming SectionThickness setting Range : 0.5mm – 99mm.Setting Values :from 0.5mm – 1mm in 0.5 mm increments.from 1mm – 99 mm in 1mm increments.Specimen Retraction Motorized Operation : Varying with section speed. Product Code:YSI-060

The Precision Rotary Microtome manufactured by us is used precise sectioning of tissues up to 1 micron thickness. The feed locator drives for system for accurate feed setting from 1 to 50 microns in steps of 1 micron. Features of Our Precision Rotary Microtome :- Independent feed mechanism with automatic safety deviceUniversal knife holder with lateral movementPermits use of entire knife edgeBall and flange type object holder for accurate centering of the specimenFull swing protective cover for easy cleaning and lubrication Available With :- One razor 120 mm with back and handleA set of three object holdersOne honing plateOil canDust cover, in wooden cabinet

• Type: Rotary Microtome
• Certification: CE Certified,ISO 9001:2008
• Condition: New
• Driven Type: Mechanical
• Warranty: 1year
• Country of Origin: India
• Brand Name: LABOID
• Brand Name: Laboid
• Section Thickness Setting: 0.5-60 µm
• Setting Value: From 0.5µm - 2µm in0.5µm increments From 2µm - 20µm in1µm increments, From 20µm - 60µm in 5µm incre
• Vertical Stroke: 70mm
• Specimen Orientation: Horizontal 8 Degree, Vertical 8 Degree
• Object Feed: 28mm
• Max. Sectioning Area: 60mm x 50mm
• Dimensions (WxDxH): 460x500x300 mm
• Working Height(Knife Edge): 105mm
• Weight(without acc.): 23Kg. (Approx)

• Minimum Setting Value: 0.5 Micrometre
• Trimming Thickness Range: 0.5 um-60 um
• Vertical Stroke: 60 mm
• Max Specimen Size: 50 x 50 mm
• Specimen Orientation: 8 Degree

We are supplier and exporter of this product.

• Brand Name: Weswox
• Model: MT-1090A
• Feed Adjustment: 1-50 microns (in steps of 1 micron each)
• Opening Of Object Clamp: 37x27 mm
• Total Feed Excursion: 28 mm
• Overall Size: 16x10x9 Inch

Vibration free operation. Smooth Drive Wheel with Locking. Conveniently located feed indicator. Automatic feed release mechanism. Study, rigid construction.   Minimum maintenance.

Model No .: KG 2392 Microtomes     With three object holders. One razor 120mm and honing stone. Automatic Feed Release Device. Graduated in microns for feed setting. Feed adjustments 1-50 µm. Minimum thickness 1 µm. With Spare Accessories.

• Max Specimen Size: 50X45 mm
• Automation Grade: Automatic
• Product Type: Biology Lab Equipment
• Material: Di-Cast
• Max Specimen Size: 50 x 50 mm
• Weight: 35 kg
