Single Coil Spring Seals Dealers (48 products available)

• Shaft Diameter(dl): 10mm to 100mm
• Pressure(p): 10 bar
• Temperature(t): -200C  to 1800C
• Velocity(v): 15 m/sec
• Seal Faces: Carbon, Ceramic, SiC, Tung. Carbide
• Metal Parts: SS304, SS316, Special Alloy
• O-rings: PTFE / Viton

Single coil spring seal is single coil spring seal developed for light contamination, dirty media and clogging type application. This type also allows it to fit onto a normal shaft without any balancing step. The mechanical drive of this seal is realised by grub screw which lock onto the shaft. The seal has a limited axial length, compact shape which allows easy mounting. SEAL CHARACTERISTICS Single Seal Unbalanced Helical Coil spring Independent of direction of rotation APPLICATION General Chemicals Petrochemicals Light Hydrocarbons

PDM series seals are wave washer spring seals. Main advantage of these seals are reduced length due to use of wave spring and work more efficiently in dirty applications as spring clogging does not occur.Specifications : Shaft Diameter - 14mm t0 100mm Pressure Unbalanced - 10 bar Pressure Balanced - 25 bar Speed - 2900 rpm Temperature : -50oC to + 220oC Face Combination - Carbon, Ceramic (99.5%), Silicon carbide, Tungsten carbide, Stellite etc.

We Bring Forth to Our Customers An Assortment of Single Coil Spring Unbalanced Seal. These Find Wide Application in Fertilizers, Refineries,& Petroleum Pipelines. Also, These are Made Using Top Class Raw Material, Which is Procured from Trusted Vendors. We Can also Custom Design These Seals in Different Sizes and Shapes, as Required By Clients. operating Limits shaft Dia. : 25 to 150min pressure : Up to 10 Bars temperature : -50 to 180 C speed : Up to 15 Ints.

We are Offering Optimum Quality Single Coil Spring Seals in the Nationwide Markets. Single Coil Spring Seals are Commonly Used in Processing of Paper and Pulp Where High Viscosity Medium is Applicable. These Single Coil Spring Seals are Capable of Withstanding Up to 8 Bar Pressure and Can Be Availed in Different Shaft Sizes as per the Requirements. Besides, We Provide Single Coil Spring Seals At the Most Affordable Rates.

• Type: Single Coil Spring Seals
• Shape: Round
• Color: Shiny-silver
• Speed: 0-20m/s, 20-40m/s
• Size: 0-3inch, 0-50mm, 100-150mm, 50-100mm, 6-9inch
• Application: Aqueous Solutions Chemicals
• Temperature Range: 0-25 Degree C, 25-50 Degree C
• Surface Finishing: Coated
• Spring Type: Single

Buyers can contact us for durable Single Coil Spring Unbalanced Seals We offer single coil spring unbalanced seals and single coil spring balance seal. Our seals are available in different types such as cs11, cs11r, cs11bb, cs11br and cs4. Our seals are used in corrosive & viscous fluids application, sulphuric and generally handled by high temperature pumps. Our Single Coil Spring Unbalanced Seals are widely demanded in industries like oil & refinery, fertilizers nuclear plants, and petroleum pipelines. AES : p08, p080, t01, t02

We are instrumental in offering superior quality Single Coil Spring Seals that come under BCS-SC Series. Our Single Coil Spring Seals are compactly designed to take Thermal Expansion, Vibration, Axial Play Miss-alignment to great extent work in both direction of rotation. This ensures efficient handling of liquids containing solid particles like slurries, sludge̢۪s, sewage, viscous and abrasive materials generally handled by Pumps, Mixers, Agitator, and Compressors etc. Both the faces of Single Coil Spring Seals are designed to take care of the presence of solid particles in the liquid which would otherwise damage the mating faces and contaminate the process. The compactness of Single Coil Spring Seals ensures easy handling, installation and provides trouble free service with virtually no maintenance.

• Brand Name: ALFA
• Model Number: ALSC

we offer Single coil mechanical seal to suit all pumps seal in available in all faces. all elastomers can fit all pump model

• Seal Faces: Carbon Vs. Sic./tc
• Shaft Diameter: 10 to 150mm
• Speed: Up to 15 M/s
• Pressure: Up to 30 Bars
• Temp.: -50 to 180 Degrees Celsius
• Secondary Seals: Viton/ptfe/gft
• Metal Components: Ss-316 / Ss-304
• Applications: Used in High Pressure Pumps, Refineries, Fertilizers, Nuclear Plants & Petroleum Products.

The company has entrenched its position as one of the reliable Manufacturers and Suppliers of Single Coil Spring Balanced Seals (TYPE FSI 25). Single Coil Spring Balanced Seals are single coil balanced mechanical seals, reliable & rugged enough for variety of applications. Single Coil Spring Balanced Seals are designated as FSI 25 & FSI 26 for 'O' Ring & PTFE wedge type Secondary Seals respectively. The balanced & unbalanced version is obtained by simply changing the carbon face assembled through circlip provided. Non-clogging spring design enables these Single Coil Spring Balanced Seals to be reliably used in situations involving abrasive, corrosive and viscous media. Single Coil Spring Balanced Seals are generally handled by high-pressure pumps.

• Specialities: Unbalanced Seal
• Specialities: Unbalanced Seal
• Brand Name: SENAA SEALS
• Pressure: Up to 10 Bars
• Temperature: -20 C to 300 Degree C
• Rotary face: Carbon, Sic,TC
• Stationary face: Carbon, Sic,TC
• Elastomers: PTFE, Graphoil
• Springs and retainers: SS 304,SS 316 & Titanium

• Material: Carbon Steel
• Shape: Round
• Color: Black
• Usage: Industrial
• Surface Finish: Metal Coated

• Temperature: -50c° to + 500 c°/-60 F° to 930 F° depending on the material used.
• Pressure: Type DB-FU-Up to 17 bar g/247 psig, Type DB-FB Up to 62 bar g/900 psig.
• Size range: 3/8" to 8" (10mm to 200 mm)

General chemical applications, oil refining and petrochemical, Pharmaceutical industries. Suitable for use with abrasive contaminated and corrosive fluids, for slurries, sludges and effluents with solid presence. By choosing suitable component material the seals can be adapted to operate with a wide range of liquid and operating conditions.

• Seal Faces: Carbon, Ceramic, SiC, Tung. Carbide
• Shaft Diameter: 10...100mm
• Pressure: 18 bar (max)
• Temperature: -20...140OC
• Velocity: 15 m/sec
• Metal Parts: SS304, SS316
• Bellows: Viton, Nitrile

Series AES-002 is unbalanced single acting helical coil spring seals independent of direction of rotation. The drive ring's notch design eliminates over stressing of the elastomer bellows. Slippages are eliminated, protecting the shaft and sleeve from fretting. Seal can be repaired in field with minimum spares, minimizing the downtime cost.     SEAL CHARACTERISTICS • Single Seal• Unbalanced• Conical Spring• Independent on direction of rotation     APPLICATIONS • Water pumps• Mixers and Agitators• Sewage pump• Pulp and papers

• Type: Single Coil Spring Seals
• Material: Metal, Stainless Steel
• Shape: Round
• Color: Grey, Grey-silver, Metallic, Shiny-silver, Silver
• Speed: 0-20m/s, 20-40m/s
• Specialities: Sturdy Design , Highly Durable
• Size: 0-3inch, 0-50mm, 3-6inch, 6-9inch
• Application: Aqueous Solutions Chemicals, Some Acids
• Surface Finishing: Coated, Non Coated
• Spring Type: Double, Single

• Speed: up to 15 m/s
• Shaft Diameter: 25 to 150mm
• Pressure: up to 10 Bars
• Temperature: -50 to 280°C

TYPE LTS-72HF : are single coil unbalanced seals, these seals are simple in design & reliable & rugged enough for the most difficult applications. In LTS-72HF 'V" packing used as Secondary seals respectively. Special notches enhance the required driving torque & hence the seal is Independent of direction of rotation. Owing to the support of sound infrastructure and dedicated workforce, we are able to manufacture, export and wholesale Single Coil Spring Unbalance Seal. Applications : Materials : Seal Faces                 : Carbon/TC/Sic. Vs Ceramic/RB Sic./TcSecondary Seals       : Viton/PTFE/GFTMetal Components  : SS-316

• Speed: 23 m/s
• Pressure: 10 bar (max)
• Shaft Diameter: 35mm
• Seal Type: Single Coil Spring Seal
• Brand: LE-CON
• Temperature Range: -20 -200 DegreeC

• Specialities: Easy installation , Sturdiness, Rust proof

Supplier & Distributor of Single Coil Spring Balanced Seal. Our product range also comprises of Dry Running Agitator Seal, Multi Spring Unbalanced Seal and Spring Unbalanced Seal.   Item Code: LS25   Type LS25: are single coil balanced mechanical seals, reliable & rugged enough for variety of applications. Designated as LS25 & LS26 for 'O' Ring & PTFE wedge type Secondary Seals respectively. The balanced & unbalanced version can just be obtained by simply changing the carbon face assembled through circlip provided. Non-clogging spring design enables these seals to be reliably used in situations involving abrasive, corrosive and viscous media. generally handled by high-pressure pumps.   Applications :Used in high pressure pumps, refineries, fertilizers, nuclear plants & petroleum products.Material :•   Seal Faces : Carbon Vs Sic./TC•   Secondary Seals :Viton/PTFE/GFf•   Metal Components : SS-316Operating Limits :•   Shaft Dia : 10 to 150mm•   Pressure : up to 30 Bars•   Temp. : -50 to 180°C•   Speed : up to 15 m/s

• Velocity: 10-15m/s
• Faces: Carbon /Ceramic / Sic. / Tungsten Carbide
• Secondary Seals: Viton / PTFE / FEP / GFT
• Hardware: SS316 / HAST-C / ALLOY-20/td>
• Shaft Dia: 12…..100mm 0.5"…..4.0"
• Pressure: 25bar (max)
• Temprature: -20 TO 180'C

• Size: 18 mm to 100 mm

 Single Spring» Rugged design» Bi-directional   Applications: Moderate slurries and chemicals. This is simple yet rugged, pusher type seal. Its design compensates for minor misalignment. Torque transmitting drive lugs make the seal bi-directional and also avoid spring distortion.

We are one of the prominent Manufacturers and Suppliers of Single Coil Spring Mechanical Seals. The Single Coil Spring Mechanical Seals are perfect to handle vibration, axial play, mis-alignment and thermal expansion. The Single Coil Spring Mechanical Seals are compactly designed which helps in efficient handling of solid particles such as corrosive, abrasive and viscous fluids which are handled by agitators, pumps, compressors, mixers, etc. The Single Coil Spring Mechanical Seals are sturdy, easy to install and unaffected by the direction of Shaft Rotation. Operating Limits Shaft diameter : 1/2" to 4"Pressure : 10 barSpeed : 6500 rpmTemperature : -50oC to +250oCFace Material : TC, Silicon Carbide, Carbon

Series 25J are single coil spring elastomer bellow seals , being designed for general sealing purpose including easy installation of the seal. These seals have a unique rubber bellow secondary seal.
