Turbo Separator Dealers

• Size available: T-300/400/500/600/800.
• Operating Consistency: 1.5% to 3%.
• Screen size: 1.8mm to 2.8mm perforation.

Principle : The equipment consists of a conical shaped body fabricated from MS plate and internally cladded with SS 304 one operating door. The door is provided with one light rejects. A tangential inlet nozzle is given on the main body for the pulp inflow. In accept chamber is attached to the main body for the collection of accepted pulp. This chamber is provided with a nozzle at the top for getting the accepted pulp and another nozzle at the bottom for cleaning purpose. In between the accepted chamber and main body a screen made from SS 304 material is provided. The overall functioning of the equipment is done by a SS 410 / CA 40 casted rotor. The accept is collected in the accept chamber whereas the light rejects are taken in the secondary screen for fibre recovery. The shaft is mounted on 2 bearings in a CI bearing housing. A stuffing box arrangement having GM bushes and gland is provided for the proper guiding and sealing of the shaft. The equipment is driven by an electric motor through flat belt pulley. Features : Operating consistency at 2-3% Light and heavy impurities are separated and efficiently removed. Due to high deflaking action the screen is ideally suited to kraft and other type of furnish. Easy maintenance and minimum fiber loss. The body is made out of M.S. with S.S. Cladding, Special model is also available in S.S. 316 sandwich plate (S.S. and M.S.) with base frame and stifners in M.S.

We are engaged in offering Turbo Separator, which is widely used in paper production industry. It automatically separates unwanted materials from waste pulp like water resistance particles. This machinery is equipped with advanced features and provides standard quality performance. Turbo separator is highly durable, sturdy and available at affordable prices.

* Effective Separation of heavy & light material (Metal pieces, Pins, Plastics) from pulp. * Easy maintenance and minimum fiber loss. * The body is made out of mild steel with S.S. cladding. Special model is also available in S.S. 316 Sandwitch plate (S.S. and M.S.) with base frame and stifners in M.S. * A cyclone effect is formed in the separator by the S.S. Rotor, So heavy particle are carried outward by centrifugal force to the junk trap. The light rejection is further treated in secondary separator or vibrating screen.

• Features: High Quality , Corrosion resistant , Smooth Finish .

• Material: MS / SS
• Item Code: T-300
• Type Of Machine: TURBO SEPARATOR
• Model Name/Number: T-300R
• Capacity: 7.5-10T

• Capacity Tons/ Day: 30-40,10-30,8-10
• Motor Rating KW: 45-55,22-30,7.5-12

Effective separation of heavy and light impurities. Low fibre loss The body is made out of mild steel with and option of internal ling of stainless steel. The rotor and screen (2-4 mm perforation) are made of stainless steel. A forced vortex is formed in the turbo by the rotor. Heavy contraries are carried outwards by centrifugal force into the junk trap while light contraries get collected in the centre which travels out through the light reject nozzle. The accepted stock passes through the screen fitted behind the rotor.

Effective Separation of heavy & light material (Metal pieces, Pins, Plastics) from pulp.Easy maintenance and minimum fiber loss.The body is made out of mild steel with S.S. cladding. Special model is also available in S.S. 316 Sandwitch plate (S.S. and M.S.) with base frame and stifners in M.S.A cyclone effect is formed in the separator by the S.S. Rotor, So heavy particle are carried outward by centrifugal force to the junk trap. The light rejection is further treated in secondary separator or vibrating screen.

  Effective Separation of heavy & light material (Metal pieces, Pins, Plastics) from pulp. Easy maintenance and minimum fiber loss. The body is made out of mild steel with S.S. cladding. Special model is also available in S.S. 316 Sandwitch plate (S.S. and M.S.) with base frame and stifners in M.S. A cyclone effect is formed in the separator by the S.S. Rotor, So heavy particle are carried outward by centrifugal force to the junk trap. The light rejection is further treated in secondary separator or vibrating screen.

Turbo Separator is a disc screen specially designed for coarse screening of primarily for pulp strainer with a high trash and flake consent like recycled paper Most suitable in screening of pulp slurries with high trash and flake content. Can be used as a secondary screen with a cylindrical screen in the first stage. Higher deflaking potential and ensures reliable operation. Online contaminants removal of both light and heavy rejects separately.

Since our foundation, we are successfully manufacturing and supplying an excellent assortment of Turbo Separator. As per current industry standards, these separators are assembled under the guidance of our professionals by utilizing optimum quality components at well equipped production unit. Furthermore, this Turbo Separator is made available in different specifications at reasonable price.

We are an experienced turbo separator manufacturer in India. We offer a broad range of turbo separator at very reasonable prices. Our range comprises of supreme quality turbo pulp separator, turbo oil separator etc.

• Size of the drill screen: 1.8 mm to 2.8 mm
• Inlet pressure: 3-3.5 kg/cm2
• Operating consistency: 1.5% to 3 %

• Brand Name: UMAC
• Material: Principal component of Stainless Steel
• Model: TS-400,600 800,900,1200
• Capacity: 20 TO 120 TPD

• Material: Cast Iron
• Brand Name: Ambica Paper Machineries
• Country of Origin: Made in India
• Voltage: 220 V
• Capacity: 70 Ton/Day
• Diameter: 1300 mm

The Turbo Separator uses centrifugal forces to stratify the stock into three regions, heavy rejects, light rejects and acceptable materials (accepts/fibres). Heavy rejects are forced against the outside wall, light rejects remain in the centre, and acceptable materials (accepts/fibres) migrate to the region in between. Heavy rejects exit the Turbo Separator via a tangential pipe at the top of the machine. This enables them to exit at high pressure. No pump is needed to move them to the High/medium/low Density Cleaner (Secondary fibre recovery device). Light rejects exit.     Features Course cleaning Screening of pulp slurries with flake content and high trashes Removal of heavy and light reject

• Capacity: 400-500 Ton/day
• Features: Precisely designed, Corrosion resistance, Sturdiness
