Universal Testing Machine Dealers in Kabnur, Kolhapur (38 products available)

We are Manufacturer, Supplier, Exporter of all our product range and our setup is situated in Kolhapur ( Maharashtra, India ) Features Motorized Control Valve. Load accuracy as high + 1%. Straining at variable speeds to suit a wide range of materials. Printer & PC graphs enable study the behavior of the material. Motor driven threaded columns for quick effortless adjustment of middle crosshead to facilitate rapid fixing of test specimen. Simplicity in reading because of digital readouts. Wide range of standard and special accessories. Easy change from plain to threaded and screwed specimens. Large effective clearance between columns enables testing of standard specimens as well structures. Simple controls for ease of operation. Robust straining frame of an extremely rigid construction. Fully enclosed and protected pressure transducer. RS 232 serial port for PC control of m/c.     Application ARUN Universal Testing Machine is designed for testing materials and other materials under tension, compression bending, transverse and shear loads.  Principal of Operation Here UTM Right Control Valve is Servo Controlled in close loop mode as per mode selection. Following control modes available : Standard Manual Control Potentiometric Control Load Rate Control Elongation Rate Control Load Hold Mode Strain Rate Control Also Auto Start, Potentiometric start & Initial Valve open start options are available for test to take care of slippage & different specimen types.Load is applied by hydrostatically lubricated ram. Main cylinder pressure is transmitted to the pressure transducer housed in the control panel. The transducer gives the signal to the electronic display unit, corresponding to the load exerted by the main ram. Simultaneously the digital encoder fitted on the straining unit gives the mechanical displacement. Machine Consists of Straining Unit This consists of a hydraulic cylinder motor with chain and sprocket drive and a table coupled with the ram of the hydraulic cylinder, mounted on to a robust base. The cylinder and the ram are individually lapped to eliminate friction. The upper cross-head is rigidly fixed to the table by two straight columns. The lower cross-head is connected to two screwed columns which are driven by a motor. Axial loading of the ram is ensured be reveling the cylinder and ram of of any possible side loading by the provision of ball seating’s.An elongation scale with a minimum graduation of 1 mm is provided to measure the deformation of the specimen. Tension test is conducted by gripping the test specimen between the upper and lower cross-heads, Compression, transverse, bending, shear and hardness tests are conducted between the lower cross head and the table. The lower cross-head can be raised or lowered rapidly by operating the screwed columns thus facilitating ease of fixing of the test specimen. Control Panel The control Panel consists of a power pack complete with drive motor and an oil tank, control valves a pendulum dynamometer a load indicator system and an autographic recorder. Software Windows based basic software for Servo Control is in standard scope of supply Real Time graph, User friendly software. Extensive graphics on screen for curve plotting, magnification and zooming. Software features include Graph comparison, point tracing facility. Different units selection for load & displacement. Statistical evaluation with water fall dig., Mean deviation, frequency distribution, Skew dig., Histogram. Also calculates max. Value, min.value, Mean Value, Variance, Standard Deviation. (Other statistical parameters on request). Selectable batch & statistical printouts. Evaluation of wide range of user selectable parameters such as % elongation, % reduction in area, young's modulus, yield stress, proof stress etc. Optional Software packages for Extensometer, Shear Bend, Torsion, Rubber, Textile testing etc. Power Pack The power pack generates the maximum pressure of 200 kgf/cm2 the hydraulic pump provides continuously non-pulsating oil flow. Hence the load application is very smooth. Hydraulic Controls Hand operates wheels are used to control the flow to and from the hydraulic cylinder. The regulation of oil flow is infinitely variable incorporated in the hydraulic system is a regulating valve which maintains a practically constant rate of piston movement. Control by this valve allows extensometer readings to be taken. Load Indicator System This system consists of a large dial and a pointer. A dummy pointer is provided to register the maximum load reached during the test. Different measuring ranges can be selected by operating the range selection knob. An overload trip switch is incorporated which automatically cuts out the pump motor when the load range in use is exceeded Accuracy & Calibration AII ARUN Universal Testing Machines are closely controlled for sensitivity, accuracy and calibration during every stage of manufacture. Every machine is then calibrated over each of its measuring ranges in accordance with the procedure laid down in BS : 1610 : Part 1 :1992 and IS 1828 : (Part 1) : 1991.ARUN Universal Testing Machines comply with Grade "A" of BS: 1610: Part 1:1992 and class 1 of IS 1828: (Part1): 1991 An accuracy of + 1.0% is guaranteed from 20% from 20% of the load range selected to full load. Below 20% of the selected range, the maximum permissible error is 0.2% of the full load reading.

• Type: 6 Pillar
• Color: Grey
• Condition: New
• Application: Testing
• Automatic Grade: Automatic, Semi Automatic
• Warranty: 1 Year

• Brand Name: ARUN MAKE
• Size: 10 ton TO 200 ton
• Model Number: AI-UTE

Arun electronic universal testing machine is designed for testing metals and other materials under tension, compression bending, transverse and shear loads. Hardness test on metals can also conducted. All arun electronic universal testing machines are closely controlled for sensitivity, accuracy and calibartion during every stage of manufacture. Every machine is then calibrated over each of its measuring ranges in accordance with the procedure laid down in british standards. 1610 : part1 : 1992 and is : 1828 : part1 : 1991. Arun electronic universal testing machine comply with grade "a" of bs : 1610 : part1 : 1992 and class 1 of is-1828-part-1:1991. An accuracy of +1% is guaranted from 2% to 100% of the capacity of the machine. Below 20% of the selected range, the maximum permissible error is 0.2% of the full load reading. Features : • loading accuracy as high as + 1%. • straining at variable speeds to suit a wide range of materials. • printer & pc graphs enable study the behavior of the materials. • motor driven threaded columns for quick effortless adjustment of middle crosshead to facilitate rapid fixing of test specimen. • continuous roll autographic recorder supplied as standard to enable study of the behavior of materials • simplicity in reading because of digital readouts. • wide range of standard and special accessories, including load stabilizer. • easy change from plain to threaded and screwed specimens. • large effective clearance between columns enables testing of standard specimens as well as structures. • simple controls for easy of operation. • robust straining frame of an extremely rigid construction. • safe operation ensured be means of safety devices. • fully enclosed and protected pressure transducer. • rs 232 serial port to transfer data to computer for analysisstorage evaluation etc. • manual control & release valve operation.

• Weight: 120 Kg
• Application: Loading
• Condition: New
• Machine Type: Automatic Front Load
• Power: Electric

MTMS Make Front Loading Universal Testing Machine is designed for testing metals and other materials under tension, compression bending, transverse and shear loads. Hardness test on metals can also be conducted.Principal of Operation : Operation of the machines is by hydraulic transmission of load from the test specimen to a separately housed load indicator. The hydraulic system is ideal since it replaces transmission of load through levers and knife edges, which are prone to wear and damage due to shock on rupture of test pieces. Load is applied by a hydrostatically lubricated ram. Main cylinder pressure is transmitted to the cylinder of the pendulum dynamometer system housed in the control panel. The cylinder of the dynamometer is also of self-lubricating design. The load transmitted to the cylinder of the dynamometer is transferred through a lever system to a pendulum. Displacement of the pendulum actuates the rack and pinion mechanism which operates the load indicator pointer and the autographic recorder. The deflection of the pendulum represent the absolute load applied on the test specimen. Return movement of the pendulum is effectively damped to absorb energy in the event of sudden breakage of a specimen.Salient Features Front loading crossheds with easy grips charging Hydrolic Gripsing Servo control for load/strain rate control Manual as well as computer control Most simple and Easy to use Able display force value and changed sharp value Confirms BIS 1825-1991 and ISO -7500--1986 Able proceed tensile, compression force, peeling, tearing testing Auto Load Selector Loading Accuracy as high as ±1% Straining at variable speeds to suit a wide range of materials Wide range of standard and special accessories, including load stabilizer Fully enclosed and protected pendulum Large effective clearance between columns enables testing of standards specimens as well as structures

• Capacity: 80-400 KN
• Usage/Application: Industrial
• Automation Grade: Semi-Automatic
• Power: 2.3 Hp
• Clamping For Round: 10-25 mm
• Specimens Diameters: 25-40 mm
• Clamping Jaws For Flat: 0-15 mm
• Width: 65 mm

The company has come up as a highly acclaimed Manufacturer, Exporter & Supplier of Mechanical Universal Testing Machine. The high quality Mechanical Universal Testing Machine is designed to perfection and is based on the client specifications. The accurate functioning of the Mechanical Universal Testing Machines, as well as their versatility, has made them popular across the globe. Application : Performs tensile, compression, bending and shear tests on metal & other materials, both in the form of test pieces and as finished products Features Continuous roll auto graphic recorder supplied as standard to enable study of the behavior of materialsHigh reading accuracy due to large size and design of dialEasy change from plain to threaded and screwed specimensRobust Straining frame of an extremely rigid constructionMotor driven threaded columns for quick effortless adjustment of lower cross head to facilitate rapid fixing of test specimenSimple controls for ease of operationSafe operation ensured by means of safety devicesFully enclosed & protected pendulumLoading accuracy as high as + 1 %Wide range of standard and special accessories, including load stabilizerLarge effective clearance between columns enables testing of standard specimens as well as structures Principle of Operation Operation of the machine is by hydraulic transmission of load from test specimen to a separately housed load indicator. The hydraulic system is ideal since it replaces transmission of load through levers & knife edges, which are prone to wear & damage due to shock onrupture of test pieces. Load is applied by a hydrostatically lubricated ram. The oil pressure in the main cylinder is transmitted to the cylinder of the pendulum dynamometer system housed in the control panel. The dynamometer piston exerts a force proportionate to the hydraulic pressure. This force is transferred through a leverage system to a pendulum. Displacement of pendulum actuates the rack and pinion mechanism which operates the load indicating pointer. Return movement of pendulum is effectively damped to absorb energy in the event of sudden breakage of specimen.

• Type: Testing Machine
• Certification: CE Certified
• Weight: 1-5 Ton
• Color: Blue
• Voltage: 220V
• Application: Testing
• Automatic Grade: Automatic
• Power: 1-3kw, 10-15kw, 15-20kw
• Warranty: 1 Year

We are proud to offer superior quality Universal Testing Machines that are made in accordance with stringent international standards. The extra ordinary testing capacity of our testing machine makes us the best universal testing machine manufacturers and suppliers from Ichalkaranji, Maharashtra. Attributes Made from superior quality raw materials Exceptional quality High testing capacity Applications Engineering firms Construction industry Oil & Gas sector Model : SKI - UTM 10, SKI - UTM 20, SKI - UTM 40, SKI - UTM 60 & SKI - UTM 100

• Capacity: 100 kN - 2000 kN

universal-testing-machine Mechanical, Electronic & Computerized versions available. Capable of tensile, compression, bend & shear tests. Windows Based Click and Go Software Package. Supports Tensile, Compression, Bending and many more Tests. Compensated for main screw clearances and frame stiffness. Extensive Database support.

Known for saving time as well as labor, Electronic Universal Testing Machine, we offer, is greatly demanded in the global market. The Electronic Universal Testing Machine manufactured by us efficiently tests both test pieces as well as final products. The Electronic Universal Testing Machine offered by us delivers accurate results, due to which it is suitable for varied testing requirements of different industries. Our Electronic Universal Testing Machine Is Used For Testing BendingShear testsCompressionTensile strength Our Electronic Universal Testing Machine Is Demanded By Engineering industryAutomobile industryPharmaceutical industryLaboratory and foundries

• Loading accuracy as high as + 1%.• Straining at variable speeds to suit a wide range of materials.• Printer & PC graphs enable study the behavior of the materials.• Motor driven threaded columns for quick effortless adjustment of middle crosshead to facilitate rapid fixing   of test specimen.• Continuous roll autographic recorder supplied as standard to enable study of the behavior of  materials• Simplicity in reading because of digital readouts.• Wide range of standard and special accessories, including load stabilizer.• Easy change from plain to threaded and screwed specimens.• Large effective clearance between columns enables testing of standard specimens as well as structures.• Simple controls for easy of operation.• Robust straining frame of an extremely rigid construction.• Safe operation ensured be means of safety devices.• Fully enclosed and protected pressure transducer.  • RS 232 serial port to transfer data to computer for analysis/storage evaluation etc. • Manual control & release valve operation.   Application :   FIE Electronic Universal Testing Machine is designed for testing metals and other materials under tension, compression bending, transverse and shear loads. Hardness test on metals can also conducted. 0   Principal of Operation : Operation of the machine is by hydraulic transmission of load from the test specimen through pressure transducer to a separately house load indicator. The system is ideal since it replaces transmission of load through levers and knife edges, which are prone to wear and damage due to shock on rupture of test pieces. Load is applied by a hydrostatically lubricated ram. Main cylinder pressure is transmitted to the pressure transducer housed in the control panel. The transducer gives the signal to the electronic display unit corresponding to the load exerted by the main ram.Simultaneously the digital electronic fitted on the straining unit gives the mechanical displacement to the electronic display unit. Both the signals are processed by the microprocessor and load and displacement is displayed on the digital readouts simultaneously.

• Weight: 1-5 Ton
• Color: Green
• Voltage: 110V, 220V
• Automatic Grade: Automatic
• Power: 1-3kw, 10-15kw
• Warranty: 1 Year

Mechanical Universal Testing Machine is best suited for testing various products such as Elastomers, Polymers, Plastics, Paper Plywood, Lather Fabrics, Aluminum / Copper conductors, Metal wires/flats and a host of other materials in conformation to testing standards laid down as per BIS, ISO, DIN,ASTM or BSS. Traverse speeds in the range of 25mm/min to 500 mm/min are available with our Mechanical Universal Testing Machine through drive pulleys, while, special traverse speeds can be offered on request. KE Tensile Testing Machines are guaranteed to an accuracy of +/-1% from +/- 10% of the load range selected to full load. Further adding, we are a proficient Manufacturer, Exporter and Supplier of Mechanical Universal Testing Machine all over the world. Grips / Accessories All machines are supplied with one set of standard holding Grips. Depending upon the type of materials to be tested, customers can request for additional appropriate accessories. To test samples like Cloth, Leather, Wires, Ribbon, Synthetic materials, etc., a variety of Holding Grips & Fixtures can be supplied on request, at extra price. Standard Features Accuracy +/-1% Simple operational 3 range dial Strip chart records for load vs. elongation various traverse speeds no foundation required

Fast, hassle-free setting of test specimens is guaranteed by the innovative designing of this Computerized Universal Testing Machine. Confirming to even the most rigorous of industrial standards, this Computerized Universal Testing Machine is easy to operate thanks to its user-friendly interface. We are a trusted Manufacturer, Exporter and Supplier of Computerized Universal Testing Machine. Details : Straining at variable speeds to suit a wide range of materialsLoading accuracy as high as + 1 %Motor driven threaded Columns for quick effortless adjustment of middle cross-head to facilitate rapid fixing of test specimenPrinter supplied as option to study the behavior of the materialWide range of standard and special accessories, including load stabilizeSimplicity in reading because of digital readoutsLarge effective clearance between columns enables testing of standard specimens as well as structuresEasy change from plain to threaded and screwed specimensSimple controls for ease of operationRobust straining frame of an extremely rigid constructionSafe operation ensured by means of safety devicesFully enclosed and protected pressure transducerConfirms to IS 1828Optional serial port to transfer data to computer for analysis / storage evaluation etc. Applications : Testing metals and other materials under tension, compression, bending, transverse and shear loadsHardness test on metals can also conducted

• Gauge Length: 25 mm & 50 mm
• Specimen Diameter: 0.5 to 30 mm

Mechatronic Control System is a prominent manufacturer of Universal Testing Machine which is available in electronic and computerized functioning. This machine is used to test the tensile and compressive properties of material. The reason Universal Testing machine is named so because it can perform all the tests right from compression, bending to tension and examine the material in all mechanical properties. We offer these in grade of 10T, 20T, 40T, 60T and 100T.

• Weight: 1000-10000kg
• Warranty: 1 Year
• Material: Metal
• Application: Industrial
• Durability: Long Life
• Surface Finishing: Polished
• Resistivity: Rust Resistant

We are offering our exclusive range of Universal Testing Machine (UTK 10 SE) at modest rates. Used in major industries, our Universal Testing Machine is appreciated for its unmatched quality, remarkable strength and quick performance.   Features : Specially designed for high accuracy and precision testing. Supports Tensile, Compression, Transverse, Shear and other similar tests. Available Load capacity 1, 2, 5, 10 Ton (100kN). Testing of various shapes of specimen. Available in Digital and/or Computerized control Panel. PC based software for capturing load Vs extension data. Extensive analysis with Yield, Proof and report.

Electro mechanical drive system for accuracy & high reliability. Digital Display for load and elongation. Design features enables high accuracy testing with economy, speed and versatility. Simple push button controls for ease of operation. Variety of tests-tension, compression, Bending Shear, Low Cycle Fatigue, Fracture. Displacement curve & processed data as certificate. Various models - Max capacity ranging from 1KN to100KN Loading accuracy well within +- 1% PC and Printer interface

Electro mechanical drive system for accuracy & high reliability. Digital Display for load and elongation. Design features enables high accuracy testing with economy, speed and versatility. Simple push button controls for ease of operation. Variety of tests-tension, compression, Bending Shear, Low Cycle Fatigue, Fracture. Displacement curve & processed data as certificate. Various models - Max capacity ranging from 1KN to100KN Loading accuracy well within +- 1% PC and Printer interface.

Computerized universal testing machine, SALIENT FEATURES Windows Based Click and Go Software Package. Supports Tensile, Compression, Bending and many more Tests. Confirms BIS 1825 - 1991 and ISO - 7500 - 1986 Standard Customer defined reports Compensated for main screw clearances and frame stiffness. Extensive Database support.

• Country of Origin: Made in India
• Capacity: 100 KN
• Voltage: 220 V
• Power Source: Electric
• Surface Treatment: Powder Coated
• Maximum Stroke: 300 mm
• Frequency: 50/60 Hz
• Displacement Resolution: 0.01mm
• Machine Type: Automatic
• Material: Mild Steel
• Brand: Aitawade Industries
• Phase: Single Phase

We are one of the well reckoned Universal Testing Machines Suppliers based in Maharashtra. The technologically advanced Universal Testing Machines provided by us has been termed as the best available in the market because of the following features. Attributes High Loading accuracy of ±1%Equipped with Training roll autographic recorderPrecise reading accuracy due to large design dialDifferent accessories for different applicationsLoading and unloading by motorized cycleEffective clearance between columnsSimple and easy to operateSafe operations backed by safety devices and mechanismEnclosed and protected pendulum Principle of Operations Hydraulic transmission of load from the test specimen to a separately housed load indicatorReplacement of transmission load; through levers and knife edgesLoad applications by a hydrostatically lubricated ramTransmission of Main cylinder pressure to the cylinder of the pendulum dynamometer system housed in the control panelSelf-lubricating design of Cylinder of the dynamometerThe load of the dynamometer is transferred through a leverage to the pendulumPendulum displacement actuates the rack and pinion mechanism which operates the load indicator pointer and the autographic recorderReturn Pendulum mechanism is effectively damped to absorb energy in the event of sudden breakage of the specimen Machine Consists of Straining UnitControl Panel Power PackHydraulic ControlsLoad Indicator SystemAutomatic Continuous Roll Load - Elongation RecorderMechanical Extensometer - To Measure elongation test specimen under load

• Brand Name: Testcraft
• Voltage: 240 V
• Material: MS
• Display Type: Digital
• Power Source: Electric
• Frequency: 50-60 Hz
• Surface Finishing: Color Coated
• Phase: Single Phase
• Is It Portable: Portable

We are one of the major Manufacturers, Exporters and Suppliers of Mechanical Universal Testing Machines in Ichalkaranji (India). The Mechanical Universal Testing Machines are widely used for the various tests on the metals and other materials like the tensile, compression, bending and shear tests. The test pieces as well as finished products can be tested by the means of Mechanical Universal Testing Machines. The Mechanical Universal Testing Machines transfers loads Highlights Of Mechanical Universal Testing Machines : Loading Accuracy: As high as + 1 %Designed for best man-machine interactionPrinter/plotter interfaceGlobally traceable pressure transducerµp/PC based optionVariable pace of training for suiting a wide range of materialsAuto graphic recorder with continuous roll as standard that enables material behavior studyThreaded columns driven by motor provide fast and effortless lower cross head adjustment and facilitate rapid fixing of sampleLarge size and dial design helps in highly accurate reading Easy change from plain to threaded and screwed specimensVarious standard and special accessories, including load stabilizerSamples and structures can be tested by the means of large effective clearance between the columnsSimple, safe and easy to use with safety devicesRobust constructionFully enclosed and protected pendulum Principle Of Operation : Operation of the machine is by hydraulic transmission of load from test specimen to a separately housed load indicator, which is better as compared to the use of levers and knife edges, since this limits the scope of wear and damage due to shock on the rupture of test pieces.Load is applied by a hydrostatically lubricated ram. The oil pressure in the main cylinder is transmitted to the cylinder of the pendulum dynamometer system housed in the control panelThe dynamometer piston exerts a force proportionate to the hydraulic pressure that is transferred to a pendulum by the leverage systemDisplacement of pendulum actuates the rack and pinion mechanism which operates the load indicating pointerIn case of sudden breakage of the sample, the return movement is effectively damped to absorb energy Parts Of Mechanical Universal Testing Machines : Straining Unit :Consists of a hydraulic cylinder and piston mounted on a robust baseLoading frame has an upper crosshead, middle crosshead and lower tableTwo plain hard chrome plated columns connect the upper crosshead and lower tableTwo hard chrome plated threaded columns to fit the middle crossheadReduction gear motor for driving the chain and sprockets that are present at the bottom of the threaded columns and provide height adjustmentIndividually lapped cylinder and ram to limit frictionAxially loaded ram ensured by the relieving the cylinderRam of any possible side loading by the provision of ball seatingElongation scale with least count of 1mm for measuring sample deformationTension test between the upper and middle crossheads by gripping the test specimen Other tests for compression, transverse, bending shear and hardness conducted between the middle crosshead and the lower tableControl Panel : Consists of a power pack that consists of a drive motor and oil tank as well as control valves, a pendulum dynamometer, a load indicator system and autographic recorder

Our company presents an assortment of Universal Testing Machines that are available at competitive prices

hardness testing machines, SAROJ make Rockwell Hardness Testing Machines
