Canary Electricals Pvt. Ltd. Moon Nagar, Morvi, Gujarat

we are offering oil cooled welding rectifier. vulcan diode type welding rectifiers oil cooled, smooth and step less output welding current control using state of the art transducting control technology, radically new design for great power saving operation compared to old and obsolete type machines of all other brand. excellent weld characteristic with all types of electrodes. this machine is very effective and useful in investment casting riser cutting besides all other heavy fabrication work. simple operation can work with long welding cable.

Brand Name : VULCAN

particulars units wr20td wr30td wr40td wr60td input supply volts 415 v, 3 phase, 50 hzs. ac open circuit voltage (ocv)(max.) v. dc 80 90 welding current range with low & high range selection amps. dc 30 - 200 30 - 300 40 - 400 60 - 600 max weldingcurrent @ 60% duty cycle amps. 200 300 400 600 rating kva 17 22 30 45 current regulation type amps. stepless (remote optional) insulation class h (copper wound) cooling forced air cooled max. dimensions (approx)(lxwxh) mm 870x510x895 940x605x940 1030x650x995 weight without remote (approx) kgs. 190 225 240 350 confirm to is – 4559 - 1993

Particulars units wr20th wr30th wr40th wr60th input supply volts 415 v Ⱡ10%, 3 phase, 50 hzs. Ac open circuit voltage (ocv)(max.) v. Dc 80 95 welding current range amps. Dc 10 - 200 10 - 300 10 - 400 10 - 600 max weldingcurrent @ 60% duty cycle amps. 200 300 400 600 rating kva 12 17 22 40 current regulation type amps. stepless (with remote) insulation class h (copper wound) cooling forced air cooled max. Dimensions (approx)(lxwxh) mm 790x310x690 945x380x770 970x460x830 weight (approx) kgs. 95 130 140 180 confirm to is � 4559 - 1993

We are offering step up transformers. Vulcan three phase voltage boosters are applied with an objective of using three phase power safely and property by increasing the voltage as needed in areas where low voltage is a chronically severe problem.

We are offering spot welding machines. vulcan pedal operated rocker arm type spot welding machines are offered in 6,8,10 and 15 kva models each with three standard throat depths to cover practically all applications.

We are offering portable welding machine. Modern looks, novel design concepts lightweight and compact-real portability for one person to do welding at odd places like civil work sites etc. Sturdy belt provided for carrying, hanging. Made from high-grade materials. Protection against overload by thermal cut-out. Works even on domestic power line. Reliable and durable. Epoxy powder coated body for long life. Coil varnishing by vacuum pressurized impregnating varnishing system.

Pneumatic operated spot-welding machines are offered in 20, 30, 50, & 75 KVA models. All machines are made of steel fabricated rigid structures eliminate the minutest spot deflection. Pneumatic spot welders are designed for high speed production jobs meet vast need of metal fabrication industries including sheet metal components, cross wire welding, kitchenware, electro brazing, resistance heating etc.

We are offering pneumatic spot welding machines. vulcan pneumatic operated spot-welding machines are offered in 20, 30, 50, & 75 kva models. All machines are made of steel fabricated rigid structures eliminate the minutest spot deflection. Pneumatic spot welders are designed for high speed production jobs meet vast need of metal fabrication industries including sheet metal components, cross wire welding, kitchenware, electro brazing, resistance heating etc.

Condition : New

Brand Name : VULCAN

Model Number : RM25

Place of Origin : Gujarat, India

Certification : ISO 9001 2008

'vulcan' regulator type mini welder medium duty machines in 150, 200, 250 amps., ratings are compact, light weight arc welders used for repair & maintenance jobs in medium duty cycles, light fabrication works, light production jobs in farms & small workshops, automobile garage & repair workshops. Yielding quite higher performance to cost ratio compared to any other machine in the market. Built with latest trends in design and manufacturing and tested to most stringent standards to offer years of trouble free service.

PARTICULARS UNITS RM 15 RM 20 RM 25 Input Supply Volts 230 / 415 Phase 1 or 2 Lines of 3 Phase Frequency Hzs. 50 Open Circuit Voltage (OCV) Volts 50 Insulation Class A or F Welding Current Range Amps. 45 - 150 50 - 200 50 - 250 Max. Continuous Hand Welding Current at 60% Duty Cycle Amps. 120 160 200 Welding Electrode Size Min. Max. MM MM 1.6 3.15 1.6 4 1.6 5 Cooling Natural Air Max. Dimensions (Approx) L - MM W- MM H-MM 510 385 520 520 435 560 Weight (Approx) Kgs. 45 55 65 Confirm To IS – 1851 - 1997

Particulars units vm25s vm40s vm60s input supply 415 v, 3 phase, 50/60 hzs. Ac open circuit voltage (ocv)(max.) volts 15 - 36 16 - 52 16 – 54 welding current range amps. 50 - 250 50 - 400 50 - 600 weldingcurrent @ 60% duty cycle amps. 250 400 600 welding current @100% duty cycle amps. 180 310 465 max input power @60% duty cycle kva 12 15 28 max input current @60% duty cycle amps. 12 20 35 recommended switch fuse rating kva tp - 20 tp - 25 tp - 45 number of voltage increment steps volts 16 30 insulation class h (copper wound) cooling forced air cooled max. Dimensions (approx)(lxwxh) m.m. 800x510x680 870x580x820 1130x550x780 weight (approx) kgs. 142 175 210 confirm to is - 7931 (part ii) - 1975

PARTICULARS UNITS RH30T RH40T Input Supply Volts 380 - 415 Phase 3 Phase Frequency Hzs. 50 Open Circuit Voltage (OCV) Volts 60 Insulation Class A or F Welding Current Range Amps. 300 400 Max. Continuous Hand Welding Current at 60% Duty Cycle Amps. 220 310 Cooling Natural Air (Optional = Forced Air Cool) Max. Dimensions (Approx) L- MM W-MM H-MM 860 540 760 Weight (Approx) Kgs. 145 170 Confirm To IS – 1851 - 1997

We are offering heavy duty stud type welding transformers etc.vulcan stud type heavy duty welding machines are reliable for dynamic output throughout the entire welding current range. Sturdy and proven construction to withstand extra-ordinary welding environment. extensively used for light and medium duty structural work, fabrication and machine building. Natural air-cooled design ensures non-stop performance even in the complex condition

We offer vulcan oil-cooled heavy duty regulator type arc welding machines. Particulars units rh30of rh40of rh608of input supply volts 380 - 415 phase 1 (2 lines of 3 phase supply) frequency hzs. 50 open circuit voltage (ocv) volts 60 80 insulation class f welding current range amps. 300 400 600 max. Continuous hand welding current at 60% duty cycle amps. 220 310 450 cooling oil cooled max. Dimensions (approx) l- mm w-mm h-mm 615 750 745 660 810 775 weight (approx) kgs. 127 140 162 confirm to is – 1851 - 1997

PARTICULARS UNITS RH30 RH40 RH508 RH608 Input Supply Volts Phase 1 (2 lines of 3 phase supply) Frequency Hzs. 50 Open Circuit Voltage (OCV) Volts 60* 80 Insulation Class A or F Welding Current Range Amps. 300 400 500 600 Max. Continuous Hand Welding Current at 60% Duty Cycle Amps. 220 310 375 450 Cooling Natural Air Max. Dimensions (Approx) L- MM W-MM H-MM 785 500 660 910 560 710 Weight (Approx) Kgs. 100 120 147 160 Confirm To IS – 1851 - 1997

PARTICULARS UNITS RH30OF RH40OF RH608OF Input Supply Volts 380 - 415 Phase 1 (2 lines of 3 phase supply) Frequency Hzs. 50 Open Circuit Voltage (OCV) Volts 60 80 Insulation Class F Welding Current Range Amps. 300 400 600 Max. Continuous Hand Welding Current at 60% Duty Cycle Amps. 220 310 450 Cooling Oil Cooled Max. Dimensions (Approx) L- MM W-MM H-MM 615 750 745 660 810 775 Weight (Approx) Kgs. 127 140 162 Confirm To IS – 1851 - 1997

PARTICULARS UNITS RH30FF RH40FF RH608FF Input Supply Volts 380 - 415 Phase 1 (2 lines of 3 phase supply) Frequency Hzs. 50 Open Circuit Voltage (OCV) Volts 60 80 Insulation Class F Welding Current Range Amps. 300 400 600 Max. Continuous Hand Welding Current at 60% Duty Cycle Amps. 220 310 450 Cooling Forced Air Cooled Max. Dimensions (Approx) L- MM W-MM H-MM 785 500 660 910 560 710 Weight (Approx) Kgs. 105 125 165 Confirm To IS – 1851 - 1997

We are offering electroplating rectifiers. Vulcan rectifier equipments cover wide variety of jobs ranging from all types of electroplating power sources. In addition to the latest standard type equipments in above fields of application. Some real marvels are also available in vulcan offering for the first time to achieve most excellent dc conversion, for example compared to types & makes (lowest ripple about 5%). Our extra low ripple (below 1%) high current unit for hard chrome plating helps to achieve best results.our all machine has yielding quite higher performance to cost ratio compared to any other machines in the market. Built with the latest trends in design and manufacturing, tested to the most stringent standards to offer years of trouble free service yet, awaiting your evaluation and approval of all virtues for your own applications.

"VULCAN" forced oil cooled, welding Rectifiers, Designed to provide DC welding current. They ore built using state of the art solid state technology and designed to meet the stringent demands of high quality welding from today�s fabrication industries including nuclear power plants, chemical process plants, offshore works, defense, steel plants, thermal power plants, mining and structural fabrications etc. Salient Features Real Vertical Characteristics.Stable Arc with easy droplet transfer.Hot Start' facilityElectronically Controlled �Antistick�Remote Control UnitProtection against H.F. Interference and Thermal run away.Superb Welding Performance.Reliable and Tropical Design. SpecificationsModelWR20THWR30THWR40THWR60THInput Supply415 Volts3 Phase, 50 Hz, AC415 Volts3 Phase, 50 Hz, AC415 Volts3 Phase, 50 Hz, AC415 Volts3 Phase, 50 Hz, ACOpen Circuit Voltage (Max.)80 Volts, DC80 Volts, DC95 Volts, DC95 Volts, DCWelding Current Range10-200 Amps. DC10-300 Amps. DC10-400 Amps. DC10-600 Amps. DCMax welding Current @60% Duty Cycle200 Amps300 Amps400 Amps600 AmpsRating (KVA)12 KVA17 KVA22 KVA40 KVACurrent Regulation TypeSteplessInsulationClass 'H'CoolingForced Air CooledDimension (L x W x H) (M.M.)790 x 310 x 690890 x 390 x 790890 x 390 x 790970 x 460 x 830Weight (Approx.)95 Kgs.130 Kgs.140 Kgs.180 Kgs. Note : Due to policy of continuous improvements, we reserve the right to modify the equipment and change specifications without prior notice.

We are Experienced Manufacturer, Exporter and Supplier of TIG Welding Machine & Inverter TIG cum ARC Welding Machine with the widest range and the best quality. Our product range also comprises of Inverter Based MMA Welding Machine, Inverter Based Arc Welding Machine. We are also provides TIG accessories and TIG Welding Equipments.Our inverter welding machines are based on fast switching IGBT Devices. IGBTs are advanced version of MOSFET’s. These machines are designed and developed in our company. We test all machines individually for under volt, over volt and performance. These machines are capable to withstand Indian power supply conditions and also works on gensets. Inverter is the name of technology, which is used for converting voltage and current levels up or down. It is replacement ofconventional line frequency transformers with advantage of power saving, better power factor, small & compact size, light weight and portability. Due to benefits of this technology more and more equipments are building better by adopting this technology.

We are offering Ac Tig Argon Welding Equipment. vulcan alternating current to weld aluminum, magnesium and rutile electrodes. Continuous regulation of welding current. Low spatter and high performance. Built in function for high quality tig welding. Down slope time control from smooth and perfect finish of welding. Inclusive hf unit high frequency generator for arc striking without contact. Gas pre/post flaw to eliminate contamination of the weld. included accessory : hf unit, gas regulator & flow meter, tig torch and dc suppressor unit.
