Fluid Bed Dryer Dealers in Mumbai

The purified air is heated by either steamelectricThermic Fluide. The hot air passes through the product container having diffuser plate and stainless steel sieve. Due to the hot air steam the wet product gets fluidized. The material gets surrounded by hot air and gets dried due to rapid transfer of heat. The moist air passes through the filter bag to the exhaust dust.

We bring forth a supreme quality Vibrated Fluid Bed Dryer (ADS-12) at competitive market price. Our Vibrated Fluid Bed Dryer is offered after conducting several quality control checks to maintain superior quality and is highly in demand in the international market.

CGMP  Fluid Bed Dryer with latest improved design makes this unit a truly versatile for Pharmaceutical, Food, Dyestuff, agriculture & Chemical industries. Our Fluid Bed Dryer is capable of drying materials in any forms like granular, powder or crystalline.Fluid Bed Dryers (FBD) are used to dry materials by fluidization with hot air, and that will create turbulence in the wet product while flowing through it. Normally an initial moisture content upto 20% is ideal but materials with higher initial moisture content can be dried successfully. Details : 2.5 kg to 500kg batch capacity. Available in cGMP and Non-GMP Model (MOC: SS316 / SS304 / M.S). Pre air filtration by 20 micron filters and secondary by 5 micron filters, Final air filtration through HEPA (0.3 micron) filters (Optional). Intrinsically safe earthing system ensures complete elimination of static charge. On-line Sampling Port for easy sampling during operation. Pneumatically operated inflatable seals provided for filter bag and product container sealing with pressure switches & FRL to ensure fail safe operation. Top mounted pneumatic cylinder (directly coupled) for shaking (without wire rope system). (Optional) II Heating mode Electrical / Steam & Thermic Fluid. Flameproof Motor with FLP Push Button and Flameproof Control Panel. (Optional)

A Fluid Bed Dryer is designed for fast and uniform drying of powders, crystals and medium sized pellets. The Fluid Bed Dryer finds application in Pharmaceuticals, Bulk Drugs, Dyes & Chemicals, Phyto-Chemicals, Catalysts, Food Products & Starch derivatives, Pesticides etc.

Being a blue-chip firm in this arena, we have set strong tie-ups with the leading e-commerce merchants who work for us and guarantee safe and secure transactions. Located in Mumbai(India), we ensure safe and secure deliveries, throughout the country, within the agreed time frame.   Features : Shrink resistance Elegant pattern

'RIDDHI' - introduces one of the finest "FLUID BED DRYER" unit providing compactness and conceptional principle of Air Fluidization for drying granules, crystalline, coarse or similar materials in Pharmaceuticals, Fine Chemicals, Dyes, Food & Allied Industries.   The basic concept of the Fluid Bed System begins with a simple Drying unit to which several different optional packages may be added for conversion to a granulation or coater.   Process control system ranges from standard pneumatic logic to sophisticated computerized controls. Air handling equipments can vary from the basic compact pre-filter and heater to the system, which provides complete control of the condition of the processing air. This higher technology of process involved many modern technologies and to match that RIDDHI introducing conventional Fluid Bed Dryer.   ADVANTAGES : The conventional drying method for drying products in tray dryers is rather inadequate & troublesome. They also occupy large space & have very high & uneven drying times and also involved high labour input. To over come this problem RIDDHI made Fluid Bed Dryer which is the simple solution to dry the products.   SUITABILITIES : This compact unit is suitable for drying granular, crystalline, coarse or similar materials in Pharmaceuticals, Dryer, Fine Chemicals & Food & Allied Industries. It is also possible to dry fine crystal or coarse materials in fluid bed dryers.   DESCRIPTION : Latest improvement in design makes this unit truly GMP model for Pharmaceuticals industries & versatile in operation for other industries like food, dyestuff, chemicals & polymer industry. In GMP models, all the contact parts made out of S.S.304 / 316 material & are provided with isolated panel board. However with standard Fluid Bed Dryers for product containers, retarding chamber are made out of stainless steel materials S.S. 304 only & other parts from mild steel sheet.   BATCH SIZE Batch size indicates weights of wet products (inclusive of moisture). Our Model RDFD-30 can take batch size of 30 to 40 Kgs. of wet material. Similarly model RDFD-120 can process 120 to 135 Kgs. of wet material per batch. The weight of materials to be loaded per batch depends upon the bulk density of wet material.   OPERATION : The wet material is introduced into the dryer as a batch of material in a product container which is provided with air distributor plate & clutch weave. Induced draught is created by the blower & fresh air is sucked into the unit. After filteration, clean air passes through the heating elements. This hot air then passes through the product containers, creating turbulance in the products & hence the product moves up and down known as Fluidization in the product container. Due to this process, the heat transfer is quick and the product is dried fast without appreciable loss of heat. Filter bags prevent particles escaping from the dryer.   HEATING: Fluid Bed Dryer can be supplied in electric heating, steam heating or hot water circulation systems or gas heating system on demand. Electrically heated dryers are provided with electrical heating elements and are suitable to raise air temperatures by about 750 C (i.e from 300 C to 750 C). Similarly steam operated dryers are provided with steam radiator suitable to raise air temperature about 600 C to 750 C depending upon pressure of steam. Generally dryers bigger than RDFD- 60 are incorporated with steam heating system as it is more economical.   DRYING TIME : The drying time depends upon various factors such as physical properties of material, moisture content, type of moisture (free moisture or water of crystallization), drying temperature etc. The crystalline products can be dried faster than amorphous product containing same percentage of moisture at the same temperature. Generally pharmaceutical granules or crystals containing free moisture of about 20% to 25% can be easily dried in about 30 to 40 minutes at a temperature of about 750C. Certain crystalline materials containing about 40% of moisture can be dried in Fluid Bed Dryer within 35 to 45 minutes.   IMPORTANT : In case the product contains solvents or inflammable substances, it is essential that the Dryer is steam operated &provided with flame proof motor.   Motor : The dryer will be provided with with suitable Remi/Hindustan/Sabar or standard ISI make motor of  2800 RPM   FILTERATION: Single stage filteration of  20 microns PP cloth filter,   P.P.  filter  bag   for   exhaust  air,  also multi stage filteration can be given on demand.    Positive  Earthing  Arrangement,  explosion flap  are given as a part of standard features.   Control Panel: Pre-wired control panel  indicate Digital Timer, Digital Temperature  Indicator cum controller(Inlet), Digital Temp. Indicator (Outlet), Sensor, Star-Delta Starter with relay, Indicating  Lamps,  MCBs, Amp.  Meter cum Volt  Meter, Selector switch  etc.                                                                                        SPECIAL  FEATURES : Uniformityindryingandreduction indryingtime. Atmosphericinletairisfilteredbymeansofsingle / multi stagefiltersof 20 microns toprevent anyfine dust to passthroughtheproduct. SteamCoilmadeoutof1”dia. SS 304/316finnedtube&isdesignedtogetpressureofaround3-4kg./cm^2(workingpressure 3 kg/cm^2). Digitaltemperatureindicatorscumcontroller isprovidedwiththeunittoindicate theinlet and outlet air temperature as well as to controllerthepresentinlet air temperature. Air suction and discharge dampers provided to control the inlet and outlet airflow. Anexplosionsafetyflapofadequatecapacityattherear endofthe dryerandanpositiveearthingpointtopreventstaticchargeinthemachine are provided. Timerprovidedtosettheprocesstimewhichwillcutoffthemotorsupplyafterpre-settimeperiod.   You  will  have  to  provide following : Levelflooratsite.   Requiredelectricalconnection up tothe machine throughsuitable isolatingswitch. Compressor with FRL to supply pure air to the Pneumatic components. Electrician at the time of Installation. Ducting from exhaust to the wall with fittings. Proper floor pan to be given at the time of ordering the machine. Steam boiler and all the connections, fittings and pipe, with controllers and pressure gauges to be connected to the radiator by party. 3 phase power supply upto the control panel of the machine. Inlet steam & outlet steam line with pressure gauge safety valve, by pass, On & Off Gate Valve provision to be made, electrical operated steam control valve 1 inch or ¾ inch BSP to be given. 4 sq.mm 6 core wire from panel Board to main motor. 1.5 sq. mm 2 core wire from panel Board to Pneumatic section. 0.5 mm 3 core wire from Panel Board to inlet & out let sensor.

  • Single piece construction- without flange joints.• Complete dryer have stainless steel construction with mirror polished   product contact surfaces.• Edges of all the parts rounded off and only butt welding carried out (by argon arc process).• Filters bag sealing arrangement by means of inflatable tube.• Interlocking between filter bag sealing tube and blower motor, and exhaust butterfly valve.• Product container lifting platform and air cylinder replaced by pneumatically operated gasket.• Rapid change of filter bag.• Built to suit GMP regulations

We are a famous Fluid Bed Dryer system manufacturer from India. Our industrial fluid bed dryers are easily available in different models including from 10, 30, 60,100,150, 200 and 250 Kgs. For the uniformity of dying, our fluid bed dryer is widely used. For the prevention of any kind of dust, our industrial fluid bed dryer is well-equipped with micro filters. Our industrial fluid bed dryers are widely used in pharmaceuticals, food products & starch derivatives, pesticides, phyto chemicals, dyes & chemicals etc. For the inlet as well as outlet air temperature, temperature indicator cum controller is also used. Product Code : 07 SALIENT FEATURES Models available in 10, 30, 60,100,150, 200, 250 Kgs. Capacities (Batch size).Uniformity in drying and reduction in drying time.Micro filters to prevent any fine dust to pass through the products with inlet air.An explosion safety flap of adequate capacity at the rear of dryer and an earthing point to prevent static charge in the machine.Timer provided to set process time.Temperature indicator cum controller for inlet and outlet air temperature.(In Electrically Heated Model only)Can be used in the fields of Pharmaceuticals, Bulk Drugs, Dyes & Chemicals, Food Products & Starch Derivatives, Pesticides, Phyto Chemicals, Catalysts etc.

Salient Features : Pre-air filtration by 20 micron filters. Secondary AIR Filtration by 5 micron filters Final air filtration through HEPA (0.3 micron) filters as an optional feature Air Dehumidification on special demand Monoblock Construction: Retarding chamber & expansion chamber are made in single piece construction to enhance cGMP  and facilitate hygienic cleaning Solid Flow Sensor Monitor: Dust monitor installation to detect Leak on Filter bags to avoid Material Loss and Air Pollution. Inlet / Outlet dampers have proportional control valve Proportional control temp controller Inlet / Exhaust Location: on service floor Wash in place Control: By PLC with MMI colour monitor with printer as optional Specially designed explosion flaps Pneumatically inflated gaskets for bowl sealing & finger bag Intrinsically safe system of earthing with low voltage Steam radiator in SS Construction Air preparation unit in SS 304 Pneumatic bag shaking

Fluid Bed Dryer is capable of drying materials in any forms like granular, powder or crystalline. Afluidized bed of solid particles with a stream of air passing up-ward through the particles at a rate great enough to set them in motion. As the air travels through the particle bed, the particles behave as boiled water. The active motion creates the potential for improved mixing and results an isothermal property. In a bubbling fluidized bed, no temperature gradient exists within the mass of the fluidized particles. Because the temperature and volume of the air can be precisely adjusted, the process achieves fast heat transfer making it very efficient,

DESCRIPTION Design as per stringent cGMP requirements. Uniform drying with electric/steam heating All contact parts SS 316 and non-contact parts SS 304 Inlet air handling unit with filter Auto shaking system for filter bag Pneumatic sealing for product container Option PLC control and processor

Voice Engineers is Static Fluid Bed Dryer Manufacturers. In Static fluid bed dryer, a specially designed perforated plate is used to keep the product in fluidization by upward moving velocity of air or gas. Fluidization occurs when the drag force of the upward moving gas equals or becomes more than the weight of the particle. Static Fluid Bed Dryer uses a heated gas to lift and maintain the feed in a fluidized state. Air is introduced into a wind box or plenum via a forced draft fan, and is distributed through a distributor plate of solid material via a perforated plate, nozzles, ceramic grid or other distribution medium. Voice Engineers the bed attains fluid-like properties flowing and mixing. The fluidization provides intimate contact between each material particle and the gas stream creating an extremely efficient transfer device. Products that have large particle size variations, or high bulk densities can benefit a vibrating bed by Static fluid bed dryer Manufacturers.   Mixing of product and drying media takes place High heat transfer and optimum physical reaction are achieved. By using different velocity of gas and air, particle classification is achieved. Higher operating temperatures are possible because of rapid heat and mass transfer rates Control of residence time makes possible to adjust moisture content of dried product. Because of no moving parts maintenance becomes negligible   APPLICATION : Drying, cooling or sterilization process for salts, polymers, chemicals & fertilizers and pharmaceuticals & food stuffs.

Static Bed Fluidized Bed Dryer is a very critical equipment where there is no moving part inside the Drying Chamber. The Salt is fluidized, each particle meets the hot air, discharges moisture, gets dry and at the same time travels forward without any mechanical push. It is meticulously handled by the balancing of the hot air through drying fan, cold air through cooling fan and exhaust air through exhaust fan. This balancing art requires very special skill in Design and Operation. We have proven-technology for designing dryers of any capacity. Since we have basic design knowledge of such dryers, we can offer the best services to our clients in case of difficulties during operation. In salt plants we suggest to go for SS 316L as MOC for such Dryers.
