Vibrating Machine Dealers in Roorkee (10 products available)

  • Vibrating Machine

    Vibrating Machine

    Vibration machine is used for the preparation of mortar cubes for the determination of compression strength of ordinary and rapid hardening portland cement, low heat portland cement, portland bleast furnace cement and high alumina cements. The machine consists of a vibrating frame assembly and an electric motor mounted on a sturdy base. The complete frame assembly consists of a vice to hold a 7.06cm cube mould and two studs threaded at top and a hopper to feed the sample in the mould. This assembly is supported on four springs and has an in built rotating shaft which rotates eccentrically and thus imparts vibrations to the entire frame.

    ...more
  • vibration test machine

    vibration test machine

    90,000 - 150,000 Per Piece

    Material : Stainless Steel

    Voltage : 220V

    Finishing : Polished

    Packaging Type : Carton Box

    Driven Type : Electric

    Operating Mode : Automatic

    ...more
  • Vibration Machine

    Vibration Machine

    Brand Name : Quality Engineering Corporation

    Place of Origin : Roorkee

    Frequency : 12000 A=400 vibration per minute

    Features : Easy to mantle and dismantle

    Speciality : Suitable for operation in 230 volts, 50 cycles & with single phase

    Owing to our in-depth industrial knowledge and state-of-the-art facility, we have been manufacturing Vibration Machines for buyers in the domestic markets. Our Vibration Machines are suitable for operation in 230 volts, 50 cycles and with single phase A.C. Supply. The cube and molds situated in the center of these machines are easy to mantle and dismantle. Also, we provide Vibration Machine with belt guard and time machine. We are a renowned Vibration Machine Manufacturer and Supplier from Uttarakhand, India. Buy them from us at reasonable prices. Details : Vibrator is mounted over coiled springs. Vibrations are by means of a revolving shaft with an eccentric. Centre of gravity of the vibrator, including the cube and mold is either at the center of the eccentric shaft or within 25 mm below it. Vibration Machine is supplied complete with one cube mold. Frequency : 12000 ± 400 vibration per minute

    ...more
  • Vibration Machine

    Vibration Machine

    1 Piece(s) (MOQ)

    Type : Vibration Testing Equipment

    Weight : 100-150kg

    Color : Brown

    Power : 1-3kw

    Driven Type : Electric

    Warranty : 1year

    We are offering vibration machine. 600 kgf to 1000 kgf electro-dynamic vibration test system.

    ...more
  • Vibrating Machine

    Vibrating Machine

    We offer Vibrating Machine. Vibrating Machine Since our establishment, we are engaged in offering optimal quality Vibrating Machine that conforms to 10080-1982. Especially designed to perfection, it consists of frame mounted on four coiled spring that helps to carry a cube mould and an eccentric revolving shaft mounted in ball and roller bearing. Ideal for the operation on 220V, 5Hz, single phase power supply, this has vibration frequency of 12000± 400 R.P.M. Per minute. Rugged construction, negligible maintenance, high operational fluency, excellent performance and longer working life are some of the salient features of the Vibrating Machine. ACCESSORIES : i) Flat Belts ii) Set of Springs. Iii) KEW Cube Mould 70.6MM (I.S.I. Marked) iv) Lubricant - 100cc. Our Vibrating Machines & Moulds conforms to 10080 - 1982. The machine is used for compaction of 70.6mm cube specimens of cement mortar under standard vibration required for determination of compressive strength of cement. The vibration machine consists of a frame mounted on four coiled springs to carry a cube mould and an eccentric revolving shaft mounted in ball and roller bearings. The machine is so balanced that the eccentric imparts simple harmonic motion to mould carrier and the mould. The frequency of vibration is 12000 ± 400 R.P.M. Per minute. The drive from the motor to the eccentric shaft is through an endless flat belt running on crowned pulleys. Suitable for operation on 220 V, 50 Hz, single phase power supply. Supplied complete with a time switch, one 70.6mm I.S.I. Marked cube. OUR Vibrating Machine Digital IS : 10080-1982 Same as above except that the machine is supplied with the digital timer.

    ...more
  • Vibrating Machine

    Vibrating Machine

    We are offering vibrating machine we bring forth in the markets precisely engineered vibrating machine. The experienced technocrats at work fabricate vibrating machine in conformation to the set industrial standards and norms. Efficient working, accurate working profile, longer service life and minimal maintenance best describe the quality of vibrating machines made available by us. about vibrating machine : concrete moulds are cast easily with the use of tamping bar or a vibrating table air tapped in cement mortar paste cannot be removed during the casting of cement mortar mouldsimparts maximum vibration of lesser amplitude to the mould during casting used to : prepare mortar cubes to determine compression strength of rapid and ordinary hardening :low heat portland cement portland cementhigh alumina cements portland blast furnace cement

    ...more
  • Shock Vibration Testing Machine

    Shock Vibration Testing Machine

    Color : Custom

    Brand Name : Pacific

    Frequency : 5-5000Hz

    ...more
  • Vibrating Machine

    Vibrating Machine

    Specification:- Vibrating machine consist of a vibrating frame assembly and an electric motor mounted on a sturdy base. The complete frame consist of a vice to hold a 7.06cm cube mould and two studs thread at the top and a hopper feed the sample in the mould.

    ...more
