4 MHz step frequency, 4 axes.
USB 2.0 connection.
100 Mbit Ethernet connection.
1 Status LED’s.
Full 3 axes interpolation.
24 Standard CNC outputs.
0-10V output for spindle conrol.
36 Standard CNC inputs.
Powered by +24V external.
Field upgradable firmware.
Runs on single core atom PC.
Features
Shortest possible CNC production time, especially 3D work, depending on the product, can be up to 2 times faster . This is thanks to the advanced Look Ahead Feed Algorithm that works for all motion segments, lines and circles by looking at their curvature and reduce speed only when absolutely necessary.
Simple one screen operation, UI designed for and by professional CNC operators.
Nesting mode execution for multiple production.
Optimized tooltip feed calculations for 4th axis milling, no tool breakage due to wrong tool-tip feed.
Feed Override control while running 0-150%.
Easy start half way in g-code file, using search method
Slave axes, for systems with dual motors (tandem) on X, Y or Z axis.
Special homing sequence for tandems, sets tandem straight.
Tangential knife, you need to program only X.Y coordinates and the tangential knife follows, also in circles and lifts automatically up when needed.
Backlash compensation.
Spindle proportional ramp-up time.
Collision detection when g-code job is loaded prevents machine damage.
Running time estimation when job is loaded.
Thread cutting (Lathe).
OpenGL graphics allows real-time PAN/ZOOM/ROTATE
Super long file mode allows endless files, tested with 100.000.000 lines g-code.
User interaction from G-Code with DlgMsg command and a lot more.
Automatic tool change can be programmed entirely in G-code.
Pause, Jog away, resume run in middle of g-code run.
Hand wheel jog with position and velocity mode.
Build in 2D CAM for drilling, engraving, profiling and pocketing, reads DXF .
PLC for customized Input/Output’s.
4 MHz step frequency, 4 axes.
USB 2.0 connection.
100 Mbit Ethernet connection.
1 Status LED’s.
Full 3 axes interpolation.
24 Standard CNC outputs.
0-10V output for spindle conrol.
36 Standard CNC inputs.
Powered by +24V external.
Field upgradable firmware.
Runs on single core atom PC.
Features
Shortest possible CNC production time, especially 3D work, depending on the product, can be up to 2 times faster . This is thanks to the advanced Look Ahead Feed Algorithm that works for all motion segments, lines and circles by looking at their curvature and reduce speed only when absolutely necessary.
Simple one screen operation, UI designed for and by professional CNC operators.
Nesting mode execution for multiple production.
Optimized tooltip feed calculations for 4th axis milling, no tool breakage due to wrong tool-tip feed.
Feed Override control while running 0-150%.
Easy start half way in g-code file, using search method
Slave axes, for systems with dual motors (tandem) on X, Y or Z axis.
Special homing sequence for tandems, sets tandem straight.
Tangential knife, you need to program only X.Y coordinates and the tangential knife follows, also in circles and lifts automatically up when needed.
Backlash compensation.
Spindle proportional ramp-up time.
Collision detection when g-code job is loaded prevents machine damage.
Running time estimation when job is loaded.
Thread cutting (Lathe).
OpenGL graphics allows real-time PAN/ZOOM/ROTATE
Super long file mode allows endless files, tested with 100.000.000 lines g-code.
User interaction from G-Code with DlgMsg command and a lot more.
Automatic tool change can be programmed entirely in G-code.
Pause, Jog away, resume run in middle of g-code run.
Hand wheel jog with position and velocity mode.
Build in 2D CAM for drilling, engraving, profiling and pocketing, reads DXF .
PLC for customized Input/Output’s.
Secondary Business TypeManufacturer / Exporters / Wholesale Suppliers
Opening Hours
SUN : Closed
MON : 9:30 AM - 6:30 PM
TUE : 9:30 AM - 6:30 PM
WED : 9:30 AM - 6:30 PM
THU : 9:30 AM - 6:30 PM
FRI : 9:30 AM - 6:30 PM
SAT : 9:30 AM - 6:30 PM
About us DeltonAutomation gives solution which is suited for many CNC applications. DeltonAutomation has 5+ years experience in motion hardware, software and motion applications. it is impossible to generate hick-free, high frequency stepper motor motion. To be able to do this, real-time behavior at micro-second level is required. So the product DeltonAutomation is designed from the ground up to work with an external CPU which takes care of this real-time behavior. The user interface of DeltonAutomation is designed with people that work with CNC machines every day. All machine operations can be done from one screen using functions keys, no mouse required. New functions will be added continuously. Also the hardware development is an ongoing process towards more functionality and higher speeds. We have two solutions regarding connection between the motion CPU and the PC; USB and Ethernet. We recommend Ethernet for industrial usage. Currently we are exploring seamless integration of manufacturing work-flows that are as simple to use for hobby systems and retain the simplicity even with the extended feature range for our professional customers. The ongoing development of back-end processes improves the functionality of existing hardware and thus our products continue to satisfy for a number of years.
