Industrial Pressure Gauge

Get Price Quote

• Scale Range0.. V acuum to 700 kg/cm2 & above on request
• Accuracy1%
• Thread Connection1/8″ , 1/4″, 3/8″, ½ ” BSP & NPT, M-10, M-12, M-20
• ApplicationChemical & Petrochemical, Plastic & Paper Pneumatic Control System, Air conditioning
• Nominal Size (mm)40,50,63,80,100,150 ,250
• Mounting of GaugeBottom, Surface, Back, Panel with 3 holes, Panel with bracket
• Case and BezelDrawn steel, SS 304
• Pressure ElementsBourdon Tube
• DiaphragmNil
• Wetted PartsBrass, SS 304 and other material on request
• OptionalLiquid Filled
• APPLICATIONS: With Liquid-filled case for applications with high dynamic pressure liquid media that ill. Pulsations or vibration suitable for corrosive environments and gaseous or not obstruct the pressure system.Process Industry: Chemical / Petrochemical, Pow er Station, Mining, on and off shone, environmental technology, mechanical engineering and plant construction.Features: Design : EN387-1,A gency Approvals : CEDial : 4” (100 mm.), 6” (150 mm.), 8” (200 mm.), white aluminum,Case : SS_304 or SS_316 (SS=Stainless Steel).Window : Plain Glass or Safety Glass.Pointer : Black aluminum, fixed or adjustable. Wid e selection of connections and pressure ranges. Crimped ring or bayonet bezel.Accuracy : 4”, 6”, & 8” : ± 1.0% (± 1.6% with filling)
