EIE Instruments Pvt Ltd Paldi, Ahmedabad, Gujarat

We are offering Salient Features · Double wall design · Single chamber for steam and water · Working chamber made of stainless steel LM - 304 grade having 2mm thickness. · Exterior Body is made of Mild steel LM, which is powder coated in attractive shades. · Lid, flange & bottom sheet also made of stainless steel. All joints argon welded. · Joint less silicon gasket · Heavy duty industrial flange heater. · Microprocessor based Digital Temperature Indicator cum Controller. · PID Controller Controls temperaturepressure precisely at set value. · Temperature Sensor : PT - 100 · Pressure range : 15 to 22 PSI, factory set at 15 PSI · Temperature Range : 121°C to 125 °C · Temperature Resolution : 0.1 °C · Temperature Accuracy : ± 0.5 °C · Working chamber size : 30 cm diameter x 50 cm height · Volume : 35 liters, rating 2 KW · Operates on : 230 Volt, 15 Amp, 50 Hz, Single Phase, AC Supply · In built digital timer; timer can be adjusted as per sterilization load requirement. · Lid fitting pressure gauge 0-30 PSI, safety spring loaded pressure valve. · Complete unit is Hydraulically tested at 60 PSI pressure. · Supplied with Calibration certificate with traceability · Complete with S.S. Perforated basket

Brand Name : EIE

Outline Dimension : As Per Machine

Discharge Way : As Per Machine

We are offering Construction Details : Inner-Door: Full view glass with aluminum frame Outer-Door: Of massive construction having seals against atmospheric infiltration by rubber gasket Shelves: Fabricated precisely to offer minimum resistance to air circulation Finished: With attractive and durable powder coated paint in pleasant shade Control Accessories : Circulation: Forced air circulation for uniform temperature by suction blower fitted with turbo F.H.P. Motor Front Panel: Mains rocker switch, Cooling Heating rocker switch, Micro - Controller, Ampere Meter, toggle switches for high & low position of heater fuse. Illumination: With fluorescent light when door opens Temperature Specifications : Range: 10 degree centigrade to 60 degree centigrade Accuracy: - 1 Degree centigrade or better Controller: Micro-Controller PID Type Display: Digital LED Sensor: Pt - 100 Humidity Specifications : Method: Steam injected humidity derived by RH Controller Range: 40% TO 95% Rh Accuracy: - 3 % Rh Heating Accessories : Tubular finned type heaters for dry temperature and relative Humidity Refrigeration : Compressor: Hermetically sealed of Kirlosker Make or equivalent Optional Attachments at additional costs Hygrometer for direct Rh indication Voltage stabilizer of suitable capacity Lux-Meter for photo stability Optional Wireless Communication Mode of controlling through PLC & HMI USB Cable for seamless integration between PC (Personal Computer) & Humidity oven Wireless communication with the help of RF Converter Online data logging and editting (User can log, modify, and control the data from any corner of the world)

Brand Name : EIE

Power : Electronic

Country of Origin : India

We are offering Salient features · CE Certified · Internal circuit wiring as per CE Norms · Working size : 45 x 45 x 45 cm ( H x W x D) · Volume : 92 Liters · No of Shelves : 02 Numbers · Ratings : 2.0 KW · Temperature range : 50 °C to 250 °C · Control accuracy : ± 1°C or better · Exterior body made of mild steel material, which is powder coated in attractive shades · Inner chamber is made of Stainless Steel S.S. 304 - mirror polished material. · 65mm high density Glass wool insulation on all sides to offer minimum chamber heat loss · Oven is fitted with heating elements on all three sides, ensuring uniform temperature distribution throughout the working chamber · Sealed and enclosed heaters to working chamber for minimum heat loss · Microprocessor based Auto tune - PID Digital temperature indicator cum controller · 8020 nichrome heating elements, ensuring long lasting and continuous heating within the chamber · Special heavy duty Stainless steel lock and door hinges with spring and roller mechanism · Stainless steel crimped wire mesh Shelves to withstand heavy load and to offer minimum resistance to air circulation for better heat distribution · Provision to add more shelves, as per requirement of test - Adjustable Shelves to place test samples or Glass wares of varying dimensions · Adjustable air ventilation mounted at top · Operation on 220230 Volt, 50 Hz, Single phase, AC Supply · With built-in forced air circulation arrangement for uniform heat distribution inside the working chamber · Complete with pilot indicating lamps, 2 meter cord wire and power plug.

Model Number : EIE - 101

Brand Name : EIE

Certification : CE Certificate

We are offering Automatic MICROPROCESSOR controlled Radial Locking System · With inner chamber and middle chamber & outer cover made of stainless steel. Fitted with industrial elements. Fitted with low water level cut-off, Microprocessor controlled, Fully automatic sterilizing operation with provision for programming temperature and Time ramps. Displays current temperature and set temperature with time remaining Microprocessor controller auto air purging and auto steam exhaust at the end of the cycle. The controller provide to just one button to cycle the unit from start to finish with alarm.

We are offering Compliance with following Intaernational Standards IS : 14858 - 2000 Introduction The digital compression testing machine has been designed to meet the need for a simple, economic and reliable means to test concrete for its compressive strength. The design expressive of simplicity, both of construction and operation, makes the machine easy to use and maintain. The digital machines are provided with a MANUAL pace rate controller, to enable maintain a constant rate of loading. The Complete unit comprises a Loading Unit which is of four pillar model construction, having a cross-head with a spherical seated platen. The lower platen is attached to the top of the piston. The Loading capacity is of 1500 KN, Cubes up to 200 mm & Cylinders up to 150 mm Diameter x 300 mm Height can be tested using the appropriate spacers. The pump facilitates rapid approach of the platens for daylight closure and also provides comprehensive control over the application of load. A control valve provides fine control over the loading rate for accurate pacing. Maximum load is held and retained for approximately 15 minutes, unless cancelled, using the panel mounted reset switch. Salient Features of EIE - Digital CTM Machine · 4 line Alphanumeric display with backlit, displaying - Actual Load, Peak load, Rate of loading and Calculated load in Nmm² · Direct reading of compressive strength in Nmm2 - No calculation required · Peak hold facility · Can manually control pace rate from 1 KNSec to 9 KNsec

Brand Name : EIE

Brand Name : EIE

Accuracy : Class 1 (EN) and Class A (ASTM)

Power Supply : AC 1 Phase 220V 60/50Hz

Power : Electronic

Display : Touch screen graphical display

Application : concrete cube compression testing

We are offering Applications B.O.D. Incubators are used to provide temperature conditions for Bio-Oxygen Demand test for cells tissue culture bacteria micro-organism culture application, raw material and bulk product storage, plasma and blood product storage, serum incubation, immunological studies and other applications in the field of research, development, production and quality control. EIE incubators are majorly used for Media Preparation & Culture growth at temperatures of 22.5°C (±2.5°C) & 32.5°C (± 2.5°C) in Microbiology or ARD labs across the world. Salient Features · Exterior boy is fabricated from Mild Steel material, which is powder coated in attractive shades. · Interior chamber is also fabricated from Mirror polished Stainless Steel S.S. - 304 Material · Outer double walled metal door with sponge - type silicon gasket for air-tight sealing as to avoid leakage of chamber uniformity · Electrical wiring as per CE Compliances - with individual numbering of each internal circuitry wire for ease of maintenance & Repairing · Chamber illumination is accomplished by Fluorescent light with door switch. · Cord wire duly tested and inspected with stress factor as per CE standard · Electric Motor of blower located at the back side of unit, which is protected with safety cover to avoid accident · Standard motor of reputed companies - such as CG, GODREJ or GE Make · User friendly and tactfully designed chamber door and locking mechanism · Aesthetic outer appearance and high quality · Unit mounted on castor wheels for easy movement. · Supplied complete with Stainless Steel Trays for sample placement · Supplied complete IQ, OQ, PQ, DQ Documentation and instruction manual. Technical Specifications · Construction : Double walled · Interior : S.S. - 304 Grade

Brand Name : EIE- 102

Application : Microbiology testing, tissue culture testing

Power Supply : 230 volts, 50 hz, single phase, AC Supply

Total Carbohydrate : 12 months

Country of Origin : India

We are offering Complete range of bitumen testing instruments as per following Marshall stability test apparatus Automatic marshall compactor Rolling thin film oven Rotational viscometer Skid resistance tester Ductility testing machine (Without refrigeration) Ductility testing machine with Refrigeration System Fully automatic penetrometer Low temperature waterbath Core drilling machine Mastic Asphalt Hardness Tester Flameproof bitumen extractor Planetary Mixer Petroleum distillation apparatus Distilllation apparatus as Muffle furnace Hot air oven - CE Marked Loss on heating test oven Softening point apparatus Saybolt viscometer Cleaveland flash and fire point apparatus Pensky marten flash point apparatus Benkleman Beam apparatus Density of semi solid bituminous material Marshall Rammer Ductility moulds Camber board Pycnometer bottle Aspirator pumps

We are offering This heat flow meter is a commercial apparatus for thermal conductivity (or thermal resistance) of insulation materials by guarded hot-plate. Specification GUARDED HOT PLATE :- Size : Metering area :- 150 x 150 mm Guard : 75 mm all around with a gap of 3mm between guard and central. Overall size : 310 mm Plate thickness : 4 mm (approx). Material : brass Max. Working temperature: 150°C No. of thermocouples : 2 each in central & Guard plate. (One for control & 3 for monitoring) Central plate: 4 thermocouples are mounted on Central Plate (two at upper and lower side at the center) i.e. total 4 thermocouples. Guard plate: 4 thermocouples are mounted on Central Plate (two at upper and lower side at the center) i.e. total 4 thermocouples. COLD PLATES :- Overall Size : 310 x 310 mm Thickness : 1 mm (approx) Material : copper. No. of thermocouples : 4 in plate.(One for control & another for monitoring) Maximum working temperature : -20°C. Specimen dimensions A single specimen is required. Thickness: 30 mm to 75 mm(The thickness is within 2% of its mean thickness over its whole area) Note: Thinner specimens can be measured, if it is the thickness that they will be supplied to the end user Length and breadth: 310*310 mm (Within range 305 mm to 311 mm) Flatness: The 310 mm square faces are flat to better than 0.2 mm (Flatness criteria do not apply to compressible or fibrous insulations) Thermal conductivity range: up to 0.5 Wm·K Mean specimen temperature range: -20 to 150 c Confirms as per IS:3346
