Fire Alarm Panel
Get Price Quote
SILITRONIX manufactures "Smoke Detection & Fire Alarm Systems / Panels" since 1985 as per IS 2189. Our Fire Alarm panels are approved by P & T, TAC, ETDC , ONGC, Bank like SBI e.t.c. Our Micro Controller Based Fire Alarm Panel is design to includes Latest Low Power consumption available Technology offering many features in Slim & most compact size. We also manufacture premium Modular type Fire Alarm Panel, which is made from premium quality materials and are available in wide range to cater to different fire safety needs of our clients. SILITRONIX Fire Detection & Alarm Panels can be Useful at many Public / Private Places where â Fire Protection â is required.
Technical Specifications Of Modular Fire Alarm Panel :
Input Supply :
230 V A.C. / 24 V D.C.
Modules :
Fire Alarm Panel Includes Different Types Of Plug in Modules, Performing Different
Operations :
Meters : Three Analogue Meters are Provided :A.C. Volt Meter , Showing Input Mains Supply.D.C. Volt Meter, Showing 24 V D.C. Feeding to Detector system.D.C. Ampere Meter , Showing Battery Charging Current in Ampere.
MCP : It Includes 24 V D.C. & 12 V D.C Regulated Power Supply & Automatic Battery Charger & Battery Backup Circuits.LCP : It Includes Inverter for Control Power Supply ±12 V D.C., Hooter Circuit, Fire Alarm LED Flasher Circuit, Silence / Reset Audio Alarm , Buzzer Fault Alarm etc.Dual Zone Card : Each Card includes / Represent Two individual Room / Hall / Area for FIRE & FAULT indications. Its circuit is Connected with series of Detectors of one Particular Area / Zone. It continuously watch Detector Signal. If it Finds some abnormal condition in Input Signal, it Indicates by different coloured LEDs glowing as Under.
Indications :
FIRE : Two Red LEDs Glow with Flashing ,Sending actuation Signal to Common Audio Buzzer & Hooter Alarm Circuit. Which also Field Hooters of that area which gets FIRE.FAULT : When Input Circuit Finds No signal from Detector, It In As a Open Circuit Glowing Green LED, Sending Signal To Audio / Buzzer Alarm. When Input Circuit Finds SHORT CIRCUIT signal from Detector, It Indicates As a SHORT Circuit, Glowing Yellow LED Sending Signal To Audio / Buzzer Alarm.ISOLATE : When any Zone / Area gets some Fault Signal, after Acknowledging it, till You Repair / rectify it, You can Isolate that effected Zone by Toggle Switch.
Switches :
On Each Zone Card , Test Switches are provided to Test / Stimulate the Health ness Of Total Systems in FIRE, OPEN, SHORT Conditions.SILITRONIX Also manufactures Slim & Most Compact Micro Controller Based Fire Detection & Alarm Panels for 1 zone 32 Zones in the Same Model.
Applications :
SILITRONIX Fire Detection & Alarm Panels can be Useful at many Public / Private Places where FIRE PROTECTION is required.
A Hotel to A GodownA Bank to A FactoryPower Station to A RefineryA Record Room to A LibraryA Computer Center to A Telephone ExchangeAnd Many Many other Public Dealing Buildings & Premises
Technical Specifications Of Micro Controller Based Fire Alarm Panel :
SILITRONIX Also manufactures Slim & Most Compact Micro Controller Based â Fire Detection & Alarm Systems â from 1 zone To 16 Zones in the Same Model using Scanning Multiplex Technology. Its brief technical details are as under.Digital Display : Our Fire Alarm System consist of two Digit Display.Zone No. Display : It is a Two digit display , showing Zone No. advancing 1 To 16.Fault Message Display : It is a four digit display showing Four types Of fault Messages for each Zone as â Fire â, â Open â, â Short â, â Good â.Key Board : Four Keys are provided for easy & friendly Operations.
Function Key : It is used to select four different Functions / Operations as
Selection of Maximum Zone Operation ranging 1 To 16 Nos.Time Delay between two Zone display ranging 2 To 9 Second.Scanning On / Hold selection. If Hold function is Selected , then select Zone No. which will Continuously showing that Selected Zone No. with Its Fault Status.By this, Buzzer Operation is selected â Continuously ON in case of any â Fault â in any Zone or Buzzer ON while that Faulty Zone No. display.
Up / Down Key :
By means of this Key operation , channel No., Time Delay etc can be change.
Enter Key :
By means of this key , any data / parameter which is selected is saved.
Buzzer Acknowledgement :
If any âFault â occurs in any of the Zone , Buzzer will ON. This Buzzer can be â Silent â by pressing this key.
LED Indications :
Four Arrays Of Different Coloured LEDs are provided for each Zone, showing Its fault status as under.Fire, Open, Short, Good.
Features :
SILITRONIX can cater Excellent & Intelligent features & Facility to a varied needs of valued Customers on demand.In case of some emergency / fire , automatic Telephone dialing system at selected number will be provided On demand.Computer Interface facility with data Logging System Using Serial data Communication â RS 485.Key Board â Password â facility will be provided on Demand for security purpose.SILITRONIX also manufactures other Fire / Emergency Alarm System Related Items as under.
Manual Emergency Alarm Panel :
It is a wall Mounting Type, Audio / Visual Manual Alarm systems. It actuates by Break Glass of Manual call Point keep at Each Wing of Floor. As soon as Break of any manual Call Point connected with Panel on any Floor, Dual Flashing â Fire / Emergency Alarm ON â LEDs Glow On Panel, with inbuilt Audio Hooter / Alarm ON. Also all External Hooters ON / Sounds Keep at Each Floor. Audio Alarm can be Silence / by Switch Operation. A Manual Test" Facility is also provided, Which actuates Alarm system with all Hooter ON.
Applications :
High Rise Buildings use as office Complex , Residence Complex, Multiplex Theaters, Shopping Mole etc.
Accessory :
SILITRONIX offers accessory useful with Fire Alarm Panels. Its brief descriptions are as under.
Hooters : It is a wall Mounting Type solid state Audio alarm System. There are
two types of Hooters available .
Speaker Based wall mounting type cabinet with inbuilt Electronic circuit. It Operates from 24 V D.C. with Vouling type Sound. It creates more than 60 DB Sound.Horn Based wall mounting type with Tilting Clamp, By which you can set the direction of Sound. Its Operating voltage is 15 V To 20 V D.C. It generates Vouling type Sound which can be listen far more than 100 Feets.Manual Call Point : It is a wall Mounting Type Break Glass Instrument. If its glass is break. It sends a signal to the panel to actuates a Alarm Circuit in the Panel & two Red Colour LEDs Glow on this Box.Response Indicator : It is a wall Mounting Device having Two LEDs. When It gets signal from Detector , this Two LEDs start to glow. It operates from 24 V D.C
...more
