RR CABLE Navrangpura, Ahmedabad, Gujarat

1.1 kV, 1 cores AL CU conductor, PVC insulated, unarmoured cables as per IS 1554 Part - 1.1.1 kV, 3 cores AL CU conductor, PVC insulated, unarmoured cables as per IS 1554 Part - 1.1 kV, 1 cores AL CU conductor, PVC insulated, unarmoured cables as per IS 1554 Part - 1.

About RR KABEL We take pride to be the first wire and cable company in India to have such a diverse and extensive range of products. We are one of the leading companies in electrical and copper industry & our journey to success as well as leadership has been complimented with a desire to adapt with new innovations and technology. We are accredited with 27 product licenses as well as 3 manufacturing certifications and, with a continuous pursuit of evolving technology, we are determined of achieving even greater success.

1.1 kV, 3 cores AL CU conductor, PVC insulated, unarmoured cables as per IS 1554 Part - 1.1.1 kV, 1 cores AL CU conductor, PVC insulated, unarmoured cables as per IS 1554 Part - 1.1.1 kV, 1 cores AL CU conductor, PVC insulated, unarmoured cables as per IS 1554 Part - 1.

We take pride to be the first wire and cable company in India to have such a diverse and extensive range of products. We are one of the leading companies in electrical and copper industry & our journey to success as well as leadership has been complimented with a des

The PVC insulated and sheathed 3 core flat cables are mainly used in pump connections. They are also used in many industrial applications. The sheath is specially made out to resist tough and difficult condition of usage, excellent resistant to water, conditionally resistant to water and grease. Specifications Approvals : IS 694 marked, FIATAC Conductor : Electrolytic grade annealed copper Core Colour : Red, yellow (centre core), blue Sheath Colour : Black Packing : Standard packing of 100 mtr. in coils. Longer length available on request.

Max. Permissible Ambient Temperature : +90°C (stationary and in motion ) Max. Permissible Operating Temperature of The Conductor : +120°C, Interpretation according to IEC 60216 : permanent temperature. 120°C for 20,000 h ( = 2.3 years ), at max. 90°C permanent temperature ( = 30 years ). Short – Circuit Temperature : +200°C (at the conductor max. 5 sec. ) Damp – Heat Test : According to EN 60068 – 2 – 78. 1,000h at 90°C and 85% humidity. Min. Permissible Ambient Temperature : -40°C (stationary and in motion) Resistance to Cold : Bending test at low temperature according to DIN EN 60811 – 1 – 4,

We take pride to be the first wire and cable company in India to have such a diverse and extensive range of products. We are one of the leading companies in electrical and copper industry & our journey to success as well as leadership has been complimented with a desire to adapt with new innovations and technology

1.1 kV, 1 cores AL CU conductor, PVC insulated, unarmoured cables as per IS 1554 Part - 1.1.1 kV, 1 cores AL CU conductor, PVC insulated, unarmoured cables as per IS 1554 Part - 1.1.1 kV, 1 cores AL CU conductor, PVC insulated, unarmoured cables as per IS 1554 Part - 1.

The cables are suitable for power and lighting circuits and building wiring suitable for use in semi flush exposed conduits, embedded conduits and in closed installation ducts. Standard BS EN 50525-2-31:2011. SABS 1507-2, SS 358 Part-3. Specifications Temperature Range : -15°C to 70°C Minimum Bending Radius Upto 10 mm2 : 3 X Overall Diameter. 16 & 25 mm2 : 4 X Overall Diameter. Above 25 mm2 : 5 X Overall Diameter.

.1 kV, 1 cores AL CU conductor, PVC insulated, unarmoured cables as per IS 1554 Part – 1. Conductor : AL up to 10 Sq. mm conductor are solid Cl.1 as per IS 8130. And above 10 Sq. mm conductor are stranded round or compact Cl. 2 as per IS 8130 In CU 4 & 6 Sq. mm conductor are solid Cl.1 or stranded Cl. 2 as per IS 8130. 10 Sq. mm & above stranded round or stranded compact Cl. 2 as per IS 8130 Insulation : PVC Type – A, as per IS 5831. (Option : HR PVC Type – C, as per IS 5831) Core Color : Red or yellow or blue or black or natural Outer Sheath : PVC Type ST-1 as per IS 5831. (Option : PVC Type – ST 2 as per IS 5831 FR Type FRLS Type ) Cable Color : Black (Options : Any other color as per requirement)

The PVC insulated and sheathed 3 core flat cables are mainly used in pump connections. They are also used in many industrial applications. The sheath is specially made out to resist tough and difficult condition of usage, excellent resistant to water, conditionally resistant to water and grease. Specifications Approvals : IS 694 marked, FIATAC Conductor : Electrolytic grade annealed copper Core Colour : Red, yellow (centre core), blue Sheath Colour : Black Packing : Standard packing of 100 mtr. in coils. Longer length available on request.

These cables are used in high rise buildings, commercial complexes, schools and educational institutions, hospitals, etc. for the connection with security systems like smoke detectors, emergency lightings, exit signboards and fire command center. These cables are used where the fire safety is utmost important.

Standard : Based on VDE 0812 Nominal Voltage : 0.14 mm² = 350 V; >= 0.25 mm² = 500 V Insulation Resistance : Min. 20 GΩ x cm Temperature Range : Flexing -5°C to +70°C. Fixed installation -30°C to +70°C Minimum Bending Radius : For flexible use 10 x cable ø Test Voltage : Up to 0.25 mm² = 1200 V. From 0.34 mm² = 2000 V Breakdown Voltage : Up to 0.25 mm² = 2400 V. From 0.34 mm² = 4000 V

We take pride to be the first wire and cable company in India to have such a diverse and extensive range of products. We are one of the leading companies in electrical and copper industry & our journey to success as well as leadership has been complimented with a desire to adapt with new innovations and technology. We are accredited with 27 product licenses as well as 3 manufacturing certifications and, with a continuous pursuit of evolving technology, we are determined of achieving even greater success.

These cables offer the advantages of an armoured 6001000V rated, zero halogen, low smoke cable with circuit integrity. They are intended for use in installations where vital circuits are required to continue operation in the event of the outbreak of fire. It is particularly suited for use in public buildings and constructions (such as hospitals, theatres, shopping developments, tunnels, mass transit railways, oil & petrochemical plants, power stations and computer installations) where the danger to life, equipment and structures may be greatly increased in the event of a power failure due to fire. Standard

Nominal Voltage : U U 300 500 V O Insulation Resistance : Min. 20 GΩ x cm Temperature Range : Flexing -5°C to +70°C. Fixed installation -30°C to +70°C Minimum Bending Radius : Flexing 20 x cable ø. Fixed installation 6 x cable ø Test Voltage : 4000V

Standard : Based on VDE 0812 Nominal Voltage : 0.14 mm² = 350 V; >= 0.25 mm² = 500 V Insulation Resistance : Min. 20 GΩ x cm Temperature Range : Flexing -5°C to +70°C. Fixed installation -30°C to +70°C Minimum Bending Radius : For flexible use 10 x cable ø Test Voltage : Up to 0.25 mm² = 1200 V. From 0.34 mm² = 2000 V Breakdown Voltage : Up to 0.25 mm² = 2400 V. From 0.34 mm² = 4000 V

CTV cables are designed to optimize the quality of video signals. The dense tin coated copper screen ensures complete elimination of EMIRFI from video signals and also provides reduced DC resistance ground path. The multi stranded construction offers better flexibility and reduced bending radius.

Standard : Based on VDE 0812 Nominal Voltage : 0.14 mm² = 350 V; >= 0.25 mm² = 500 V Insulation Resistance : Min. 20 GΩ x cm Temperature Range : Flexing -5°C to +70°C. Fixed installation -30°C to +70°C Minimum Bending Radius : For flexible use 10 x cable ø Test Voltage : Up to 0.25 mm² = 1200 V. From 0.34 mm² = 2000 V Breakdown Voltage : Up to 0.25 mm² = 2400 V. From 0.34 mm² = 4000 V Cable Construction

This system cable is used to interconnect L2-BUS components. This cable is an economical solution for the cell andThe high level of screening reduces substantially the effects of electrical disturbances. These cables are used for

or use as a data and control cable in machinery, computer systems etc as well as a signal cable for electronics. The high level of screening ensures a high degree of interference protection. degree of interference protection

India's 1st Heat Resistant and Flame Retardant REACH and RoHS Compliant Cable with Unilay Conductor. No Loose Contacts, No Broken Ends. Suitable for use in conduit and for fixed, protected installation

Approvals : IS 694 marked, FIATAC Conductor : Electrolytic grade annealed copper Class 5 as per IS 8130 Standard Cable Colour : Black, grey & white Voltage Rating : Up to and including 1100V Packing : Standard packing of 100 mtr. in coil. Longer length available on request

Bare copper strands as per EN 60228, Cl. 6 Conductor Bunch Variants : Normal flex and Super flex Special Elastomeric Insulation : Thermoplastic Elastomer Vulcanizate PropertiesAcid Resistance Test : In sulphuric acid of specific gravity 1.28 at a temperature of 160°C to 210°C and check the cable after 60 hrs. No effect on insulation. Insulation free from deformation and shrinkage. Chemical Resistance :Resistant to ozone, acids, solvents, detergents, vaseline and oil.
