Thermic Fluid Pumps Dealers in Vatva, Ahmedabad (9 products available)

Our company is a prominent Manufacturer, Supplier and Exporter of Thermic Fluid Pump from Ahmedabad, Gujarat. Our Thermic Fluid Pump is widely preferred in various industries for its efficient working and long functional life. Customers from all over the world can place bulk orders for Thermic Fluid Pump with us. We make them available at highly modest rates.   As per ISO 2858 / DIN 24256 : Capacity up to - 250 m3/Hr Temp. up to - 350oC TDH up to - 95 MLC Working Pr. up to - 20 Bars Delivery Size up to - 100 mm Industries Covered : Pharmaceuticals & Chemical Oil Extraction Plants Pulp & Paper Industries Waste Oil Refining Plants Starch Industries Air-Conditioning / Heating Plants Effluent Treatment Plants Cooling Tower Water Circulation Dyes & Intermediates Solvent Transfer RO & DM Water Plants Thermic Fluid Circulation Material of Construction : Pumps are manufactured in variety of materials such as Stainless Steel as per ASTM A 351/743 Gr. CF8, CF8M. Carbon Steel / WCB.

"Flowchem" Series PPC pumps are Centrifugal Pumps in Back Pull-out Construction , Horizontal, Center line Mounted, Single stage, End suction and Top Centerline Discharge Suitable for Thermic Fluid & Hot Oil also.Impellers are provided either with Back Vane to minimize Axial Thrust and Gland Leakage.

Our range of Pumps is manufactured by adopting latest technological development. Engineered to meet the perfection these are designed with utmost care and assure longevity .Further its compact & light-weight structure allows it to be easily placed inside original equipment.

End Suction Pumps (Cantilever), End Suction Process Pumps for both Engine Driven and Motor Driven, Wet Pit, Dry Pit Pumps. These pumps are used in applications such as water transfer, process water transfer, chemical, petrochemical, fire fighting, chilled water circulation, cooling water, hot water circulation, thermic fluid circulation, furnace oil transfer or circulation, water treatment plant.

• Power: !-3 kw , 3-6 kw, 6-9 kw
• Max Flow Rate: 250 M3/hr.
• Working Pressure: 15 Bars
• Temperature: 350 deg c
• Speed: 960 / 1450 / 2900 rpm
• Color: Red , White , Yellow
• Voltage: 110 V , 220 V , 320 V, 380 V

we are counted among the leading suppliers of exclusive quality thermic fluid pump to our valued customers. These pumps are manufactured from best quality stainless steel and cutting-edge technology. Offered pumps are appreciated for their noise and vibration free performance, easy installation and high degree interchangeability. Our pumps are suitable for both organic and inorganic fluids and used in oil refineries, paper, food, chemical, textile industries and sea water desalination plants. These pumps are equipped with water / self cooling feature that makes them suitable for the applications in heat transfer plants and handling of organic heat transferring of oils. In compliance with the latest industry standards, these pumps are designed with heavy duty bearings.     features • low maintenance • easy to operate • longer service life. specifications (as per iso 2858/din 24256) • capacity up to 250 m3/hr • temperature up to 350ºc • tdh up to 95 mlc • working pressure up to 20 bars • delivery size up to 100 mm. • speed – n- :- 960/1450/2900 rpm   industries covered • pharmaceuticals & chemical :- oil extraction plants • pulp & paper industries :-waste oil refining plants • starch industries :- air-conditioning heating plants • effluent treatments plants :-cooling tower water circulation • dyes & intermediates :- solvent transfer • ro & dm water plants: – thermic fluid circulation. material of construction • pumps are manufactured in variety of materials such as carbon steel / wcb as per astm / din standards • stainless steel as per astm a 351/743 gr. Cf8/cf8m • carbon steel (wcb) / alloy steel • cf-8 , cf-8m cf-3 ,cf-3m (ss-316l) , alloy 20 , cd4mcu   construction features casing :- volute –type , back pull out , centre line top discharge , end suction , integrally cast feet,center line support casing if required shaft sleeve :- easily replaceable , hardened , compatible , supply of thermic fluid sealing arrangement :- graphite packing in gland box having cooling chamber that ensure to pass cooling water and safeguard graphite packing life. mechanical seals :- single spring / metallic bellow impeller :- enclosed type , provided with back vanes to reduce pressure on stuffing box and to minimize axial thrust and gland leakage, high hydraulic and mechanical efficiency. bearing housing :- reinforced and standard and bearing assemblies which are perfect for high temperature as well as high suction pressure of 0.05 mm. It is available with constant level oiler flanges :- enclosed flange rating pn 16 and drilled to din standard to meet iso 2858 requirements. throat ring / bush :- it is perfectly designed to reduce the pressure on stuffing box. Also it helps to increase the life of graphite packing. designed for :- circulation of heat oil transfer jacketing for cooling offered for s/box , casing pedestal and bearing-housing, standard bearing / special heavy duty bearing arrangements available.

• Capacity – Q- up to: 250 M³/hr.
• TDH - H- up to : 95 MLC
• Speed - n - : 960 / 1450 / 2900 rpm
• Temperature : 350 ºC
• Working Pressure : 15 Bars
• Pump sizes – DN - : 32 mm to 100 mm

Horizontal, end suction, centrifugal pump manufacturers, radially split, volute casing process pumps in back-pull-out design, fitted with a radial impeller. CONSTRUCTIONAL OPTIONS : 1.  Offered with Closed Impeller.  2.  Impellers are provided either with Back Vane to minimize Axial Thrust and Gland Leakage.  3.  Flange Rating PN 16 and drilled to DIN standard to meet ISO 2858 requirements.  4.  Shaft Sealing by, Moulded Graphite Rings.( GRAFOIL PACKING )  5.  Mechanical Seals ( SINGLE SPRING / METALLIC BELLOW).  6.  Jacketing for Cooling offered for S/Box, Casing Pedestal and Bearing- Housing,    MATERIAL OF CONSTRUCTION : AS PER ASTM / DIN STANDARDS ·    CARBON STEEL(WCB) / ALLOY STEEL
