Fibre Optic Patch Panels
Get Price Quote
The Optical Fibre Patch Panel is suitable for terminating optical fibre cables coming from the line and connecting the optical fibres to the pigtails by splicing. These pigtails are connected to the pre-installed adaptors at one end and from the other end output can be taken to active devices using patch cords. Patch Panel provides splicing, termination and distribution ina single unit.
Features
Compact and robust construction.
Available in wall mounting and rack mounting versions
Accessibility from the front & top sides for testing and easy handling
Main body constructed from internal stress free CRC sheet. Aluminium sheet body also available.
Powder coated finish enables operation even in coastal areas
Dust and insect ingress resistant
Provision to store extra lengths of fibres
Provision of two inputs & two output ports
Contains Fibre Organizer trays to hold fibre splices, capacity of each tray upto 24 splices
Capacity to accommodate upto 6 nos. of Fibre Organizer trays and house upto 144 splices
Design ensures bend radius of stored pig tails & patch cords above the critical value
Capacity to hold adaptors of FC, Sc & ST type as required
Complete Kit with consumables available
Applications
Long distance Optical Transmission Networks
Termination & Distribution of OF Cables
Datacom Networks
Specifications
Physical dimensions suitable for installation in 19” rack with multiples of ‘U’ as stand alone system
Operating Temperature: -30°C - +70°C
...more
