PET Flakes Dealers in Ambala

The Snellen eye chart was originally introduced in 1862 by Herman Snellen. The Snellen eye test uses the idea of a subtended 5 minutes of arc with a 20 foot distance. This became the "standard vision" measurement. Also, Snellen developed the idea of a 5x5 grid for a standard for his optotypes. Each optotype must meet certain percentage requirements in this grid before it is used for testing. This helps to make a uniform and equal vision chart. The Snellen eye test is the basis for many other vision tests.Non-reflecting, matte finish eye charts, Designed for vision testing at 20 foot distance, Eye chart measures 22 x 11 in.

We are offering 33kv heat shrinkable outdoor termination kits. Heat shrinkable indoor termination kits from 6.6kv to 12kv used for low to medium voltage requirements, this product has gained a wide and loyal clientele worldwide, which is an acknowledgement, for our international quality norms. Our products in this category are renowned for the stringent quality processes we employ in our state of the art manufacturing facility. Used in a wide spectrum of industries, this product has the following properties. Parts of the termination system: 1. Heat shrinkable non tracking tube: (red) non tracking tube (red) is used as an external protective covering for the core for both indoor and outdoor applications. Properties of this tube are high insulation, non tracking, erosion resistant, weather proof and flame retardant. Minimum length of the non tracking tube depends on the system voltage and whether the application is indoor or outdoor. Please refer to the engineering drawing for details. 2. Heat shrinkable stress control tube: sct (black) stress control tube (black) is used to control the high electrical stress present at the end of the semi-con screen of the cable. This tube has a combination of resistive and capacitive characteristics which, when applied to the end of the semi-con screen of the cable, give relief to the electrical stress, by stress grading. The minimum lengths of the stress control tube necessary for effective stress control are 130 mm for 12 kv 3. Heat shrinkable lug seal hv lug seal is made from the same material as the non tracking tube and is coated internally with the red sealant. Lug seal protects the interface between the termination lug and the cable core covered with the non tracking hv tube. 4. Heat shrink mv breakout mv breakouts are used to provide insulation, binding force and sealing over the crutch of three core cables at the branching point. They are coated internally with waterproof, non-tracking, butyl rubber based red sealant mastic. 5. Heat shrink hv sheds hv sheds are used to extend the creepage path. The properties of the hv sheds are electrical insulation, non tracking, erosion resistant, weather proof and flame retardant. Hv sheds are internally coated with waterproof, non-tracking, butyl rubber based red sealant mastic. The minimum number of sheds designed to be used in the termination system depends on system voltage and whether the application is indoor or outdoor. Please refer to the engineering drawing. 6. Conductive paint / stress grading mastic conductive paint / stress grading mastic is applied around the step formed at the screen-cut point i.e. At end of the semi-con screen and start of the xlpe insulation of the cable, to render the air entrapped at the step discharge free. Use of either conductive paint or stress grading mastic in the termination, depends on the respective end users. Terminations of both types are available and have separate installation procedures. 7. Red sealant red sealant is applied around the base of the terminal lug where it is crimped to the cable conductor. The red sealant acts as a filler and insulating material to fill in the step formed at the end of conductor insulation. It forms a waterproof seal at the end of the termination, which is essential for the long service life of the termination. The red sealant is made from butyl rubber based mastic and has good non-tracking properties. 8. Discharge supression compound cuts and scratches on the xlpe insulation may cause electric discharge under the stress control tube. Application of a thin layer of silicone based discharge suppression compound will make it free of partial discharge. 9. Earth bond the earth bond arrangement consists of a metallic ring, hose clips and tinned copper braid attached to the copper tape screen of each core and armour of the cable at the base of the termination. This proven armour earthing arrangement provides sound electrical contacts at armour bonding points and avoid excessive temperature rise during earth faults. Electrical specifications (12 kv rated accessories) test requirement requirement test value uxo/e-1112-series a.c. Withstand, 1 minute 35 kv pass d.c. Withstand, 15 minute 48 kv pass discharge extintion voltage ( 12.7 kv impulse withstand (crest kv) 75 kv > 75 kv continuous current rating as per cable as per cable ordering information cable size (sq mm) outdoor kit code indoor kit code 16-35 yxo-11 yxe-11 50-95 yxo-12 yxe-12 120-185 yxo-13 yxe-13 240-300 yxo-14 yxe-14 400-500 yxo-15 yxe-15
