Apollo Valves & Pipes Ankleshwar, Gujarat

Engineering Options: S.S. 304/316 parts can be supplied Glass Length as per your request Available M.O.C.: PP (POLYPROPYLENE) HDPE (HIGH DENSITY POLYETHYLENE) ISOTACTIC PP PVDF (POLYVINYLIDENE FLUORIDE)

Top plate double drilled to fit ISO 5211 dimensions and standard secondary bolt circle dimensions Unique centre-lock seat design virtually eliminates any seat movement during the seating and un-seating of the disc Unique stem retention system to provide blow-out proof stem and easy assembly and disassembly of valve Heavy duty one piece wafer and lugged wafer body designed to withstand specified pressures Nylon coated high strength disc with hand polished disc edge and hubs ensures excellent corrosion resistance to several chemical media Heavy duty square grooved seat design with moulded O-ring seals to serve as flange gasket One piece stem with close tolerances double D drive eliminates the need for disc screws or taper pins Heavy duty bearing absorbs the forces acting on the stem/disc assembly due to line pressure Applications: ​​ Water works Power plants Sewage plants Process industries Chemical and petrochemical plants ​ Specifications: ​Manufacturing Standard - API609/ BSEN 593 (BS 5155) Size Range 50 to 600 mm Pressure Ratings PN10, PN16 End Connection To suit ANSI # 125/ 150

Features: Rigid and sturdy design with minimum head loss Long service life and leak-tightness of high order Suitable for clear water having turibidity upto 3000 o ppm and temperature of 65 Centigrade (rubber to o bronze / stainless steel seating) and upto 95 Centigrade (Bronze/ bronze, stainless steel / stainless steel seating Applications: Used in waterworks piplines to reduce water hammer effect Preventing back flow of water to the pump Specifications: Manufacturing Standard Generally as per BS 5155 / IS 13095 Size Range 800,1000 & 1200mm Pressure Ratings PN6, PN10 End Connection Flanged

Features: Double Orifice Type (Small and large orifice), kinetic type Single air valve Non clogging and self sealing balls for trouble free operation Totally tamper proof kinetic air valve series available. Suited for turbid or clear water sewage; releasing air when water mains are being filled and admitting air while being emptied. Cuts loss of water when water mains are full Releasing air accumulated under pressure in pipe during normal conditions. Applications: Water Supply Lines / Distribution Lines Clear Water and sewage applications Specifications: Manufacturing Standard IS 14845 Size Range 50 to 200 mm Pressure Ratings PN6, PN10, PN16, PN 20

Features: Swing check type design Rigid and sturdy design with minimum head loss Long service life and leak-tightness of high order Suitable for clear water having turibidity upto 3000 o ppm and temperature of 65 Centigrade (rubber to o bronze / stainless steel seating) and upto 95 Centigrade (Bronze/ bronze, stainless steel / stainless steel seating Applications: Used in waterworks piplines to reduce water hammer effect Preventing back flow of water to the pump Specifications: Manufacturing Standard BS 5153 (EN 12334) / IS 5312 Part 1 & 2 Size Range 40 to 1500 mm Pressure Ratings PN6, PN10, PN16 End Connection Flanged​

Features: Double Orifice Type (Small and large orifice), kinetic type Single air valve Non clogging and self sealing balls for trouble free operation Totally tamper proof kinetic air valve series available. Suited for turbid or clear water sewage; releasing air when water mains are being filled and admitting air while being emptied. Cuts loss of water when water mains are full Releasing air accumulated under pressure in pipe during normal conditions. Applications: HVAC Building and construction (Multi storied buildings/Shopping Complexes/Auditoriums/In door Stadium/ Airports/ Refrigeration System). Industry (Pharmaceuticals/ Bottling plants/ Chemical/ Food and Beverages Specifications: Suction Diffuser​   Size Range: 2" to 20" Pressure Rating: ANSI Class 125 and class 250 ANSI Standard Flanges​​ Triple Duty Valve Size Range: 2" to 24" Pressure Rating: ANSI Class 125 and class 250 ANSI Standard Flanges

Features: Internationally patented design for minimum loss of live steam Multi-concept, high energy saving, efficient impulse cum themodynamic steam trapping device Ends - Flanged / Screwed Applications: For every industry using steam lines Specifications: Manufacturing Standard : ISO 6552 Size Range: 15, 20 and 25 mm Ends Flanged / Screwed

  Features: Rigid and sturdy design Low pressure loss across the valve Suitable for clear water up to 45 C and 5000 ppm turbidity, other fluids with maximum pressure / temperature conditions within the scope of IS:14846 Long service life and leak-tightness even after thousands of open / close cycles Applications: Water works Water / Effluent / Sewage treatment plants Fire Fighting Power Specifications: Manufacturing Standard - BS 5163 / IS14846 Size Range 32 to 1500mm Pressure Ratings PN10, PN16 End Connection Flanged​ ​

Features: Rigid and sturdy design Low pressure loss across the valve Suitable for clear water up to 45 C and 5000 ppm turbidity, other fluids with maximum pressure / temperature conditions within the scope of IS:14846 Long service life and leak-tightness even after thousands of open / close cycles Applications: ​​ Water works Water / Effluent / Sewage treatment plants Fire Fighting Power ​ Specifications: ​Manufacturing Standard - BS 5163 / IS14846 Size Range 32 to 1500mm Pressure Ratings PN10, PN16 End Connection Double Flanged​

Engineering Options: Teflon coated Rubber, EPDM Rubber, Viton Rubber on request Available M.O.C.: PP (POLYPROPYLENE) HDPE (HIGH DENSITY POLYETHYLENE) ISOTACTIC PP PVDF (POLYVINYLIDENE FLUORIDE

Features: Double Orifice Type (Small and large orifice), kinetic type Single air valve Non clogging and self sealing balls for trouble free operation Totally tamper proof kinetic air valve series available. Suited for turbid or clear water sewage; releasing air when water mains are being filled and admitting air while being emptied. Cuts loss of water when water mains are full Releasing air accumulated under pressure in pipe during normal conditions. Applications: Water Supply Lines / Distribution Lines Clear Water and sewage applications Specifications: Manufacturing Standard AWWA C512 Size Range 50 to 200 mm Pressure Ratings PN10, PN16

Max Bore : 100 mm

Features: Rigid and sturdy design Long service life with leak tightness Back seating surfaces provided integral to bonnet Applications: Refineries and Petrochemical Industries Fertilizer Plant Themal Power Plant Other Process Industries Specifications: Manufactured Standard: API 602/ BSEN 15761 (BS: 5352) Size Range: 8 to 50 mm Pressure Rating: Class 800 End Connections: Socket weld, Screwed End

Engineering Options: Teflon coated Rubber, EPDM Rubber, Viton Rubber on request Available M.O.C.: PP (POLYPROPYLENE) HDPE (HIGH DENSITY POLYETHYLENE) ISOTACTIC PP PVDF (POLYVINYLIDENE FLUORIDE)

  Features: Rigid and sturdy design with minimum loss of head across the valve Perfectly flat seating surfaces for good sealing Preventing entry of foreign body to pump through suction pipe Long service life Applications: Used in suction side of pump to avoid flow reversal from pump to sump with monobloc pumps Specifications: Manufacturing Standard IS 4038 Size Range 50 to 600 mm Pressure Rating PN 2

  Features: Metal to metal seating for longer service life Rigid and sturdy design with minimum loss of head across the valve Accurate interchangeability of components Accurate parallelism between side flanges Equal taper between wedge faces Perfect machining and press fitting of body and wedge rings Excellent finish on spindle threads resulting in low friction and smooth operation of valves Leak-tightness even after thousands of Open / Close Applications: Fire service water control valves Specifications: Manufacturing Standard IS 14846 Size Range 50 to 250 mm Pressure Rating 250 PSI End Connections Flanged

Engineering Options: S.S. 304/316 parts can be supplied Glass Length as per your request Available M.O.C.: PP (POLYPROPYLENE) HDPE (HIGH DENSITY POLYETHYLENE) ISOTACTIC PP PVDF (POLYVINYLIDENE FLUORIDE)

Flush Bottom Valve has been designed for use in highly corrosive liquid services. The heavy duty construction of this valve features a cast ductile iron body with corrosion resistant fluropolymer lining. It is suitable for high temperature applications. We can supply it as both, manual or automated valve, increasing the flexibility of this device to address your tank draining requirements.

Features: Rigid and sturdy design with minimum loss of head across the valve Compact, light weight, low operating torques Eccentric seat geometry results in less wear and tear and longer life Self cleaning and non jamming seat design Gas tight shut-off Self energizing seating design Combined 'O' ring and 'U' cup seating on shaft Through flow disc design for large size Butterfly Valves Applications: ​​Water works Power plants Sewage plants Process industries Chemical and petrochemical plants ​ Specifications: ​Manufacturing Standard BS 5155 (BS EN 593)/ AWWA C504/ IS 13095 Size Range 50 to 4500 mm Pressure Ratings PN6, PN10, PN16, PN20 Class -75, 150, 250 End Connection Double Flanged​

Engineering Options: S.S. 304/316 Parts can be supplied Teflon coated Rubber, EPDM Rubber, Viton Rubber on request Available M.O.C.: PP (POLYPROPYLENE) HDPE (HIGH DENSITY POLYETHYLENE) ISOTACTIC PP PVDF (POLYVINYLIDENE FLUORIDE)

Features: Double Orifice Type (Small and large orifice), kinetic type Single air valve Non clogging and self sealing balls for trouble free operation Totally tamper proof kinetic air valve series available. Suited for turbid or clear water sewage; releasing air when water mains are being filled and admitting air while being emptied. Cuts loss of water when water mains are full Releasing air accumulated under pressure in pipe during normal conditions. Applications: Water Supply Lines / Distribution Lines Clear Water and sewage applications Specifications: Manufacturing Standard IS 14845 Size Range 50 to 250 mm Pressure Ratings PN6, PN10, PN16

Features: Double Flanged / butt weld end, outside screw rising stem, yoke type bonnet Back seating bush arrangement to enable repacking under pressure Rigid and sturdy design Long Service Life Applications: Naptha and naptha derivatives in oil refineries Water, steam, air, gas and liquids having corrosive properties Suitable for wide range of working conditions of pressures and temperature ratings Specifications: Manufacturing Standard BS 1873 Size Range and Pressure Rating 25 to 400 mm Class 150 25 o 300 mm Class 300 End Connection Flanged

Features: Double Flanged / butt weld end, outside crew rising stem, yoke type bonnet Back seating bush arrangement to enable re - packing under pressure Rigid & sturdy design Low pressure loss across the valve Long service life and leak tightness Applications: Naptha and naptha derivatives in oil refineries Water, steam, air, gas and liquids having corrosive properties Suitable for wide range of working conditions of pressure and temperature ratings Specifications: Manufacturing Standard API 600 Size Range and Pressure Ratings 50 to 750 mm : Class 150 50 to 600 mm : Class 300 50 to 350 mm : Class 600
