Liquid Filling Machinery Dealers in Ankleshwar (6 products available)

  Automatic Rotary Piston Filling Cum Sealing Machine is versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are provided to facilitate the servicing of machine, work on volumetric principle with rotary motion. The unit is made compact, versatile and enclosed in stainless steel elegantly matt finish body. No container No filling & No Sealing system arrangement is standard features of the machine. Salient Features • Motorized Height Adjustments. • Automatic chain washing system for conveyor belt. • In-built pre-inspection. • Nitrogen Flushing. • Cap Elevator to feed caps to the cap feeding bowl. Technical Specifications Model PEW-N-RFSC-4/4 Output/Hour* 1500 to 6000 Number of head/Syringe/cap 4/4 Direction of Movement** Left to Right Fill Size*** 30 ml to 200 ml Height of Conveyor ** 910 mm to 960 mm Adjustable. Machine Dimensions** 3050 (L) x 1400 (W) x 2200 (H) Case Dimensions 3250 (L) x 1600 (W) x 2400 (H) Net Weight 2400 Kgs Gross Weight 2950 Kgs

Working on volumetric principle, the unit is made compact, versatile and enclosed in stainless steel elegantly matt finish body. The semi automatic volumetric liquid filling machine is precision built on sturdy welded MS frame completely enclose in stainless steel sheet and doors are provided to facilitate the servicing of machine. Working on volumetric principle Salient Features of Semi Automatic Two Head Volumetric Liquid Filling Machine Containers have to place manually below the filling nozzles at platform of machine Where motor operated syringes fill desire pre set volume in container. Bottle guide is provided for precisely match for centering of container below nozzles to avoid spillage of liquid on container. The dosing block with a hexagonal bolt fitted below syringes. This means fill size can be easily set. Technical Details of Turn Tablet Scrambler & Un Scramble Output/Hour* 700 to 2400 containers Number of head/Syringe 2 Nos. Fill Size 5 ml to 1000 ml Electric Specification** 1 HP / 415 Volts / 50 Hz (Main Machine) Machine Dimensions** 925 mm (L) x 700 mm (W) x 710 mm (H ) Case Dimensions 1200 mm (L) x 900 mm (W) x 900 mm (H) Net Weight 120 Kgs.8. Gross Weight 275 Kgs

We are offering beverage dispensers

Tube Filling Machine, Ointment Plant, Silicone Filling Machine

Coffee Vending Machines, Coffee And Tea Vending Machines, Tea Vending Machine
