Pouch Packaging Machine Dealers in Ankleshwar

Suitable for ampoule, vial, oral liquid and other small round bottle automatic printing, tray forming and feeding in tray. This machine is an improved product innovated by our company that incorporates pneumatic-photo-electro-mechanic, controlled by PLC and man-machine interface operation. It meets packing requirement of small round bottle as ampoule for automatic printing, tray forming, feeding and cutting. It is featured by compact construction and convenient operation. Model: Model PEW-IDPB250/PEW-IDPB320/PEW-IDPB350 Cutting Frequency (times/min) :10-30/10-30/10-30 Production Capacity (pcs/h) :12000-30000/13000-35000/15000-38000 Max. forming area and depth (mm)240(310/340)×140×26(Standard depth: 14 Travel Range (mm) :40-150 (Can be lengthened to 180mm as user's requirements) Air Pressure (Mpa) :0.4-0.6 Air Supply :=0.35m3/min Total Power :380V/220V 50Hz 6.2kw Main Motor Power (kw) :1.5 PVC Sheet (mm) :0.25-0.5×250 (320/350) PTP Aluminum Foil (mm) :0.02-0.035×250 (350) Dialysis Paper (mm) :50-100g×250 (350) Mould Cooling :Tap Water Or Circulating Water Weight (kg) :1600/1900/2100 Features: Automatic production line of up and lower heating, positive press forming (tray forming), printing, automatic feeding (feed in tray) and cutting. Equipment with mechanism checking device, eject empty or lack packing tray automatically. Blister forming, heat-sealing, lot number embossing, avulsion line impressing and cutting etc all adopt gear mandrel orientation, each can move freely in the mandrel when rotating the hand wheel, and the machine equipped with a staff gauge and tightening nuts for calibration and orientation. It can line with labeling machine in front and cartooning machine in back part, carry out the whole automatic production line. Main transmission part adopts parallel axis and bevel wheel speed reducer. Forming, heat-sealing and impressing moulds adopt bolt orientating which leads to precise orientation, easy to change mould and material saving

The PEW-RP-240 is an automatic Blister Packaging machine utilized for packaging of the tablets, capsules in a blister pack. This is a machine with continuous operations of forming station, feeding station, sealing station and printing station. Whereas punching station is of intermittent nature. Product capacity of the machine depends on the product characteristics, pack layout and on type of feeding device Salient Features 1. PVC film is generally used as base film and Aluminum foil with heat sealable VMCH coating as lidding film. 2. Batch code printer, Inspection Camera and Inline perforator are the accessories, which can be mounted on the machine. 3. The blister cavities are formed on the PVC/PVDC film web by vacuum processes. 4. This blister formed web moves over the web guide track and at this station the products are fed into the individual cavities. 5. The formed web along with the tablet or capsules moves towards a sealing station, where it is fused to the aluminum foil, which is drawn from an aluminum reel – feed station 6. The punching tool punches out the specified pack, which is transferred to the out feed conveyor. 7. Products to be packed on the machine are specifically pharmaceutical products such as Tablets and Capsules. Different type of products can be fed into the blister formed cavities on the formed web over the web guide track at the feeding zone Technical Specification PEW-RP-240 1. Max. Machine Speed (Packs)4.5-5.5 meters/min{240 packs per      minute} 2. Max. Forming Area 110 x 210mm 3. Max. Forming Area 30 x 140mm 4. Optimum Forming Depth 10mm 5. Max Reel Diameter 440mm 6. Max. Lidding Foil 210 mm 7. Max. Core Diameter 70mm Floor Space 8. Machine Width 925 mm 9. Machine Height 1750 mm 10. Machine Length 2900 mm

ALU-ALU (OPA). Lidding Material : Aluminium with Heat Sealable Lacqure Coating. We are leading manufacturer, supplier & exporter of Blister packing machine in Gujarat, India.
