Embedded System Designing
Get Price Quote
We are providing embedded system designing. An introduction to embedded system design using 8051 microcontroller.
SYLLABUS
� Basic Electronic Concepts
o Resistors, capacitors, diodes, rectifier, power supply, op-amp circuits, driving LED�s, buzzer, relay
� Digital Electronics Concepts
� Basics of Embedded Systems
� Embedded Programming Languages
� 8051 Microcontroller, Architecture
o Embedded C
o Assessments on 8051 Microcontroller
o Introduction to the Compiler Embedded C, basics tips and tricks
o Simple Programs to Interface LEDs
o Interfacing of switches
o Buzzer Interface
o Reading input from Port pins
o Writing Output Data to port pins
o Interfacing to LCD display and its programming using C
o Relay interfacing with 8051
o Interfacing of Motor Driver L293
o Time delays in 8051
o On chip Timer programming
o Use of timer to generate time delay
o Use of Timer as Counters in 8051 and its programming using C
o Frequency Calculation
o Analog to digital Converter (ADC) Interfacing
o Sensor interfacing
o Theory of Serial Communication
o Serial Communications basics
o What is USART, UART in 8051
o RS-232 PROTOCOL, theory and operation
o Serial Communication on 8051
o Sending data to PC
o Receiving data from PC
o Project Development
What do we Offer
8051-microcontroller based project kit (Rupee 600- extra)
� 8051 Microcontroller (Philips P89v51RD2 In system programmable, no programmer needed)
� Clock and reset Circuit
� Power supply circuit
� MAX-232 Computer Interface circuit
� Serial Cable for interfacing with PC and 232-based devices
� 1 X ULN2803 Relay Stepper motor drive circuit
� 8 X LEDs
� 4 X Switches
� 1 X Relay
� 1 X buzzer
� Provision for Connecting LCD (LCD included)
� CD containing all the sample codes, circuit diagrams, e-books, project ideas etc
� Course Completion Certificate
Add On kits
� Motor Driver Kit
� LCD module
� Wireless Remote Control Module
� Infrared Sensor Module for robotics
Course Fees: - 6500- (without above mentioned trainer kit)
Above mentioned trainer kit can be used for development of any kind of embedded project on 8051
Students can download the program into the microcontroller without need of any external device programmers so they can practice with the trainer kit at home using only PC and Kit
Full support about coding, project, basic concepts, via e-mail even after completion of course, since we are resident at Aurangabad only.
