Mahesh Extrusions Ltd Mundargi, Ballari, Karnataka

Upvc Elastomeric Sealing UGD Pipes for drainage and sewage systems are as per IS 15328 : 2003. The pipes have one end elastomeric sealing ring and the other end chamfer with 15 which fit snugly without couplers. Elastomeric Sealing ring joint non-pressure Socketed pipes SDR51, SDR41 and SDR 34 are manufactured in the range of 110mm to 315mm diameters and are supplied in standard length of 6 meters and available in brown colour. Applications Underground non-pressure drainage systems Bio-gas and oil distribution lines Subsoil drainage systems Industrial and chemical effluent disposal systems Acid and slurries transportation Features Joints accommodate expansion and contraction Convenient push fit joint saves manpower Jointing can be done under any weather conditions and at any time of the day faster installation, immediate pressure testing and commissioning possible.

Features Low maintenance costsLightweight, Economical No chance of clogging in the drainage system

  Mahesh elastromeric ringtite pipes are used to overcome problems experienced commonly in the joining the higher diameter uPVC pipes using solvent Cement. Ringtite pipes offer excellent advantages over other uPVC pipes specially for underground applications AdvantagesHighly reliable and robust. It has prolonged self life. it is not affected by ultraviolet radiation, bacteria, termites and fungus and ozone. the joints are waterlight, stable and resist pressure from both vertical and horizontal tractate forces. it is easy to install in any climatic condition in the field. Pipelines can be tested and put into use immediately after the jointing. Shorter installation time. Ringtite pipes are available from 63mm to 315mm diameters in 4,6,8,10 kgf/cm2 working pressure

Plumbing pipes are joined by using solvent cement in which fusion and mating between fitting and the pipes takes place creating a homogeneous joint. Plumbing pipes are available in blue and grey colors, sizes ranging from OD 20mm to 50mm in metric series as per IS4985 : 2000

Mahesh HDPE Pipe manufactured from high quality virgin pipe grade materials. ie. PE63, PE80, PE100 are available size from 20mm to 315mm in various pressure ratings(PN2.5, PN4, PN6, PN8, PN10, PN12.5 and PN16). Avilable in 6mts length or long coils depending on pipe dimensions. manufactured as per standard IS4984 : 1995. ApplicationSuitable for under ground and over ground installations. Telephone ducting Portable water supply Irrigation Drip Irrigation and sprinkler system Sanitation, sewage & process industries Advantages Light weight Leakproof, strong and easy jointing Excellent flow characteristics More Flexible.

Advantages & Features The conduits are light in weight and easy to install. Fire Resistance Long Life Non-corrosion and good visual appreaance Available in sizes19mm and 25mm from 1.00mm to 2.00mm thickness.

Features Excellent flow properties by virtue of smooth internal surface. Light weight, strong and easy to handle installation Easy to transport and store Excellent resistance to Chemical, Corrosion and also fire resistant Energy Saving, maintenance free Resistance to Soil Movement by virtue of inherent flexibility. Application Agriculture Lift and drip irrigation Tube well casing Rural and Urban Drinking Water Supply Schemes and Projects Industrial/chemical effluent disposal systems Plumbing and Drainage System Rainwater Disposal Systems. Poultry farms
