Nurse Calling System
Get Price Quote
Patients’ care is undoubtedly the main aim of all hospitals and Nursing Homes. Hence nursecall_systems there is a need to provide one dedicated line of communication to every patient so that the patient can draw attention of a nurse from his bed whenever required. The resources that patients look for are good doctors, good medical equipments and timely care. Hence it is very much essential to have foolproof system by means of which patient can communicate with nurses/doctors to seek their help.
In rapidly changing world, it is becoming essential for nurses only to take care of patients 24 hours without much help from kith & kin of patients. Nursing needs to focus on Quality care and extend utmost importance to the service of the patients and develop a sense of responsibility and accountability of total nursing with compassionate heart. Our Nurse Call System is designed keeping in view the relevance of quality nursing in today’s context and gives topmost priority to it. Installing our NCS in the hospital enables efficient management of nursing staff.
PRODUCT FEATURES
Designed by highly experienced engineers.
Room Number Display tailor made to customer requirements.
Working successfully since past 5 Years.
Cost effective, efficient, compact and highly reliable.
Maintenance free.
Makes use of super bright 7segment LEDs to enhance the life of indicators and reduce power consumption.
Voice module with Standard voice “patient wants you Please Assist” instead of buzzer makes it distinguished.
Very low working voltage to ensure patient’s safety.
Very simple design to make it easily installable and Maintenance free.
Call from a patient remains registered till the nurse attends the patient and clears the call from his room.
SPECIFICATIONS
1. MAIN MICRO CONTROLLER BASED NURSE CALLING DISPLAY UNIT.
This is a Microcontroller based device placed in the nurse station with static windows which displays the room number of the calling patient and also it has a voice module to announce the call.
Power Button : Press switch turns the device ON..
Mute Button : It is for acknowledging a call from patient. It will make the window steady and It will silences the voice module until a call is cleared.
Fuse protection : Protection against high AC Mains Voltage & Protection for call units
Volume control : “Volume” To adjust the volume of Voice Message
No. of Windows : Maximum 12
Dimension : 400H X 345W X 100D mm
Light Source : Super Bright 7 segmsent LEDs
Operating Voltage : 12V DC
Current : 50 MA
Maximum Visual Indication : Through RED LED.
Dimensions : 345mm (L) x 400mm (W) x 100mm (D)
Operating Temperature : 0 to 50 degree Celsius
. MICRO CONTROLLER BASED REMOTE NURSE CALLING DISPLAY UNIT (LCD).
4 X 20 LCD used to display the bed numbers. This Unit can be placed remotely from Main Nurse Station
MAIN FEATURES
Built in Power Supply.
Built in Voice Message.
Mute Switch-To silence Voice Message.
User friendly display-Back lit LCD (Liquid Crystal Display (4×20)80 Characters.
LCD gives –Room number/ Bed Number.
TECHNICAL SPECIFICATIONS
Mains Input Voltage : 230V A.C, 50Hz+/-10VSecondary Voltage : 5V. DCNormal Current Consumption : ≤50mA @ 230V And ≤ 100mA @ 5V D.CMaximum Current Consumption : ≤200mA @ 230V And ≤500mA @ 5VEnclosure : CRCA Fabricated Wall mounting typeDimensions : 300(H)x340(L)x100(D)mm
3. MICRO CONTROLLER BASED CALL UNITS
The unit is designed with soft touch key pad consisting of one key for call initiation and another for clearing call which is required to be done by the nurse after attending the patient.
Additional push button switch is integrated to this unit by means of a coil cord to enable apatient to initiate a call from the bed itself.
Operating Voltage : 12V DC
Current : 25 MA maximum.
Visual Indication : RED LED
Switch Operation : More than 100000 operations assured
Dimensions : 90mm(L) x 90mm(W) x 50mm(D)
4. MICRO CONTROLLER BASED GSM SMS UNIT FOR EMERGENCY INDICATION
If any call is not attended for 5 Minutes/30 Minutes, SMS will be sent to configuredmobile numbers through GSM / GPRS modem.
MAIN FEATURES
Built in Power Supply.
User friendly unit.
Built in high Sensitive antenna.
Built in Sim Card Tray.
160 characters for each message.
Unlimited cell phone numbers can be entered.
TECHNICAL SPECIFICATIONS
Mains Input Voltage : 230V A.C, 50Hz+/-10VSecondary Voltage : 5V. DCNormal Current Consumption : ≤50mA @ 250V And ≤ 100mA @ 5V D.CMaximum Current Consumption : ≤200mA @ 230V And ≤500mA @ 5VEnclosure : CRCA Fabricated Wall mounting typeDimensions : 240(H)x 255(L)x70(D)mm
5. PC BASED SOFTWARE TO LOG THE CALLS
It is a DOS based software which is connected to COM port of the PC. All the call requestand call attended for each bed will be logged and Date Wise report can be provided. Delay timewill be provided between call requested and call attended.
