X-Y stage range: 0 - 25mm
Theta stage mounted on X-Y Stage.
Theta stage: 100 mm diameter.
Drive: Micrometer control for all the three axes.
Material: Black anodized Aluminum
Guides: Cross-roller guides.
X-Y stage range: 0 - 25mm
Theta stage mounted on X-Y Stage.
Theta stage: 100 mm diameter.
Drive: Micrometer control for all the three axes.
Material: Black anodized Aluminum
Guides: Cross-roller guides.
Range 10° tilt and 10° rotation with locking arrangement.
Two micrometers of 0 – 10 mm are provided.
V-block accepts barrel mounted lens system and other cylindrical devices.
Convenient for independent tilt and rotary angle adjustment.
Two slots are provided on either sides of base plate.
Material – Anodized Aluminium.
Range 10° tilt and 10° rotation with locking arrangement.
Two micrometers of 0 – 10 mm are provided.
V-block accepts barrel mounted lens system and other cylindrical devices.
Convenient for independent tilt and rotary angle adjustment.
Two slots are provided on either sides of base plate.
Material – Anodized Aluminium.
The top adjustable mount has kinematic movement (with Micrometer Heads) without obstruction of the laser beam. The mirror is held in the front surface of the mount.
Adjustment range in tow planes: +/- 3 degree
Mounting: The mount can be held by using standard post having M6 tapped hole
Fine Adjustment: By Micrometer Heads
Construction: Aluminum alloy
Finish: Black anodized
The top adjustable mount has kinematic movement (with Micrometer Heads) without obstruction of the laser beam. The mirror is held in the front surface of the mount.
Adjustment range in tow planes: +/- 3 degree
Mounting: The mount can be held by using standard post having M6 tapped hole
Fine Adjustment: By Micrometer Heads
Construction: Aluminum alloy
Finish: Black anodized
This rotary stage comprising two concentric threaded ring is separated by a precision plain bearing. The inner ring is free to rotate while the outer is held stationery. One clamp screw limits the rotation of one ring relative to the other. The second clamp screw locks both rings together.
SPECIFICATIONS:-
Range: 360 degree Coarse, 5 degree fine
Positioning Accuracy: + 1 degree
Dimensions: 200 mm dia. x 35 mm
This rotary stage comprising two concentric threaded ring is separated by a precision plain bearing. The inner ring is free to rotate while the outer is held stationery. One clamp screw limits the rotation of one ring relative to the other. The second clamp screw locks both rings together.
SPECIFICATIONS:-
Range: 360 degree Coarse, 5 degree fine
Positioning Accuracy: + 1 degree
Dimensions: 200 mm dia. x 35 mm
They have a fine pitch of 0.2, 0.3, 0.5 etc.
They feature round and flat ends with/without carbide tip.
Aluminium knurled caps.
Nuts are made of brass.
Material – EN Steel with hard chrome finish.
They have a fine pitch of 0.2, 0.3, 0.5 etc.
They feature round and flat ends with/without carbide tip.
Aluminium knurled caps.
Nuts are made of brass.
Material – EN Steel with hard chrome finish.
For lenses up to 100mm dia.
The 3 points of the lens holder are anchored to a fixed ring and attached by pins in grooves to the spring loaded rotatable outer ring, when the top levers are pinched with one hand the rotatable ring moves and the jaws open.
With Post, Post holder, Collar and Base plate.
Material – Anodized Aluminium.
Available in different sizes.
For lenses up to 100mm dia.
The 3 points of the lens holder are anchored to a fixed ring and attached by pins in grooves to the spring loaded rotatable outer ring, when the top levers are pinched with one hand the rotatable ring moves and the jaws open.
With Post, Post holder, Collar and Base plate.
Material – Anodized Aluminium.
Available in different sizes.
Rotary stage, miniature rotary stage and large rotary stage are available
Rotation by means of radial ball bearings for smooth precision rotation
Range of 360° and ±5° fine
Load capacity of 5 kgs approximately
Rotary stage, miniature rotary stage and large rotary stage are available
Rotation by means of radial ball bearings for smooth precision rotation
Range of 360° and ±5° fine
Load capacity of 5 kgs approximately
Precision pin mounted Prism Mounts is provided with two micrometers fitted tangentially.
Two micrometers/set screws reading up to 0.01mm will facilitate precision movement in X & Y direction.
Range of 3° approximately in each axis.
Accuracy of 10 arc seconds.
Material – Anodized Aluminium.
Available in different diameters.
Precision pin mounted Prism Mounts is provided with two micrometers fitted tangentially.
Two micrometers/set screws reading up to 0.01mm will facilitate precision movement in X & Y direction.
Range of 3° approximately in each axis.
Accuracy of 10 arc seconds.
Material – Anodized Aluminium.
Available in different diameters.
These clamps are designed to mount two post at any angle in relation to each other.
Can be locked at any desired position.
Material – Stainless Steel.
Available in various diameters.
These clamps are designed to mount two post at any angle in relation to each other.
Can be locked at any desired position.
Material – Stainless Steel.
Available in various diameters.
A visible sheet polarizer of 25mm clear aperture is mounted in divided circle assembly of 90 mm diameter.
A short arm provides a smooth manual control of polarizer and scale through 360° rotation. A knob locks the polarizer and scale in position.
A control orientation may be read to one degree.
By releasing a second clamp knob orientation of the index may be adjusted trough 360° with respect to the mounting pin.
Pair of Polarizer and Analyzer.
Material - Anodized Aluminum
A visible sheet polarizer of 25mm clear aperture is mounted in divided circle assembly of 90 mm diameter.
A short arm provides a smooth manual control of polarizer and scale through 360° rotation. A knob locks the polarizer and scale in position.
A control orientation may be read to one degree.
By releasing a second clamp knob orientation of the index may be adjusted trough 360° with respect to the mounting pin.
Pair of Polarizer and Analyzer.
Material - Anodized Aluminum
Z-translation stage with Cam design. Specially designed to provide controlled linear movement in vertical plane.
Movement of 5 mm in Z axis.
Material – Anodized Aluminium.
Available in different sizes.
Z-translation stage with Cam design. Specially designed to provide controlled linear movement in vertical plane.
Movement of 5 mm in Z axis.
Material – Anodized Aluminium.
Available in different sizes.
Heavy duty, of load capacity of 30 Kgs.
Thread ground screw for precise lift.
Traverse height 70mm to 125 mm.
Top plate 100mm x 170mm with M6 tapped holes at 25 mm center distance.
Material – Anodized Aluminium.
Heavy duty, of load capacity of 30 Kgs.
Thread ground screw for precise lift.
Traverse height 70mm to 125 mm.
Top plate 100mm x 170mm with M6 tapped holes at 25 mm center distance.
Material – Anodized Aluminium.
Mounts are kinematically designed for independent orthogonal movements.
Set screws will facilitate precision movement in X & Y direction.
Range of 9 ° approximately in each axis.
Accuracy 8 arc seconds.
Compact design with good stability and high sensitivity.
With Post, Post holder, Collar and a Base plate.
Material – Anodized Aluminium.
Available in different diameters.
Mounts are kinematically designed for independent orthogonal movements.
Set screws will facilitate precision movement in X & Y direction.
Range of 9 ° approximately in each axis.
Accuracy 8 arc seconds.
Compact design with good stability and high sensitivity.
With Post, Post holder, Collar and a Base plate.
Material – Anodized Aluminium.
Available in different diameters.
Mounts are kinematically designed for independent orthogonal movements.
Two micrometers/set screws reading up to 0.01mm will facilitate precision movement in X & Y direction.
Tilt of 9° approximately in each axis.
Accuracy 8 arc seconds.
Compact design with good stability and high sensitivity.
Material – Anodized Aluminum.
Available in different diameters.
Mounts are kinematically designed for independent orthogonal movements.
Two micrometers/set screws reading up to 0.01mm will facilitate precision movement in X & Y direction.
Tilt of 9° approximately in each axis.
Accuracy 8 arc seconds.
Compact design with good stability and high sensitivity.
Material – Anodized Aluminum.
Available in different diameters.
These are precision micrometers fitted on all our standard components.
Micrometer has various ranges with vernier reading of 0.01 mm.
These micrometers can be mounted to a 10mm diameter hole.
They feature round and flat ends with/without carbide tip.
Material – EN steel with hard chrome finish
These are precision micrometers fitted on all our standard components.
Micrometer has various ranges with vernier reading of 0.01 mm.
These micrometers can be mounted to a 10mm diameter hole.
They feature round and flat ends with/without carbide tip.
Material – EN steel with hard chrome finish
Heavy duty precision mount to hold mirror or beam divider of 125 mm dia and 25 mm thick. The precision movement is achieved by micrometers of 0.01 mm least count and are spring loaded. The mount is fixed on a sturdy base.
Heavy duty precision mount to hold mirror or beam divider of 125 mm dia and 25 mm thick. The precision movement is achieved by micrometers of 0.01 mm least count and are spring loaded. The mount is fixed on a sturdy base.
Secondary Business TypeManufacturer / Exporters / Wholesale Suppliers
Opening Hours
SUN : Closed
MON : 9:30 AM - 6:30 PM
TUE : 9:30 AM - 6:30 PM
WED : 9:30 AM - 6:30 PM
THU : 9:30 AM - 6:30 PM
FRI : 9:30 AM - 6:30 PM
SAT : 9:30 AM - 6:30 PM
Opto Electronics is a Company dedicated to design, develop, manufacture and market mechanical systems for applied optics. We have specialized in manufacturing optical hardware, micro – positioning equipment and Opto-Mechanics since 1976. The host of products currently under original equipment manufacturer includes Mirror Mounts, Translation Stages, Laboratory Jacks, Lens / Mirror holders, Post and Post holders, OPTO ELECTRONICS PRIVATE LIMITED Standard Angle Brackets, Rigid clamps and optical Honey comb table with vibration Isolation System / Rigid supporting stand. We also manufacture custom built equipment and integrate Mechanical to Electronic Systems. At Opto Electronics we strongly believe in working to build long lasting relationship with all our customers to earn their trust and Confidence. Our aim is to bring you the best products at competitive pricing with the best of the service. We are totally committed to your satisfaction. Our clients include Space & Atomic Centers, Defense & Research institutions, Universities, and Multi National Corporations. It has been our Endeavour to provide our customers the highest levels of Quality, Precision and reliability.
