diameter0.8 - 5 Inches / 20 mm - 130 mm adjustable product entry guides
height2 inches – 15 ½ inches / 50 mm - 390 mm (Motorized Adjustment)
Induction sealers seal an aluminum laminated liner to the top (bunghole) of plastic containers and/or glass containers with flat threaded caps. This lining consists of several layers of materials typically one metallic layer over a thermoplastic layer. When the container is positioned next to an active induction head, one or more induction coils excite the metallic molecules of the metallic layer. This ultrahigh frequency vibration causes the metal layer to heat up, which in turn melts the thermoplastic layer of the lining causing it to fuse to the top of the container. This seal is hermetic and impermeable to gases. In effect the lining becomes part of the container. From this point on nothing enters or exits the container until the lining is punctured. For this reason induction sealers are used widely thought many industries. The process is extremely simple, and can be accurately repeated time after time.
Advantages
Tamper resistance
Protection from the elements and airborne pollutants
Keeps humidity levels stable
Product freshness
No product leakage
Extended shelf life
Improved product perception & excellent appearance
Seals product aroma
Seals in flavors
Keeps out odors
Tamper evident
Cleanliness
Machine Specifications
Simple to use with minimal operator training
Power: 2000 W
Cap diameter: 0.8 - 5 Inches / 20 mm - 130 mm adjustable product entry guides
Container height: 2 inches – 15 ½ inches / 50 mm - 390 mm (Motorized Adjustment)
Equipped with integrated belt conveyor
Entrance guide with conveyor: 60 inches (1530 mm)
Adjustable speed control: 0 – 34.5 ft/min (0 – 10.5 mt/min)
Forced air cooling system
Stainless steel / aluminum construction
Control Panel
Master ON/OFF switch
Seal current indicator
Input power voltage
Power indicator
Seal ON switch
Seal OFF switch
Induction head UP/DOWN switch
Conveyor belt speed adjust
Other Specifications
Power supply: 220 V AC / 50-60Hz / 1Ph
Casters for ease of movement
Machine dimensions: 60 inches (1525mm) x 14 inches (355mm) x 30 1/2 inches (762mm)
Packaged machine Size: 63 inches (1600 mm) x 27 inches (686 mm) x 48 inches (1219 mm)
Packaged machine weight: 243 lbs (110 kg)
Warranty: This machine comes with a 12 month manufacturer 'return to base' warranty. In the event of a breakdown (which is extremely rare), simply send the machine to us and we will repair and send back to you.
