Max. Oil Flow2 x 211 l/min at 1800 min-1 (Hydraulic)
Max. Swing Speed11.5 per Min
Swing Torque64,400 N-m
Suction Filter105 Micro M
Max Travel Speed5.6 Km/hr
Ground Pressure0.046 MPa
Operating Mass22,220 Kg
Features:-
Engine:
Super Tropical package for temperatures -15°C +55°C
Turbocharger with air cooled intercooler
Double element air cleaner
Air-pre cleaner - cup type
Pre fuel filter
Fuel filter w/ water separator
Automatic/manual engine return to idle
Neutral safety start
Emergency stop
Dial type throttle control
Hydraulic System:
2 variable flow piston pumps
Auto/Heavy/Super Power working modes
Auto power boost
Swing priority (swing+arm)
Travel speed change
Selectable working modes
Pre-set auxiliary pump settings
ISO pattern controls
Straight travel valve
100% return oil filtration
Cab And Operator Compartment:
Pre-disposal for the optional cab protection
Pressurized cab heat and defrost functions
Tilting consoles - 4-position
Low-effort controls
Sliding cockpit
Mechanical suspended seat
Arm rest
Sun shade
Color LCD monitor display
Auxiliary select system
Aux-in port for personal electronics (12v)
Rubberfloormat
One-piece right hand window
Two piece door window
Roof top openable metal window
Windshield wiper / washer
Storage compartments
Anti-theft device
On-board diagnostic system
Standard handrails
Sliding front window – storable lower windshield
Rh front console w/ clock and cell phone holder
Rear mirror (mounted on cab)
Glow-plug pre-heat
Equipment And Undercarriage:
5,70 meter boom
Two lights on cabin top
One light on tool box
HD Bucket linkage Refuel pump
Tool box
Sealed and lubricated tracks
Single track guide
600mm triple grouser steel shoes
Rear mirror (mounted on tool box)
Main Features:-
High Precision And Controllability:
High performance and smooth control.
The CASE Intelligent Hydraulics System is the result of continous research of perfection of a legendary brand. CASE is synonymous and reference in the market for its fastest cycles times, best energy saving performance and smooth control.
High Efficiency:
Up to 4% more fuel efficiency due to hydraulic system control and 6% better efficiency from FPT engine.
5 energy saving controls & ECO gauge function enable the continuous monitoring of the fuel consumption.
High Reliability:
Robust design.
Increased plate thickness on HD structures and HD attachments to improve durability.
Lower cost of ownership.
With the CASE World Class Manufacturing.
Comfort And Safety:
Spacious and safe cab.
Low noise and vibrations.
Ergonomic workstation.
Real time parameters monitoring.
With the newly designed cab, fully adjustable seat, joysticks and 7” LCD monitor.
Outstanding Visibility:
Safe and fast operations.
More comfort.
With wider glazed area.
Fast Cycles:
Higher breakout force.
Continuous operations.
Up to 10% higher digging capability.
With A/H/SP working modes and Auto Power boost
High Versatility:
The perfect machine for every application.
With 3 available power modes and 10 auxiliary hydraulic settings.
Low Total Cost Of Ownership:
Longer service intervals.
Reduced downtimes.
