LCD Thermal Imager
240,000 Per Piece
Brand Name : SONEL
Temperature Range : Range 1: -20 DegreeC - 150 DegreeC Range 2: 150 DegreeC - 650 DegreeC Range 3: 650 DegreeC-1500 Degr
Resolution : 192x144
Accuracy : +-2 Degreec Or 2% Of Reading (for Ambient Temperatures Between 15 Degreec And 35 Degreec And Object
Display : LCD
Spectral Range : 8
Model : KT-200
Visualization : 1
Humidity : 10% - 95%
Operating Temperature : -10 DegreeC - 50 DegreeC
Storage Temperature : -40 DegreeC - 70 DegreeC
Thermal Sensitivity : 50 mK
Pixel Size : 25 MP
Focusing : Manual
IFOV (Standard Lens) : 3.45 mrad
Minimum Focus Distance : 0.5 m
Lens (field Of View/focal Length) : 37.8 Degree*28.8 Degree/7 mm (option: 14.4 Degree*10.8 Degree/19 mm)
Imaging Mode : IR /Visual/InfraFusion MIF/PiP
Zoom : 1.1 - 4
Image Analysis Mode : 5 Points,2 Lines,5 Areas. Temp. Readings: Min.,Max.,Mean. Isotherms. Temp. Difference Alarm Temp
Palettes : 8
Emissivity coefficient : Adjustable From 0.01 To 1.00 Or Taken From The Material List.
Measurement correction : Settable Distance,Relative Humidity,Ambient (reflected) Temperature
Photo Image Format : JPG
Notes to IR Photos : Audio (60 Seconds),Text,Graphic,Photo
Report module : PDF Reports,Report Printing Through Wi-fi
Video File Format : AVI,IRV (including information on temperature)
Built-in Functions : Visual Camera 5 MPIX,Led Torch,Laser Pointer,Microphone,Speaker.
Wireless communication : Wi-Fi
Interfaces : Micro SD Card Port,Mini HDMI,Micro USB 2.0
Power supply : Li-ion Battery (operating Time >4 Hours),Built-in Charger,Ac 110-230 V (50/60 Hz) / 12 V Power Su
Shock/vibration Resistance : 30g 11 ms (IEC 60068-2-27) / 10 Hz
Housing : IP54
Dimensions (with Standard : 274 mm x 106mm x 78 mm
