L x w, cm (in) (CONTROL CONSOLE)195 x 65 (76.8 x 25.6)
DIMENSIONS (HXWXD) CM, (IN) (DISPLAY)217 x 52 x 22.5 (85.4 x 20.5 x 9) stand, 196 x 70 x 34 (77 x 27.6 x 13.4) generator
Dual Bucky System: Small 18 x 24 and Large 24 x 30
Generator: High Frequency X-Ray Generator
Tube: Dual Track Molybdenum/Rhodium X-Ray
Focal Spots: .01mm and .3mm Focal Spot Sizes
Exposure Modes: Three Exposure Modes (Automatic
Optimization of Parameters (AOP), Fully Automatic, and AECSemi Automatic/Manual
Magnification: 1.3 and 1.9 Magnification Factors – Single Platform
Telescopic Motorized Positioning Column: Command Buttons
Located on Each Side and Top of the Column for Easy Access
Digital Display: Compression Pressure, Breast Thickness, Size
of X-Ray Field, and Magnification Factor
Foot Pedals: Motorized Compression Controlled by Two
Compression/Decompression Foot Pedals with Manual Fine Tunning
Compression Paddles: Slide Mount for Stability/Easy of Mounting
System Also Includes: Image Receptor, Control Console,
Lead/Glass Operator Radiation Shield, Face Guard, Operator
Keyboard/Console, DataFlash Patient ID System, Operator
Generator
High-voltage wave form: Multipulse
Exposure voltage : 23kV to 35kV, adjustable in increments of 1kV
mAs range : Mo X-ray tube: 2mAs to 560 mAs (mAs-mode)up to 600mAs (AEC-mode)
Mo/W X-ray tube : 2mAs to 710 mAs (mAs-mode) up to 752 mAs (AEC-mode)
Exposure times : From 10 ms to 4s , From 10 ms to 7s for magnification techniqueAutomatic exposure control
Automatic exposure control (AEC): Microprocessor controlled, transparency compensation
Detectors: Semi conductor detector
Accuracy of optical density (2-6 cm): ± 0.15 OD from the mean optical density for predefined film screen combinations (separately for each grid table, magnification table and anode-filter combination at appropriate clinical kV).
Density correction : ± 3 exposure points, adjustable in 1/8 step increments
Film-screen combinations : 2; User selectable on the generator control panel (H/D).
