• Max. 2M (1920 x 1080) resolution
• 16 : 9 Full HD (1080p) resolution support
• 4.4 ~ 140.8mm (32x) IR corrected optical zoom,
16x digital zoom
• H.264, MJPEG dual codec,
Multiple streaming
• Day & Night (ICR), WDR (120dB)
• Auto tracking, Intelligent video analytics
• SDSDHCSDXC memory slot,
Bi-directional audio support
• IP66, IK10, IR LED (2ea)
14" Sony Interline Transfer CCD
420 TV Lines
Day & Night (DSS)
22x Optical Zoom, 10x Digital Zoom
3.6~79.2mm (F1.6) Focal length
64 Presets Positions
5 Tours (16PresetsTour), Auto Pan, Auto Flip.
"Auto Flip" rotates dome 180˚ at bottom of tilt travel
Built-in surge and limited lightning protection
Video
Image Sensor 14" Sony Interline Transfer CCD
Signal System PAL : 625 lines
Scanning Frequency(H) 15.625kHz
Scanning Frequency(V) 50 Hz
Sync. System InternalExternal (Line Lock, VD Lock)
Total Pixels Number 795(H) x 596(V) 470K
Effective Pixels Number 752(H) x 582(V) 440K
Horizontal Resolution Horizontal : 420 TV Lines
Video Output Level 1.0 Vp-p (75 Ohms, composite)
SN Ratio More Than 48dB (AGC Off)
Lens 22x Optical Zoom (F1.6, f=3.6~79.2mm) Video AF
Digital Zoom Ratio 10x (Total Zoom Ratio : 220x), 2x ~ 10x Variable
Angle of View Horizontal : 47 degree (wide) 3 degree (tele)
Min. illumination 0.5 Lux (DSS)
Day & Night System Digital Slow Shutter (DSS)
ZoomFocus Preset 64 Mode Set (Store Internal EEPROM)
Electronic Shutter Speed 150 ~ 110,000sec (8 steps)
OSD Menu On Off
Color BW On Off
Sharpness Control Manual (Up ~ Down)
Focus Mode Auto Manual
Brightness Control Manual (Up ~ Down)
Mechanical
Pan Movement 360˚ continuous pan rotation
Vertical Tilt Unobstructed 0˚ ~ 90˚ Manual PanTilt Speed
Pan 0.5˚ ~ 200˚Sec manual operation
Tilt 0.5˚ ~ 128˚Sec manual operation
