Bench Center Dealers

We offer a vast range of superior quality bench centres, which are extensively used for general inspection work in metrology laboratories and other industries. Our range includes cast iron bench centre, mini bench centre ,vertical bench centre, universal bench centre and many other. These bench centres are known for delivering better durability, reliability and performance in the defined operations. Further, we also customize these bench centres as per the specific demands of clients. Our range of bench centres includes cast iron bench centre, vertical bench centre, mini bench centre cast iron base, mini bench centre granite base, universal bench centre, surface plate with bench centre and bench vise. Backed by a team of experts, we are offering a qualitative range of cast iron bench centers that are accurate and quick method for inspecting radial run out of camshafts, crankshafts and cylindrical shafts. Manufactured as per IS: 5980-1978, these cast iron bench centers are utilized in machine shops, tool rooms and standard rooms for checking various parameters such as concentrically , parallelism and true rotation of components. The bench centers manufactured at our works are made up of close grained cast iron and finished to higher degree of accuracy by hand scrapping.   Made By : Luthra Made In : Indian

We are offering cast iron bench centre. Gmt cast iron bench centre - the base is made of close grained cast iron, heavily ribbed and stress relieved. The checking centres consist of head stock and tail stock. Head stock spindle is made up of nickel-chromium steel, case hardened and ground. Centres are made up of tool steel and ground.

Sizemm:150 x 75, Centre distancemm: 150, Centre height mm 75, Accuracy in microns um 10, quality product which is not what we put into it, but quality is what the customer gets out of our products.

We are offering precision bench centre. this is a precision bench centre centre height - 60mm between centre - 150mm

Application : Bench center is used to check runout in big cylindrical work piece   Product Details : Graded cast iron Stress relieved working face Unique easy removal and mounting mechanism Hardened centers Precision ground Aesthetic Finish Rugged Construction

• Material: Casting Iron
• Size/Dimension: 100 x 50 mm
• Bed Width: 200 mm
• Bed Length: 300 mm
• Weight: 9 Kg.
• Model Number: MBC-100
• Brand: Minimatic Machines

• Roller Center Distance: 5 mu m
• Brand Name: Micro Flat Datums
• Center Distance: 200 mm
• Height of Center: 75 mm
• Center Distance of Sine Rollers: 400 mm
• Co-Axiality of Centers: 5 (mu m)
• Parallelism of Axis: 5 mu m

• Material: Cast Iron
• Features: Aesthetic Finish,Rugged Construction

• Material: Cast Iron
• Color: Blue & Silver
• Country of Origin: Made in India
• Brand: Luthra
• Grade: A
• Size/Dimension: 200 x 50 mm
• Surface Finishing: Chrome Polished
• Model No.: MBC 200
• Bed Length: 450 mm

WORKING PERFORMANCE co axiality-0.0010/300M Range of admit between centre :upto 2000mm. Application Measuring co-axiality& faceout,inspectionof automative components like cam shaft

• Admit Between Centre in mm: 300
• Centre Height in mm: 125

Bench Centre:Made generally as per IS: 5980-1978. Made from good quality of Castings with high Density Alloyed Cast Iron castings conforming to Grade FG-220 of IS: 210. Stress Relieved Hand Scraped Surface. The centres are having such design that on placing at any centre distance, they remain aligned. All the centres are provided with carbide Tipped dead centres.

• Material: Cast Iron
• Color: Blue
• Country of Origin: Made in India
• Brand: LUTHRA
• Center Distance: 300 TO 500 mm
• Grade: 1
• Height Of Center: 80 mm

Surface table and centre heads are made from closed grained iron castings, seasoned, stress releaved and finished on the working face and reference side edge of the table by hand scrapping to meet with the required accuracy's as per ISI Standards. The centre stock spindle bearings are smooth lapped to ensure accuracy of the spindle height and relationship to reference side edge. The centres are hardened high carbon steel accurately ground on the diameter and conical point. One centre is spring loaded to accommodate small variations in component length. Tee slot at 450 angle on the surface table and teebolt through hole at the base of the centre stocks to ensure firm engagement with the reference side edge of the table. Each centre stock can be locked in any position along the tee slot by means of knurled hand knobs.

Precision Bench Centres - Overview JASH Inspection Bench Centres are ideal for precision inspections and checking various parameters like concentricity, facial and radial run out etc. in tool room and machine shop. Get high quality precision bench centres from the leading manufacturer and supplier of precision tools. Salient Features Made generally as per IS: 5980 - 1978. Cast Iron Base made from plain cast iron conforming to grade FG:220 of IS 210. Castings stress relieved as a precaution against distortion Precision Bench Centres with Granite Base are also offered, with metallic (Cast Iron) T-slots. One Centre is spring loaded for easy loading and unloading and also ensure uniform pressure on work piece. Extra accessories offered on request, at extra cost: Roller guide attachment for heavy jobs. Stub Centres for inspection bench. Carbide Tipped dead centre. Taper and parallel test mandrels. Concentricity Checking Attachments for inspection bench centre. Steady rest for extra long and heavy jobs Sliding Fixture for mounting dial stand and magnetic base Standard Sizes of Precision Bench Centres Standard Sizes:Admit between Centre (ABC): 300 mm, 500 mm, 750, 1000 mm, 1250 mm, 1500 mm, 1750 mm, 2000 mm, 2500 mm and 3000 mm.Height of Centre (HC): 125 mm, 160 mm, 200 mm, 250 mm and 300 mm. Other sizes can be offered on request.

We are offering bench centres. Bench centres for checking the concentricity of the shaft or similar items with centre height of 150mm onwards. ‘t’ slots are provided for easy sliding movement of bodies (checking centre) by means of tenon base.

• Material: Cast Iron
• Color: Pink
• Country of Origin: Made in India
• Roller Center Distance: 5 Microns
• Brand: Micro Flat
• Center Distance: 300 mm
• Height of Center: 75 mm
• Center distance of Sine Rollers: 400 mm
• Co Axiality of Centers: 5 Microns
• Parallelism of Axis: 5 Microns

• SIZES MM: 300 x 125

We are leading supplier of Granite Base Bench Center. We are among one of the paramount companies that is preciously engaged in engineering industries in offering most outstanding product Granite Base Bench Center.

GT’ Offers BENCH CENTRES for checking the Concentricity of the Shaft with Centre Height of 150mm Onwards. These centers are very useful in the Inspection Departments.Specifications :BENCH CENTRES for checking the Concentricity of the Shaft or similar items with Centre Height of 150mm Onwards. ‘T’ Slots are provided for easy sliding Movement of Bodies (Checking Centre) by means of Tenon Base.   Both the bodies are adjustable to the required position and the extra fine setting screw facilitates Easy and Quick setting of the required distance between centers. The other feature is Locking of Retractable sleeve at the time of Inspection. Bench Centre can be placed on M.S. Fabricated Stand with Levelling Screws and the Inspection work can be carried out easily. Clamping of the bodies in position is positive And alignment is maintained by means of tenons along the ‘T’ Slots placed in front. The Rear ‘T’ Slot is meant for holding attachment and fixtures and its optional. We also offer Bench Centre Fitted with Chucks, These are specifically designed for users application.

Bench Center, pushpull gauge, Surface Plate, Vernier Calipers

bench centers, Granite Surface Plates, Cast Iron Surface Plates

We offer a vast range of superior quality Bench Centres, which is extensively used for general inspection work, in metrology laboratories and other industries. Our range of Bench Centres includes cast Iron Bench Centre, Mini Bench Centre, Vertical Bench Centre, Universal Bench Centre and many others. Bench Centres provided by us are known for delivering better durability, reliability and performance in defined operations. Further, we also customize Bench Centres as per the specific demands of clients. Highlights Dimensional accuracyWell-constructedReasonable pricesHigh level of performance
