Electric Heater Coil / Industrial Heating Coils Dealers

Being an illustrious Supplier of Coil Heater, we endeavor to achieve 100% customer satisfaction. Maintaining the set industrial standards, we make sure that the range is as per the requirements. The offered Coil Heater is available in a length of 20cm.

These finned tubes have fins made of wire instead of strips. Continuous loops of wire are formed and are continuously soldered to the circumference of the tube to ensure 100% contact. Loops per turn and turns per foot can be altered as per surface area requirements. Due to continuous soldering of wire loops these finned tubes offer a very high heat transfer efficiency with less air pressure drop.  Maximum Operating Temperature-175 °C: a)Tube Diameter : 5/8’’ to 1” (15.8 mm to 25.4 mm) Tube Material : Carbon Steel / Stainless Steel / Copper b) Tube Size : 5/8” – ¾” (15.87mm – 19.05mm) Wire Material : GI Wire / Stainless Steel Wire / Copper WireWire Thk. : 0.7mmLoops per Turn : 58 – 90 Nos. per turn.Turns per foot : 36 – 66 Turns per foot. ApplicationUsed in air cooled Oil Coolers in thermo Pac units and also used for Air Heating applications

Nozzle coil heaters are similar to the coil heaters but with a bigger cross section and the option of brass collet and clamping band over the heater to ensure perfect snug fit onto the nozzle for the efficient heat transformation. The problem of material spillage results in frequent failure of mica nozzle heaters, where as these heaters are robust in such conditions. Features Available with nickel chrome steel band Temp range for upto 400 deg C Option of J type or K type thermocouple available on request Negligible effect of material spillage Minimum inner diameter of 25mm Application Injection and blow moulding Process engineering Extend nozzles

We manufactures water wall Membrane panels for boiler furnaces and convection passes as per accepted engineering practices and tolerance in dimensions and are maintained as per na-tional & international codes Special points of interest: Shortest radius band: 38.1mm ODx3.6 thkx38 mm radius.
