HT Motor Dealers (72 products available)

Vacuum impregnation is the most important process for electrical insulation. CEE DEE VACUUM designs, manufacture and installs vacuum pressure impregnation plants suitable for all types of impregnation varnishes, oils, resins etc. The plants are useful for impregnation of LTHT motors, generators coils, HV motors. The system can be designed for special applications like silver nitrate impregnation, carbon impregnation etc. In this case, the pressure applied is critical and needs special care.

By keeping track of current market developments, we bring forth a qualitative assortment of HT Motor. Our offered range is widely used in the electrical industry for meeting various applications. This motor is designed using basic raw material and technically advanced tools under the guidance of skilled professionals. Before the final dispatch from our end, the entire range is well tested upon several parameters.

The Impak range has been designed to provide the maximum variety of cooling forms and enclosures, whilst still utilising standardised electrical components. Two stator frames have been developed for each frame size : a horizontal foot mounting frame, mounting designation IM 1001, and a vertical flangeskirt mounting frame, mounting designations IM30113611. The horizontal foot mounting frame has an open top with Impak high voltage range Frames 355, 400 & 450 machined faces to accept the cover or heat exchanger. The vertical flangeskirt’ mounting frame has two open sides with similarly machined faces. The specified range of cooling forms and enclosures is available on each mounting arrangement. The first part of this publication details the mechanical features while the second part deals with electrical information.

• Power: 2150 kw
• Phase: Three Phase
• Voltage: 415 V AC
• Mounting Type: Foot Mount
• Ambient Temperature: 50 Degree C
• Frequency: 60 Hz
• Speed: 12075 rpm
• Usage/Application: Industrial
• Insulation Class: F/H
• Winding Material: Copper
• Body Material: Cast Iron

• Wire Range: 10 SWG to 30 SWG
• Maximum Diameter of Coil: 0 mm
• Winding Speeds Approximate: 0–3000 R.P.M
• Main Motor: 2/1.75/1440/Three

We are using 2 type of Servo motor and Drive packages to achieve Winding and Unwinding operation.Traverser will be unique design with LM Guideways and Ballscrews integrated with 1:1 connection of the servo motor.Control panel to house Drives and Operator Panel with 4 line HMI for Operator Interface. Uncoiler will be provided with brake chopper and brake resistor for maintaining Tension. Wire break is detected by Proximity switch. Complete operation will be controlled by ABB frequency Drive PLC unit with 3 inch HMI display. HMI will be placed in operation panel and Main PLC in the main control panel.

With our immense domain expertise, we are involved in offering H. T Electric Motors. Used in many industries for preparing various machines, these motors are manufactured using the best quality components and cutting edge technology at vendors’ end in line with industry norms. Apart from this, we provide these motors in different sizes and designs as per the needs of our clients. Our quality examiners test these motors against varied quality examiners.

3.36.611 KV   Capacity : 200 HP to 2500 HP in various RPM

Initial technical know-how for the manufacturing operations came from Brush Electrical Machines Ltd., U.K. Later Crompton Greaves entered into a technical collaboration with Hitachi Ltd. Japan - the world leaders in Induction Electric Motors. The division also has extensive links with prestigious institutions of higher learning and research like IIT Mumbai, IISc Bengaluru, and TCIRD Patiala etc. Today the division can supply Induction motors of ratings up to 10,000 kW with superior designs and enhanced reliability features for applications in a Thermal Power Plant. Application for the range of motors include Boiler Feed Pumps, Circulating Water Pumps, Induced Draft Fans, Forced Draft Fans, Primary Air Fan, Secondary Air Fan, Condensate Extract Pump, Crushers, Coal Mills Conveyer and Ash Slurry Pumps. HT Motors of Crompton Greaves offers benefits of easy installation, low noise levels, easy maintenance, great energy savings low vibration levels and high efficiency even at part loads.

• frame size: 355-630

HV three phase induction motors (frame size 355-630) & HV wound-rotor three phase induction motors (frame size 355-630) are produced combing with the design and manufacture experience of long-term and steady producing high voltage motors. These motors are adopted new technique, material and technology. With the material chosen exquisitely and the products excellent workmanship, such motors are engineered with many remarkable features such as high efficiency, energy saving, low noise, small vibration,lightweight, reliable performance, easy mounting and maintenance etc.

Standards:BS 5000IS 4722, Insulation:Class FClass H, Armature Voltage:110 to 1000 Volts, Field Voltage:180 to 360 Volts, Cooling:IC 010600410666W37A861744, Protection:IP 234454.

We offers a wide range series of YVF/YSP series high tension motors with improved energy efficiency and life cycle value.

• Voltage: 230-66000 V
• Frequency: 50 Hz
• Phase: Single Phase
• Finishing: Paint Coated
• Material: Mild Steel
• Automation Grade: Automatic
• Type of Motor: AC

• Power: 0.5 MW
• Phase: Three Phase
• Frequency: 50 Hz
• Speed: 3000 rpm
• Voltage: 11 kV
• IP Rating: IP55
• Mounting Type: Foot
• No. of Poles: 2

• Voltage: 0.38 kV
• Mounting Type: Foot
• Frequency: 50 Hz
• Phase: Single / Three Phase
• No. of Poles: 4

• Voltage: 300
• Phase: Three Phase
• Frequency: 50/60 Hz
• Power (Watts or HP): 185kW

The Impak range has been designed to provide the maximum variety of cooling forms and enclosures, whilst still utilising standardised electrical components. Two stator frames have been developed for each frame size : a horizontal foot mounting frame, mounting designation IM 1001, and a vertical flangeskirt mounting frame, mounting designations IM30113611. The horizontal foot mounting frame has an open top with machined faces to accept the cover or heat exchanger. The vertical flangeskirt’ mounting frame has two open sides with similarly machined faces. The specified range of cooling forms and enclosures is available on each mounting arrangement. The first part of this publication details the mechanical features while the second part deals with electrical information.

All sizes and HP, 110 -415 Volts AC motors, 110-600 Volts DC motors.Rebuilding of AC and DC electric motors from small to 1500HP (1.5KV),Dynamic Rotor Balancing (SynchronousNon Synchronous),Generator (StatorRotor) Rewinding and Repair.

Repair and Rewinding of Stator of 4000KW, 6.6KV HT Motors for Dr.NTTPS,APGENCO Repair and Rewinding of Stator and Rotor of 1250KW, 6.6KV Motors for M-II NLC, Neyveli. Repair and Rewinding of Stator and Rotor of 1250KW, 6.6KV Motors for Chennai Port Trust. Re-Insulation of 1000KW Motor 6.6KV Stator for SETNEB, ETPS ,Ennore. 2000KW,3.3KV Motor Rotor Bar Replacement for M-I, NLC, Neyveli. 800KW,3.3KV Vertical Water Pump Motor Repair for Thermal Power Station,NLC Ltd, Neyveli. 750KW,3.3KV Motor Stator and Rotor Rewinding for NLC Ltd, Neyveli. 630KW,6.6KV and 630KW,3.3KV Motor Stator and Rotor Rewinding work for SEETPS, TNEB, Ennore and NLC M-I, M-II.. 500KW,6.6KV Motor Stator Re-Insulation work for CEMTPS,TNEB, Mettur Dam. 420KW,6.6KV Motor Stator Rewinding work for BHEL SSTP Trichy and NLC M-I & II. 300350KW 3.3KV Motor, Stator and Rotor Rewinding work for Chennai Port Trust and NLC M-I& M-II.
