Load Frame Dealers (36 products available)

Specifications : The Unit is designed for a maximum load of 5000 kg. and consists of a two speed screw jack mounted in a frame with identical top and base channel pieces so that the unit can be placed either way up and the device can be used for loading from above or from below whichever is convenient. This is a floor model.

We use quality-approved raw materials as inputs for the production of our finished goods. The selection procedure of the raw materials is conducted by our expert quality auditors. Capable of catering to the varied demands of the customers, we are named amidst the respected Suppliers of Load Frame.   Specifications : Load frame s scrically cum manually operated having constant rate of strain 1.25mm per minute use ful for CRB, Unconfined or triaxial shear Test. As above but three tates of strain 1.25mm. 2.5mm and 1.50 mm per minute. As above but 6 rates of strain between 1.25mm minute to 0.0004mm per minute.

We are a name of repute in manufacturing and supplying Load Frames of superior quality at reasonable rates. The Load Frames we export are available in two models. LOAD FRAME MOTORISED CAPACITY 50KN HAVING 8 SPEEDS FeaturesTwo Pillar typeDetachable FrameEnclosed Motor and Gear SystemIndicatorSpeed ChartUseful in Triaxial and C.B.R. testComponentsCabinet which housed the electrical motorReduction gear the loading is done by the upward movement of the lower plate which is firmly fixed to the lead screw. When the lever is set in the neutral position , it isolate the lead screw from the rest of the drive mechanism, and the lead screw ca n then be manually moved up or down by operating the handle.A main switch, an indicator and a forward reverse switch are fixed on the unit.A relay is fitted inside the cabinets that in case of power failure, the unit will not restart of its own on the resumption of power, unless the switches are operatedThe adjustable cross head can be set at any desired position or height over the two pillars and secured in position by tightening the adjustment nut. It has a hexagonal adaptor.Its rates of strain are 0.0 2 5mm. /min, 0 .0 5mm/min , 0 .0 5mm/min , 0.0 6 2 5 , 0 .1 2 5mm/min , 0 .0 2 5mm. /min , 0 . 0 2 5mm. /min , 0 . 5mm/min, 0 . 6 2 5mm. /min and 1.2 5mm. /min.Suitable forOperation on 230 volts,5 0 cycles , single phase ,A.C. supply LOAD FRAME MOTORIZED CAPACITY 50KN WITH 3 RATES OF STRAIN. Technical detailsTwo pillar typeDetectable frameEnclosed motor and gear systemIndicatorUseful tri-axial and C.B.R testElectrical motorReduction gearAdjustable crossheadMain switch, forward reverse and reverse switch fixed on the unitRelay is fitted for power back-upHexagonal proving ring adaptorRate of strain are 2 .5mm./min, 1.5mm/min and 1.2 5mm. /minUsed inConstruction industryChemical industrySoil-testing purpose

We are offering structural loading frame for educational.

• Brand Name: Quality Engineering Corporation
• Weight: 5000 kg.
• Plae of Origin: Roorkee
• Usage: Loading from above or from below
• Specifications: Customized

We can be contacted for purchasing Hand Operated Load Frame as per the requirement. Our Hand Operated Load Frame is a lightweight frame designed for application of penetration load in Laboratory or field CBR tests on soils, and compressive loads in triaxial shear test. Featuring a sturdy construction, our Hand Operated Load Frame can bear up to 5000 kg. It consists of a two speed screw jack mounted in a frame and with identical top and base channel pieces. This arrangement ensures that the unit can be placed either way up and the device can be used for loading from above or from below as per the requirement. We make available Hand Operated Load Frame in customized specifications at the best market prices.

Motorised Bench Type Load Frame : Alpha Chem is manufactures,exporter & suppliers Motorised Bench Type Load Frame. Motorised Bench Type Load Frame : This is a portable load frame which can easily be kept on Laboratory bench. Thus it is very convenient to the user to conduct tests. A motorized screw jack is fixed at the base to which are fixed two vertical pillars which can be easily dismantled. A circular platen of 150mm diameter is fixed to the lead screw and loading and unloading is effected by upward/downward movement of the lead screw using a forward/reverse switch. The cross head is adjustable at any desired height and carries an adapter for Proving Ring. An adjustable dial gauge bracket is provided on one of the pillars . The rate of strain is constant 1.25mm/min. Operates on 230 Volts AC.

Motorised Bench Type Load Frame : Alpha Chem is manufactures,exporter & suppliers Motorised Bench Type Load Frame. Motorised Bench Type Load Frame : This is a portable load frame which can easily be kept on Laboratory bench. Thus it is very convenient to the user to conduct tests. A motorized screw jack is fixed at the base to which are fixed two vertical pillars which can be easily dismantled. A circular platen of 150mm diameter is fixed to the lead screw and loading and unloading is effected by upward/downward movement of the lead screw using a forward/reverse switch. The cross head is adjustable at any desired height and carries an adapter for Proving Ring. An adjustable dial gauge bracket is provided on one of the pillars . The rate of strain is constant 1.25mm/min. Operates on 230 Volts AC.

• Voltage: 230 V
• Phase: Single Phase
• Frequency: 50 Hz
• Brand: Enkay Enterprises
• Platen Diameter: 150 mm
• Capacity: 2000 Kg

Perfectly Balanced Load Cell arrangement with frame and HX711 interface ready to use with nay of the microcontrollers.

Load frames are extensively used for application of compression and penetration loads required for various tests. Load frames are available in different frame structures, mode of operation, loading capacities.

• Material: Stainless Steel
• Phase: Single
• Surface Finishing: Polished
• Power Source: Electric
• Frequency: 50-60 Hz
• Voltage: 240 V

LOAD FRAME, Motorised cum hand: Tow pillar type 4 speeds: Ideal for use inmobile laboratory as it is light weight & sturdy. This Load frame is designed for conducting Unconfined, Triaxial CBR and other routine tests. Loading system comprises of a screw jack with detachable handle. The lower platen moves up and down. The top bracket is adjustable for vertical clearance and has an adapter for connecting standard Proving ring. A dial gauge mounting bracket is provided on one to the two pillars. Rate of train 1.25, 1.50 & 2.50 mm/min. Suitable for operation on 220V, 1 Phase 50 cycles, AC supply.

• Voltage: 240 V
• Material: Stainless Steel
• Phase: Single
• Surface Finishing: Polished
• Power Source: Electric
• Frequency: 50-60 Hz

Load Frame which we make available is the best in the industry. Our Load Frame is motorised and is electrically operated. A commendable feature of our Load Frame is its capacity of 5 Ton. This makes it best suitable for C.B.R and triaxial shear testing on soils. Load Frame is composed of a cabinet. Functioning Of Load Frame Loading is practiced with an upward movement of lower platenOn setting the lever in the neutral position, Load Frame automatically isolates the lead screw from other drive mechanism

• Country of Origin: India
• Brand Name: UMI

structural loading frame - 50, 100, 200, 300, 500 ton capacity - for educational training purpose

• Power Source: Electric
• Warranty: 1 year
• Application: Water Well
• Power Type: Diesel
• Lead Time: 4-6 weeks
• As per Order: Pumping Testing Unit

Being a reputed company, we are offering an encompassing gamut of Loading Frame with Pumping Unit. The given product is inspected by our quality experts on diverse parameters so as to assure its flawless range. This product is developed from the top notch material and latest techniques in fulfillment with international standards. Our valuable customers can easily avail this product from us in a given time frame at industry leading rates.   Features: Precisely designed Reliable operation Smooth functioning Specifications: vertical size- ht- 2700 x wth- 1500 mm x Bridth-400 mm ,with surrounding peripheral vertical platens in side the 400 x 400 mm 'c' channel inner heavy duty stiffened by in side heavy duty 60 x 60 mm squire roads contentiously welded together with the channel section, in the center of 10 mm platen, also top and bottom 'c' section are cross stiffened by 60 mm square road perpendicular to horizontal welded square road Top horizontal beam is customize to move up and down which will be sheeted through its nut and bolts unlocking Even all four inner sides of 10 x 500 mm platen will be designed customize by giving 12 mm holes at every 6" intervals to locate, fix every things at desire level and height vertically and horizontally All the platens are duly welded with heavy duty electrical weld joint with specifics materials welding roads and complete frame will be tested upto full load of 50 ton

Load Frames are used to apply load on the test specimen. The capacity and speed depends on the requirement of a particular test. Load Frames are used in C.B.R. Triaxial, Unconfined Compression Test etc.The Unit is designed for a maximum load of 5000 kg. and consists of a two speed screw jack mounted in a frame with identical top and base channel pieces so that the unit can be placed either way up and the device can be used for loading from above or from below whichever is convenient. This is a floor model.

• Material: Cast Iron
• Voltage: 230 V
• Phase: Single Phase
• Country of Origin: Made in India
• Brand Name: Smarcon
• Color: Blue
• Automation Grade: Manual
• Power: 5 W

• Material: Stainless Steel
• Condition: New
• Automation Grade: Automatic
• Model Number: BSC296
• Brand Name: Bestco

This unit consists of a cabinet which houses the gear system and motor mounted on a sturdy angle iron base. The loading is done through the bottom loading plate which is carried on a lead screw. The advancement of this lead screw is secured against rotating by a sliding key. The top bracket is adjustable in height and carries a hexagonal adaptor for taking standard proving rings. The instrument is fitted with a motor operation on 220/230 volts, single phase, 50 cycles A.C. supply.This is for evaluating the strength of soil on field exploration or construction site and in the preliminary laboratory studies.It gives directly the unconfined strength.

Load Frames (AIM 062-1, AIM 064, AIM 064-E, AIM 065, AIM 066)   Load Frames are Loading devices employed for application of compression and penetration loads required for various tests, such as Unconfined Compression Test, Triaxial Shear Test, California Bearing Ratio Test etc. The load application is effected by advancement of a lead screw secured against rotation by a sliding key and is measured with a Proving ring or Load Cell. Aimil manufactures a wide variety of Electro Mechanical to Microprocessor Load Frames with different designs of frame structure, modes of operation (manual or electrically driven), loading capacities, speeds of travel, so that appropriate selection is possible to meet the requirements of standard methods used for various tests to cover different soil types and sizes of specimens.Ordering Information :AIM 062-1         Load Frame, Motorised Three                           Speed, 50 kNAIM 064             Load Frame, Motorised, 30 speeds,                           50 kNAIM 064-E         Load Frame, Motorised, 50 kN                           Microprocessor BasedAIM 065             Load Frame, Motorised, 12 speeds,                           200 kNAIM 066             Load Frame, Motorised, 12 speeds,                            500 kN   Application General Purpose CBR, Triaxial tests, Traixial and CBR tests, Traixial test on rocks Unconfined Compression test on medium & Coarse grained stablized soil, Triaxial, CBR & Unconfined Compression test. Industry Chemical/Process Agricultural Civil Infrastructure Dams & Tunnels Geophysical/ Seismology Testing Geotechnical (soil/ rock) Testing Irrigation Mining Real Estate Roads, Highways & Bridges Education Architecture Building Technology Civil Department Geotechnical Mining Engineering Science Colleges Traffic & Transportation Railways Roads, Highways & Bridges

• Features: Rugged construction, Two fixed speed easily selectable by frequency changer, Upper beam can be adjusted in height
• For CBR Test: 1.27mm/min
• For Marshall test: 50.8 mm/min
• Power supply: 230V, 1 phase,750W
• Weight: 130Kg

Load Frames are Loading devices employed for application of compression and penetration loads required for various tests, such as Unconfined Compression Test, Triaxial Shear Test, California Bearing Ratio Test etc. The load application is effected by advancement of a lead screw secured against rotation by a sliding key and is measured with a Proving ring or Load Cell. Aimil manufactures a wide variety of Electro Mechanical to Microprocessor Load Frames with different designs of frame structure, modes of operation (manual or electrically driven), loading capacities, speeds of travel, so that appropriate selection is possible to meet the requirements of standard methods used for various tests to cover different soil types and sizes of specimens.

Glass Frame (Load), Pass auto Rear Door, Trey Side Falka Tata ACE Body Parts

side spring loading trial frame, aluminium weighted tuning fork

Triaxial Load Frame, Rust Prevention test apparatus
