Mass Mixer Dealers

Mass Mixer Uniform Mixing Process Technik for Dry & Wet Granulation Application & Process : The Mass Mixer is designed for uniformly mixing of dry and wet material and especially suitable for powder of Pharmaceuticals, Food, Herbals, Agro Chemicals & Chemicals. The mass mixer consists of a rigid fabricated structure motor, gear box, mixing drum, stirrer and tilting device. Specially designed self adjusting sealing arrangement of unique design is provided to ensure that no black particle enters into the mixing drum. The material under mixing process can be monitoring through acrylic dust cover and its controls dusting and contaminations. The tilting device is provided to make easy the unloading of the material and easy cleaning of the mixing drum. Salient Features : Design is cGMP - Current Good Manufacturing Practices compliance. All contact parts AISI 316 & non contact parts AISI 304. Uniform Mixing with paddle blade stirrer. Self adjusting sealing arrangement to avoid entire black particles. Tilting device for easy unloading and cleaning. The interlocked acrylic covers of product container, enclosed drive & Overloads relay protection. Safety Features : Total drive transmission system enclosed Limit switch installed in the top lid ensure lid is closed Overload relay Protection.

The Mass Mixer Machine is basically mixing a assembly where in the mixing stirrer is in horizontal position in the container & have a single speed, simple rotation. The stirrer rotates around itself at a very slow speed inside the bowl and thereby achieving intimate mixing of dry or wet materials of Tablet Granulation, Powder, Chemicals, Food & Confectionaries etc..   SPECIAL FEATURES: Special design feature of machine & stirrer, the mass mixer can be mix the sticky materials & also uniformally and intimately mix the materials which are to be difficult to mix. Range of models to suit working volume 50,100 & 200 Kg. At bulk density of 0.50 gm/cc. All contact parts are made out of S.S.304 quality material. (SS316 provided on demand on extra cost) Compact design requires comparatively smaller floor space. Single stirrer with single speed for dry & wet mixing. As stirrer's sealing comes in contact with product, there may be any black particle contamination problem, after sealing bush got wear & tear. All non contact parts (general structure)made out of mild steel and claded with SS304 or crome plated or made out of SS304 in GMP Model. Contact parts   are polished to the mirror finished and non contact parts are polished to the matt finished in GMP Model. All safety guards & covers made out of SS304   material in GMP model & made out of mild steel & painted in standard model.  General structure & all non contact parts are made out of Mild Steel & same will painted in Standard Model.  All moving parts are enclosed with safety guards. Thrust bearings are provided to carry out rigid thrust load. Easy for cleaning & operating. Simply designed SS304 dust cover provided with one port for material charging & inspection. Interlocking system with top dust cover, to avoid accident, during process. The container tilting system provided for easy unloading of material and easy cleaning. Specially design all moving parts provided with provision of easy lubrication.   OPTIONAL SS316 product contact parts instead of SS304. Variable speed drive or double speed of stirrer provided on extra cost , if required. Flameproof model.

• Application: Industrial
• Material: Stainless Steel
• Phase: Single Phase
• Automatic Grade: Semi-Automatic
• Power: 5.6 kW
• Brand Name: Technic Pharma Equipments
• Capacity: 50-200 kg
• Surface Finishing: Powder Coated
• Speed: 1440 RPM

Mass mixer ideally used for mixing both wet & dry materials to provide uniform mixing. Designed with utmost precision & perfection our offered mass mixers are used for mixing & blending purposes.. The mass mixer is suitable for mixing of wet mass, dry powder, dry powder with wet mass, etc, for the preparation of pharmaceutical mass for preparing tablets and similar other applications. The mass mixer gives through mixing due to its unique blade design and the angle of the blade. Powder & Mass Mixer machines are designed for efficient and homogeneous mixing of dry and wet powders.

• Application: Industrial
• Weight: 100-200kg
• Color: Silver
• Voltage: 220V
• Automatic Grade: Manual
• Power: 1-3kw
• Driven Type: Electric

Salient Features: All contact parts are made of SS 304 (SS 316 optional) Thrust bearings are provided to carry rigid and thrust load. Easy for cleaning and operating. Interlocked acrylic dust cover for inspecting the mixing process. The tilting device provided for easy unloading of the material.   Salient Features:- Mass Mixer - SS 304 Pharmaceutical Mixing Machine All contact parts are made of SS 304 (SS 316 optional) Thrust bearings are provided to carry rigid and thrust load. Easy for cleaning and operating. Interlocked acrylic dust cover for inspecting the mixing process. The tilting device provided for easy unloading of the material.

• Type: Automatic
• Certification: CE Certified
• Voltage: 220V
• Power: 1-3kw
• Driven Type: Electric
• Warranty: 1 Year
• Loading Capacity: 5 Kg to 20 Kg
• Dimension: 900*450*650mm

• Type: ACVFD For Variable Speed.
• Condition: New
• Automatic Grade: Automatic
• Application: Industrial

 All Contact Parts SS 316 / 316L as per cGMP Standard.The laboratory Mixer operates with plough shape type mixing elements and is designed for dry mixing of powders, granules and fibers particle containing products.Differences in volume ranging to 1:1,00,000 can be mixed homogeneously within a few minutes.The drum, unilaterally supported on one sided & it tiltable.The mixing drum made of stainless steel has a removable cover through which the material can be fed and discharged.

We are offering mass mixer machine. Here, you can add new products, along with detailed information. Fill in the details accurately and upload a clear image with a close-up of the product.

We are well-known in the industry as a prominent manufacturer, supplier and exporter of mass mixer machine. Mass mixer machine is used in a number of industries for mixing at the mass level. We specialize in fabricating technically advanced mass mixer machine by utilizing the latest technologies. Our mass mixer machines are demanded across the globe for their superior performance and robust make. Besides, we offer mass mixer machine at very cost-effective prices. brief about mass mixer machine the mass mixer machine is basically mixing an assembly wherein the mixing stirrer is in horizontal position in the container & has a single speed, simple rotation. The stirrer rotates around itself at a very slow speed inside the bowl and thereby achieving intimate mixing of dry or wet materials of tablet granulation, powder, chemicals, and food & confectionaries materials. Because of a special design feature of machine & stirrer, the mass mixer can be mix the sticky materials & also uniformly and intimately mix the materials which are to be difficult to mix. special features range of models to suit working volume 50,100 & 200 kgs. At bulk density of 0.50 gms/ccall contact parts are made out of s.s.304 quality material.(ss316 provided on demand on extra cost)compact design requires comparatively smaller floor spacesingle stirrer with single speed for dry & wet mixingas stirrer's sealings comes in contact with product, there may be any black particle contamination problem, after sealing bush got wear & tearall non contact parts (general structure) made out of mild steel and claded with ss304 or chrome plated or made out of ss304 in gmp model. Contact parts are polished to the mirror finished and non contact parts are polished to the matt finished in gmp model. All safety guards & covers made out of ss304 material in gmp model & made out of mild steel & painted in standard model.general structure & all non contact parts are made out of mild steel & same will painted in standard modelall moving parts are enclosed with safety guardsthrust bearings are provided to carry out rigid thrust loadeasy for cleaning & operatingsimply designed ss304 dust cover provided with one port for material charging & inspectioninterlocking system with top dust cover, to avoid accident, during processthe container tilting system provided for easy unloading of material and easy cleaningspecially design all moving parts provided with provision of easy lubrication optional features ss316 product contact parts instead of ss304variable speed drive or double speed of stirrer provided on extra cost, if requiredflameproof model ideal for mixing of pharmaceutical powderschemicalsfood and confectioneries etc

• Capacity:: 10 – 500 kg/batch
• Power:: 1 – 30 HP
• Purpose:: Mixing
• Applications:: Food industry, ayurvedic industry, pharmaceutical industry
• Materials of construction:: Fully in AISI 304 SS

Mass mixers are ideal for mixing powders with semi solids. Compared to other blenders, the power of motor will be higher in mass mixers. Two types of mass mixers are available in different capacities of handling, namely single trough mass mixer and double trough mass mixer. Double trough mass mixer is 75% expensive than single trough mass mixer, but mixing is faster and handles high volumes easily.

• Application: Industrial

It is suitable to mix dry and wet materials. This mixer has all contact parts made out of stainless steel 304 ISA with mechanical sealing devices to prevent outside lubricant from entering into mixing chamber. SPECIAL FEATURES Easy and strong tilting device. Very thick strong paddles on the main shaft are arranged that through material and uniform mixing is achieved. Reliable and heavy duty gear box, motor and starter are provided with the machine. Capacity-30 kg. to 250 Kg. available. Mechanically & motorized tilting is also available. APPLICATIONS Herbal materials, Pharmaceuticals, Food, Chemicals, Cosmetics, Dyes and Pigments etc.
