OLED Display Dealers

• Color: Black
• Application: Advertisement, Display, Promotion
• Certification: ISO 9001:2008 Certified
• Type: Garment Display Rack
• Country of Origin: India
• Material: Metal
• Size: Multisizes
• Feature: Fine Finish, Heavy Duty, Long Strength

we have the items available in stock!!! please kindly contact via

• Brand Name: Royal Display
• Country of Origin: Made in India
• Emitting Color: Green
• Character Pitch: 5.76 x 10.08 mm
• Character Size: 4.74 x 8.90 mm
• Dot Pitch: 0.96x 1.12 mm
• Dot Size: 0.90 x 1.06 mm
• Number of Characters: 16 Character x 2 Lines
• Active area: 91.14 x 18.98 mm
• View area: 98.0 x 21.0 mm
• Module Dimension: 122.0 x 44.0 x 10.0 mm

• Operating Voltage: 3.3-5V
• Resolution: 128 x 32
• OLED Driver IC: SSD1306
• Text Color: Blue
• Background Color: Black
• Working temperature: -30°C
• Interface: I2C
• GND: Power Ground
• VCC: Power + (DC 3.3
• SCL: Clock Line
• SDA: Data Line

This module is a 0.96 inch blue OLED display module. The display module can be interfaced with any microcontroller using SPI/IIC protocols. It is having a resolution of 128×64. OLED is a self light-emitting technology composed of a thin, multi-layered organic film placed between an anode and cathode. In contrast to LCD technology, OLED does not require a backlight. OLED possesses high application potential for virtually all types of displays and is regarded as the ultimate technology for the next generation of flat-panel displays. OLEDs basic structure consists of organic materials positioned between the cathode and the anode, which is composed of electric conductive transparent Indium Tin Oxide. The organic materials compose a multi-layered thin film, which includes the Hole Transporting Layer, Emission Layer and the Electron Transporting Layer. By applying the appropriate electric voltage, holes and electrons are injected into the EML from the anode and the cathode, respectively.       Resolution: 128 x 64 Visual Angle: >160° Input Voltage: 3.3V ~ 6V Compatible I/O Level: 3.3V, 5V Mini Size: 2.7 x 2.8cm Only Need 2 I/O Port Control Full Compatible with Arduino Working temperature: -30°C ~ 70°C Module volume: 32 x 35.5 x 4mm

• Module dimension: 85.0(W)x30.0(H)x9.7 max(D)
• Viewing Area: 58.22(W)mmx13.52(H)mm
• Dot Size: 0.57(W)mmx0.67(H)mm
• Dot Pitch: 0.60(W)mmx0.70(H)mm
• Display Format: 16 characters (W)x2 lines (H)
• Controller Interface: KS0066 or Equivalent 8-bit 68xx-Series MPU Parallel
• ROM Selection: English_Japanese Character Font Table
• Built-in: With DC/DC Converter
• OLED Type: OLED White & Black
• Rear Polarizer: Reflective / Positive
• Backlight Type: OLED
• Temperature Range: Wide Temp.,3.3V,Single Supply Voltage
•  :

oled display, mobile lcd display, a70 display lcd screen

OLED (Organic Light-Emitting Diode) is a self-light-emitting technology composed of a thin, multi-layered organic film placed between an anode and cathode. In contrast to LCD technology, OLED does not require a backlight. OLED possesses high application potential for virtually all types of displays and is regarded as the ultimate technology for the next generation of flat-panel displays.

Alphanumeric OLED Displays
