Oxygen Gas Plant Dealers

We follow strict quality strategy, guidelines and thus, to sustain good quality standards, we carry out stern examination of the raw inputs used at the initial stages. Over the years, we have become a primary choice of the buyers sine our product is qualitative and deliveries are time bound. Product Details: Simple to use Long lasting Exact designs Safe to use Safe shipment Reasonable costs

We offer Oxygen Analyzer. RELTEK Oxygen Gas Analyzer is a panel mountable instrument meant for measuring oxygen from the flue. It consists of two parts – Analyzer and Zirconia Oxygen probe. Analyzer The Analyzer is microcontroller-based and can be powered by Mains 230V AC. It senses the gas sample from the probe and measures Oxygen by means of Zircona sensors. . The outlet from the Zirconia Oxygen probe is fed into the analyzer through connecting cable. PRECISION ELECTRONICS offers INTERNATIONAL QUALITY PRODUCTS Oxygen Analyzer 38 - D GIDC BHAKTINAGAR RAJKOT 360 002 GUJARAT INDIA PRECISION ELECTRONICS RELTEK Phone: 91-281-2376820 MOBILE: 91-9586826585 E-mail: RELTEKINDIA@GMAIL.COM Web: http:sites.google.comsite reltekprecision The Analyzer has been designed with latest technology using LED Display and keys. Gases Measured Parameter Principle of Measurement Oxygen O2 Zirconia Sensor Measurement Parameter Parameter Range Resolution Working Temperature 0-45 c of Probe Temperature Resolution 1 Degree Celsius Sensors Zirconia Cell Accessories Instrument Manual Side mounting clamps TECHNICAL SPECIFICATIONS Oxygen O2 0 – 21.0% or 0-9999 ppm 0.1 %or 1 ppm Display LED 4-digit with Keypad Most Advanced Technology Power Mains 110- 230 V AC 50 Hz Key Board Key board for setting v arious parameters Calibration Manual by front panel pushbuttons, digital calibration Size: 192X96X300 (D) mm Temperature Range 0 to 600 Degree Celsius Sample Temp. RELTEK Offers Electrochemical type as well as Zirconia type Oxygen Sensors

They are used to connect to pressure transmitters. Manifolds eliminates several parts used in conventional piping and hence reduces cost. They are very compact in design and hence reduce lot of space requirement. They come in variety of types as shown below. Types of Manifold Valves based on number of valves - Two Valve Manifolds - Three Valve Manifolds - Five Valve Manifolds There are no available standard specification for double ferrule compression fittings. The following two standards which are applicable for Single compression fittings can also be used for double compression fittings. - BS 4368 Part IV : 1984 - IS 10103 :1982

Oxygen Analyser is used to detect the Oxygen level in any given gas, Oxygen Analyser available in PPM and Percentage type. Oxygen Analyser are of different ranges 0-30%, 0-100% & 0-5000 PPM, Oxygen Analyser has electrochemical type sensor. Oxygen Analyser has Digital display with 2 PPM or 0.01% resolution. Maximum operating pressure and temperature is 0.5bar and Ambient plus or minus 10 degree Celsius.

We offer a variety of payment methods to our customers so that they can pay as per their convenience while focusing on the core trade. We are New Delhi(India) based organization, affianced in making available the finest lot of products in the market.

We are offering air intake manifolds up to 6 cylinders engines, made in aluminum alloy for automobile sector. These parts can be produced in sand casting or gravity die casting.

  Suction Filter         High efficiency filter supplied with the compressor     Air Compressor:   This is a multistage heavy duty water cooled air compressor with fly wheel inter cooler, foundation bolts, motor pulley, v belt, guard and slide rails and air filter. This is used to compress atmospheric air complete with motor and Starter.     Process Skid (Skid Mounted Version): Consisting of the following   1.  After cooler with tank   2.  Nitrogen cooler with tank   3.  Moisture separator   4.  Chilling unit with freon unit   5.  Oil absorber filled with alumina   6.  Molecular sieve battery on skid   7.  Defrost heater   8.  Gas/Air/water line as per standard layout on skid/ /platform prefabricated and ready for  installation.   9.  Water pump.  10.  Inlet & outlet water lines  11.  Drain manifold complete with ball valves for draining moisture   copper pipes (inlet and outlet) hydraulically operated high efficient engine with ball type of valves stainless steel liner vertical type of German Design.     Expansion Engine with Motor: Complete with motor and starter with hydraulic valve control, bursting disc for safety, complete with flywheel pressure gauge, motor pulley v belt, belt guard, slide rails inter connected   MANUFACTURING PROCESS 1. COMPRESSION OF ATMOSPHERIC AIR BY AIR COMPRESSOR The free saturated air is sucked from atmosphere through a highly efficient dry-type suction filter into the first stage of the horizontal balanced opposed, lubricated reciprocating air compressor. Compresssed air is chilled to 12 degree centigrade in a chilling unit ata temperature of 12 degree centigrade to a moisture separator where the condensed moisture gets removed before entering into Molecular Sieve Battery. Before sending the air to MOLECULAR SIEVE BATTERY, air is passed through an OIL ABSORBER where air becomes oil free. 2. PURIFICATION OF AIR BY PROCESS SKID Chilled air passes through the Molecular Sieve Battery consisting of Twin Tower packed with Molecular Sieves to remove moisture and Carbon dioxide present in the air. Molecular Sieve Battery operates on Twin Tower System, when one tower is under production the other tower is regenerated by passing waste Nitrogen gas at 200 degC through a reactivation heater. After interval of 8 to 10 hours, the tower under production gets exhausted and regenerated by similar process before use and thus the cycle continues. Any dust particles gets filtered in the DUST FILTER before air enters the AIR SEPARATION COLUMN. 3. COOLING OF AIR BY EXPANSION ENGINE (EXPANDER) The process air before liquefication in the air separation unit needs to be cooled to temperatures sub-zero (cryogenic). The main portion of the air after the process skid enters the expansion engine through the heat exchanger no. I after pre-cooling. The temperature of the air drops to around -165degC by the Expander which is a very highly efficient advanced design with Teflon piston rings and completely hydraulic mechanism with leakproof ball valves.4. SEPARATION IF LIQUID AIR INTO OXYGEN AND NITROGEN BY AIR SEPARATION COLUMN Chilled, Oil free and moisture free air enters into multi-pass HEAT EXCHANGER NO.I where it gets cooled to (-80) degC by cold gained from outgoing waste Nitrogen and Oxygen. A part of air this enters a multi-pass HEAT EXCHANGER NO. II or LIQUIFIER made of special Alloy tubes. This air cools to (-170) degC before passing through an expansion valve. Due to joule Thompson Effect, after the expansion valve. Due to joule Thompson Effect, after the expansion valve, air gets further cooled down and gets liquified before entering into bottom column is known as rich liquid. The rich liquid in the bottom column enters into feed tray of top column enters into feed tray of top column. Similarly the liquid nitrogen called POOR LIQUID enters into top column as a reflux & it takes away the latest heat of condensing Oxygen and gets vapourised whereas the liquid Oxygen flows down the trays of the top column into the Condenser passes through a Sub-Cooler to a LO Pump. 5. COMPRESSION/WITHDRAWAL AND FILLING OF OXYGEN AND NITROGEN Liquid oxygen pump pumps Liquid Oxygen through heat exchanger no. II and I, where liquid Oxygen gets gasified before filling in Cylinders in the Filling Manifold. The pure bone dry Oxygen gas at ambient temperature and high pressure is filled into Oxygen Cylinders through manifold valves by means of the highly efficient reciprocating LO pump.

Our company in collaboration with 'Felice Mandressi' of Italy manufactures and exports technologically updated air separation plants that perform in sync with the plants of international standard. Made with the Italian technology, experience, resources, design and premium quality raw materials, our outputs fulfill the expectation of our clients. We bring the air separation machines that generate oxygen and nitrogen from air via the process of compression, cooling, liquefaction and distillation of air. Our products offer upto 99.7% pure oxygen and upto 99.99% pure nitrogen. We have an extensive lineup of plant capacities, ranging from 50 m/hour to over 5000 m/hour. The state-of-the-art production units are backbone of our organization, which manufacture plants and machinery. We also hold a well equipped R&D department that helps us forming significant design advances resulting in higher productivity and exceptional functioning. We also impart trainings on a frequent basis to enrich our personnel about all the latest technologies applicable in handling and operating the air separation plants. Features of air separation plants Start-up by single push button Quick Start-up time Skid mounted design Low power consumption Low maintenance cost Latest and sturdy design Fully automatic rotary air compressors (air cooled water free design) Apart from well equipped R&D units, skilled workforce and technologically advanced factory, we open a customer support department to solve day to day queries of our clients. Operation 24X7, the department listens you carefully before providing solutions, which meet your requirement. Either call or write to us, you will get immediate response. To get your technical queries solved within least possible time, consult the department now. If any question popping up in your mind, feel free to contact us now.   Scope of supply of air separation system: Our air separation plant comprises of the following equipments: 1. Air compressor We offer latest Rotary Air Compressor - ATLAS COPCO. It comes up with a number of advantages, including: Energy saving device High performance guaranteed 24x7 service support Fully automatic function Air cooled design 2. Air purification unit The air purification unit removes impurities available on the air, including dust, hydrocarbons. In addition, we also use 2 molecular sieve batteries to remove Carbon Di-Oxide via the process purification skid. 3. Air separation column (cold box) A grade air separation column is employed to generate highly pure oxygen and nitrogen to fill in cylinders directly at pressure of 150 to 200 Bar.

Hydro testing Filling pump: Hydrostatic testing has long been used to determine and verify pipeline integrity. Several types of information can be obtained through this verification process. to perform the process. To complete the process fluid is pumped in vessel or pipeline, these pump are used to filling this fluid.
