Power Factor Meter Dealers

MBPF-1 is Delta own development, signifying the ultimate in expertise that has been achieved in electrical parameters measurements. MBPF-1 is one of the most advanced instruments of its kind, employing the latest microprocessor technology. The circuitry is used. An absolute accuracy of 1.0 degree in phase angle measurements assures the computed power factor be accuracy of measurement is independent of line frequency variations.

• Size: 99 mm x 98 mm x 65 mm(depth)
• Brand: Unitech
• Model: PF
• Usage: Laboratory

Technical Details•Accuracy•Class: 1.0/Class 0.5 (Optional)Single Phase two wire•Supply: 170V – 260Vac, 50Hz•Display: One Line Seven Segment display, Size 0.56•Dimension: 95mm(H) x 95mm(W) x 84mm(D) Features DetailsTrue RMS Measurement.One Line 3 digits Display.Lag & Lead LED indication.Bright Seven segment LED display for better readability.

• Dimension: 96 * 96 * 86 mm
• Class Accuracy: +/- 0.01%

Available in Single Phase Two Wire & Three Phase Four Wire, LagLead indication on the display, Universal Auxiliary Supply – 80 to 300V ACDC, Bright 4 digit 14 mm LED display, Measurement Range : Zero Lag – Unity- Zero Lead.

LFL96 & LFL144 Power factor meters measure PF (cosine of the angle Ø between Voltage & Current vectors) with a better resolution. It is calibrated in values of cosØ in values of Ø. Housed in UL94V-0 approved polycarbonate case it can be mounted in Mosaic.

Power factor meter,Power Factor : Unity to 0.1 ( Lead Lag ) Input Voltage : 230V +20% to -60%, 50Hz. Input Current : 110% to 10% of rated current, 50Hz. Accuracy : ± 0.02 P.F ± 0.5 electrical Degrees Auxillary Power Supply : 230V ± 15%, 50Hz.

We are offering digital power factor meter. Meco-g has introduced a unique 4-in-1 meter for the first time. It has simultaneous measurements of volt, current, frequency and power factor (single phase and three phase balanced load). This reduces the cost of using 4 separated meters and saves space on the panel. Wiring of cables is also reduced thus effecting tremendous saving in cost.

We have hired a team of professionals who hold immense knowledge of packaging. They make use of premium packaging material so as to make damage free deliveries. We make sure the ranges of product we offer purchasers with are as per global quality management standards.

• Brand Name: Rish
• Country of Origin: 2 x rated value for 1 sec, repeated 10 times at 10 sec intervals
• Nominal Input Voltage (AC RMS): Phase-Neutral 57.7 - 277V L-N (Line-Line 100 - 480V L-L)
• Max Continuous Input Voltage: 120% of rated value
• AC Auxiliary Supply: 110V AC -15%/+20% / 230V AC -15%/+20% / 380V AC-15%/+20
• DC Auxiliary Supply: 12 to 48V DC ± 10%
• Current: 20 x rated value for 1 sec, repeated 5 times at 5 min intervals
• Response time to step input Resolution: min 1 sec approx. 0.001 (4 digit)

Measurement of power factor in AC system on L.T. Circuits having higher current load without interrupting circuit.

• Display Type: Pointer type
• Total Carbohydrate: 12 months
• Country of Origin: Made in India
• Model Name/Number: 96QF11
• Brand: MECO
• Usage/Application: Industrial
• Phase: Single
• Application Type: Panel Boards
• Material: ABS Plastic
• Range: 0.5 Lag to Unity to 0.5 Lead
• Accuracy: Class 2.5
• Coil Voltage: 250V , 415V
• Cut Out Size: 92 x 92 mm
• Over Load Current: 1A or 5A

Power Factor Meter (Panel Type)   Power factor of a circuit is the ratio between the effective power and the apparent power and is measured with the help of a power factor meter. This panel type pwer factor meter has iron free electrodynamometer coil movement. It is available in two sizes: 96x96mm and 144x144mm

• Brand Name: Elmeasure
• Country of Origin: Made in India
• Model Name/Number: LG+1119
• Usage/Application: Industrial
• Phase: 3 Phase ( 1Phase Selectable)
• Display Size: 96x96mm
• Usage: Industrial

We are a well known Manufacturer and Supplier of Digital Power Factor Meter from Haryana, India. Known for its reliable operation and robust design, our Digital Power Factor Meter is manufactured using high quality components and advanced machinery. To ensure customer satisfaction, we make sure to observe the quality norms and standards set by the regulatory bodies. Clients can rely on us for quick delivery of Digital Power Factor Meter within the postulated time. Features : High overload Two alarm output Robust steel base Low power consumption Direct connect operation Effective value measuring Multi function LCD Kwh Meter

The moving coil indicators and a phase angle adjuster are used to monitor changing power factor conditions on ir-reversible balanced load systems.The power factor is indirectly determined by measuring the phase angle φ between current and voltage (both sinusoidal). However the indicators are calibrated in values of cosine of the angle φ.

• Number Of Flower: Single phase/Three phase single element
• FEATURES: Absence of current is indicated by "Err",Negative sign indicates lagging P.F.
• OPERATIG VOLTAGE: 63.5V/110V/240V/440V., 2VA.
• OPERATING CURRENT: 1A/5A, 0.5VA.
• RANGE: 0.1 Lag - 1 - 0.1 Lead
• ACCURACY: ± 2°
• AUXILIARY SUPPLY: 110V / 240V ±10%, 50 / 60 Hz, 3VA.
• INSULATION RESISTANCE: Greater than 20 Mohms at 500V DC
• DIELECTRIC STRENGTH: 2kV RMS for 1 minute.
• OPERATING TEMP.: 0°C to 55° C.
• STORAGE TEMP.: -20°C to 70°C.
• HUMIDITY: Up to 95% RH.
• DISPLAY COLOUR: Red

Salient features available in single phase two wire & three phase four wire. universal auxiliary supply – 80 to 300v acdc. bright 4 digit 14 mm led display. laglead indication on the display. measurement range : zero lag – unity- zero lead. accuracy : +- 0.01%. resolution : 0.01 (for single phase p.f. Meter). 0.001 (for three phase p.f. Meter).

• Model: ALABS-A77-003
• Categories: Analog and Digital Meters
• Rated Accuracy: ± 1.0%
• Phase Wattmeter: ± 3° (Electrical)
• Position: Horizontal

• Rated Accuracy: ± 3° (Electrical) as per ISS 1248 for Power Factor Meters.
• CURRENT RANGE (Any One): 0.5/1A, 1/2A, 2.5/5A, 5/10A
• POTENTIAL RANGE (Any One): 62.5/125/250V, 125/250/500V, 150/300/600V
• CURRENT RANGE (Any One): 1A or 5A
• POTENTIAL RANGE (Any One): 110V or 440V
• CURRENT RANGE (Any One): 0.5/1A, 1/2A, 2.5/5A, 5/10A, 10/20A
• POTENTIAL RANGE (Any One): 62.5/125V, 110/440V, 125/250V, 250/500V, 300/600V

They can be used in Single phase, Three phase Three wire and Three phase Four wire system and are designed to be used in horizontal positions.

FEATURES   => State of Art Microcontroller Based Design.=> Built in Solid state selector switch for phase selection=> Super bright LED display for crystal clear long distance day light viewing=> Built in Transducer=> True RMS measurement

The Selec MP14 Digital Panel Meters - Digital Power Factor Meter which can Indicate power factor in operation of equipment, machinery, systems or processes in a wide range of industrial applications. It consists of 4 Digit, 7 segment LED display. Comprises of Input type: 1ø-2 wire with 0.001 resolution. Supply Voltage: 240V (50 Hz).   Features 4 digit, 7 segment LED 0.001 resolution

Models : DPF11, DPF31, DPF9611S, DPF9631S, DPF72x14411, DPF72x14431, DPF14411, DPF14431 Ordering Information Model, Input Voltage, Input Current, Input Frequency, CTR PTR (if any), Auxiliary Supply, Accuracy Class and Display Digit Height

We understand the importance of infrastructure in growth of a company.Uma Electronics is headquartered at Jaipur having capabilities in design, manufacturing, marketing and after sales support. Transformers testing, Pump testing & Motor testing Lab for our customers to get technical training on various aspects of testing.

Power Factor Meter Applications : Control Panel Motor Control Centers Distribution Panels Genset Panels Plant Monitoring Control System Power Factor Meter - MP14 (48mm x 96mm) Single phase power factor meter 0.001 resolution Power Factor Meter - MP214 (72mm x 72mm) Single phase power factor meter 0.001 resolution Power Factor Meter - MP314 (96mm x 96mm) Single phase power factor meter 0.001 resolution

• Frequency: 47 - 53 H Z
• Availability: 1.8 kg (approx)
• Core - Gap: 55 mm Maximum
• Dielectric Test Voltage: 2 KVAC ( r.m.s. ) for 1 min.
• Insulation Resistance Test: Over 25 ohm at 500v DC
• Scale length: 70 mm (approx)
• Dimensions (In mm): 330 x 99 x 98
• Response Time: Less than 1.8 kg (approx)
• Calibration: 50 H 1 AC Supply
• Confirms to IS: 1248 - 1983
• Accuracy: ± 3* (expressed as phase angle)
• Indicator: Analogue, Moving Coil Type Indicating Meter
• Accessories (Standard): (1) Potential Leads - 1 pair, (2) Operator"s Manual - 1No. (3) Carrying Case - 1N0. Accessory (optional), Neutral Box.
