Thermoplastic Road Marking Machine Dealers

Our thermoplastic road marking machine is designed for fast, efficient heating of thermoplastic material & application. Our road marking machine equipped with mercury temperature gauge meter to measure temperature of the paint and also gives flexibility to do marking of different widths.

we are one of the prominent manufacture and supply a high quality Thermoplastic Road Marking machine. Road Marking machine Superior Thermoplastic materials are essential for the development of a quality product. Our offered high quality precisely functioning machine are trusted for marking straight line, broken lines, curve lines etc. Our whole equipment of the road marking machine is manual applicators, semi-automatic or automatic. The machine separate Bimetal temperature gauges for heating temperature and paint temperature. We offer this product to our clients at nominal prices. Features Easy to operate High Pressure burner Optimal marking capacity of the machine With stand optimal pressure Minimal maintenance

Our company manufactures, supplies and exports high grade Thermoplastic Road Marking Machine. Thermoplastic Road Marking Machine is incorporated with the latest generation industrial automation controller. Our Thermoplastic Road Marking Machine can be availed at reasonable prices. We assure delivery of goods in stipulated time frame. We being a customer-centric firm also provide customized packaging facility to our esteemed customers. Features High Grade components usedTensile strengthReliable performanceAffordable Prices

We offer the most efficient Machines that are known for their operational efficiency. These machines are made of high-grade materials, under the supervision of experienced professionals. Our Machines are very sturdy, but, simple & have long lasting value for money. Operators with little orientation and training can understand and run these machines.   Specifications Applicator Tank: 200kg Stainless Steel Glass beads container: 12 kg Stainless Steel Glass beads system spraying: Rotor type (MS) Weight of total system: 130kg Heating system: LPG Dimensions of applicator: Width 16″(41cm), Length 36″(92cm)& Hight 36″(92cm) Glass dispensing box: 10cm and 15cm (MS) Laying Shoes: 10cm and15cm laying shoe as standard attachment (MS) Front wheel size:  25cm×5cm made of special Rubber Rear wheels size: 15cm×5cm made of special rubber with metal Operating system: Manual (Push behind).   Specification for Pre-heater  Capacity of Boiler: 250 kg Dimension of Boiler: 81×132×147 cms Oil system: Of HP company Engine horse power: Water cooled 8 HP diesel engine (Onkar) Number of Burners: 5 Make of gear box: Eicher, Mahindra or Mitsubishi Heating system: LPG layer Jacket: Made of four layers   Jacket number 1: Stainless steel of 3mm thickness   Jacket number 2: Stainless steel of 4mm thickness which is enclose with oil   Jacket number 3: Stainless steel of 2mm thickness enclose with air   Jacket number 4: Stainless steel of 2mm thickness enclosed with glass wool to maintain temperature Operating system: Manual Weight : 450kG

Thermoplastic Road Marking Machine for application of hot Thermoplastic making on roads, highways, airports and other surfaces, User friendly, Easy to operate and for application of precise an extraordinary strength and gives consistent performance and break free operation. Our machine is suitable for smal as well as big projects.   100 Kg. Capacity of Stainless Steel Tank and agitator with vertically mounted agitating arm. Front Mounted Pointer Guide adjustable according to laying shoe size. LPG Heating System: LPG Supply through heavy duty ring type burners for material tank and screed box. Hand Torch for safe lighting of burners. The Material tank shall have an outer jacket fitted with Dial Type Temperature Gauge 30o C - 400 o C to maintain the uniform Temperature of the material. Screed Shoe: Available in 10 cm and 15 cm width provided easy adjustment of thickness adjustment with rotating knob. Glass Beads Dispenser: Available in 10 cm and 15 cm width adjustable for minimum discharge of glass beads @300gms /m2. The dispenser shall be linked via chain drive from wheels of the machine so that quantity of dispensed glass beads is constant irrespective of speed of the machine and thereby assuring constant quality beads every time at any marking speed. Glass Beads Storage Box with window. Auto Lockable Rear Wheel capable of straight & fine alignment of markings track locked position or 360 degree swivel. Tool Box for tool kit & storage etc. 100 Kg. Capacity of Stainless Steel Tank and agitator with vertically mounted agitating arm. Front Mounted Pointer Guide adjustable according to laying shoe size. LPG Heating System: LPG Supply through heavy duty ring type burners for material tank and screed box. Hand Torch for safe lighting of burners. The Material tank shall have an outer jacket fitted with Dial Type Temperature Gauge 30o C - 400 o C to maintain the uniform Temperature of the material. Screed Shoe: Available in 10 cm and 15 cm width provided easy adjustment of thickness adjustment with rotating knob. Glass Beads Dispenser: Available in 10 cm and 15 cm width adjustable for minimum discharge of glass beads @300gms /m2. The dispenser shall be linked via chain drive from wheels of the machine so that quantity of dispensed glass beads is constant irrespective of speed of the machine and thereby assuring constant quality beads every time at any marking speed. Glass Beads Storage Box with window. Auto Lockable Rear Wheel capable of straight & fine alignment of markings track locked position or 360 degree swivel. Tool Box for tool kit & storage etc.

Utilizing state-of-the-art packaging tools and superior grade supplies, we pack our products and help them remain protected from external damages. Furthermore, the packages are labeled properly for information. We can be entrusted for delivering the orders within the promised time frame as we have sophisticated transportation facilities.

HOT THERMOPLASTIC OPERATOR PROPELLED ROAD MARKING MACHINE :- Model : KI-100 (MO) SS   Designed for fast, efficient heating of thermoplastic material & application (stainless steel tank 100kg. Capa.) Provides direct heating of thermoplastic material in applicator machine & provides easy means for swapping out application on the spot. Unique self wheel lock on rear wheel allows perfect straight line. Mercury Temperature gauge for Paint Screed box hook mechanism allows clean cut & sharp smooth strips, provided thickness adjustment provision on spot innovation makes for easier use & less parts to maintain. ( Auto Glass Bead Dispenser ) Positive dispensing of Glass Bead Spraying Mechanism automatically activates with the turn of machine with Glass bead flow adjustment providing theoperator less hassle. Heating: LPG supply to burner for tank, screed box 2 burners & hand torch. Safety traffic revolving light with rechargeable battery. The machine finish (Stainless Steel) provides longevity with less maintenance. Thus applies a complete line of thermoplastic materials, with minimum labour and fewer efforts. Technical Details Thermoplastic Tank Capacity : 100 kg. Capa Removable / Interchangeable Stainless Steel Tank & Body Glass Bead Container : 10 Kg Capa. Rotor Type positive dispensing of Bead Spraying Mechanism Size L X W X H : 1200 mm x 600 mm x 900 mm Weight : 115 Kg. Wheels Front / Rear : 3 Rubber Wheels 2x Dia 250/1 x Dia 150 Heating System : LPG Supply to burners Screed Box : For Marking Battery : 12 W Battery with Interchangeable System, Safety Traffic Lamp

HAND PROPELLED THERMOPLASTIC ROAD MARKING MACHINE : MODEL - T-5   T-5 :- Manual Thermoplastic Road Marking Machine (Screed Type) Manually operated machine having provision to lock the movement in straight line   Front mounted pointer guide adjustable according to laying shoe size. Heating System : LPG supply through heavy duty ring type burners for material tank and screed box. Hand torch provided for safe lighting of burners. 90 Ltr. Stainless steel tank to avoid corrosion. Agitator with vertically mounted agitating arm. The material tank is provided with a outer jacket fitted with dial type temperature gauge 30º C - 400º C to maintain the uniform temperature of the material. Screed shoe: Available in 10cm and 15cm widths. Glass Beads Dispenser : For 10cm and 15cm width. The unit is adjusted for minimum dischare of glass beads @ 300 gms/m2. Linked via chain drive from wheels of the machine hence quantity of dispensed glass beads is constant irrespective of speed of the machine, thereby assuring constant quantity bead every time at any marking speed. Glass beads storage box with window to keep a watch on quantity available in the box. Lockable Rear Castor : Straight track locked position or 360 degree swivel.

Thermoplastic Road Marking Machine, Road Kerbing Machin

Thermoplastic Road Marking Machine, Orange Polyfur Fabric Roller

GAJJAR thermoplastic road marking machine is designed for fast, efficient heating of thermoplastic material & application. Our Road Marking Machine equipped with mercury temperature gauge meter to measure temperature of the paint and also gives flexibility to do marking of different widths. The machine finish offers durability with less maintenance.
