Tube Straightener Dealers

In order to satisfy our clients in an efficient manner, we bring forward a wide range of SS Tube Straightening Machine. This offered machine is manufactured using quality assured stainless steel and other allied components. Our valuable clients can avail the offered range as per their preferred requirement. Besides, the offered machine is available with us in a number of specifications at reasonable rate.

Tubetech Straightening Machines for round tubes are multi cross roll type, based on well proven principle of rotation & deflection through hyperbolic profiled rolls mounted in pairs, hence delivering high degree of straightness up to 1 in 3000. A verity of optional features are offered to comply with customer’s requirement. Features: Fixed / Variable Speeds Built-in Dial Indicators for accurate settings Digitally displayed Pressure indicators for highly accurate settings Hydraulic lift of entry bottom roll for smooth tube entry Paraffin oil feeding & collection system for lubrication Automatic / Manual tube handling system

Tube straightening machine For straightening of tubes with medium straightness requirements, 6-roll straightening machines are used. Today, 10-roll straightening machines are used for the production of precision tubes.

Meraj multi- cross roll tube straightening machine allows the tube to be rounded straight during straightening. The machines provide all the advantage and meet the requirement of modern industries. We offer two types of straightening machine with 6 roll and 10 roll design respectively, each of which meets a particular requirement of straightness tolerance. The 6 roll tube straightening machine caters to straightening tolerance of 1mm in 1 mtr length and the 10 roll tube straightening machine caters to straightening tolerance upto 1mm in 5 mtr lengths depending on material specifications features machines comprise of six / ten work rolls arranged in pairsrolls are quickly and easily adjusted angularly to give a perfect contact between the tubes and roll over the maximum effective roll profilesetting of the machine for different sizes of tube is simpleall rolls are driven by two identical electric motorsmachines are fitted with indicators for vertical and angular setting of rollsaccuracylong-life straightening rolls specifications model no.capacity (od) range mmmax dia mmmax. Wall thicknessmin. Wall thicknessspeed mtr.mts-803/08/12920.540mts-1303/13/12152.50.538mts-2004/20/12202.50.535mts-3006/30/12323.2132mts-4008/01/40454.5130mts-6513-657561.528mts-10020-1001158.1225mts-12525-1251408.5225mts-15030-1501659.5318mts-20040-20021510416

We proffer metal tube straightening machine that is manufactured from superior quality raw materials ensuring our customers our trustworthiness. The tube straightening machine supplied is based on the rotary principal of straightening which is available for metal-tubes that are either ferrous or non-ferrous. This tube straightening machine is available in various specifications suiting to the demands of our customers. We provide easy accessibility and at the most pocket friendly prices and are consequently known as the top straightening machine manufacturer of India. Construction : The standard machine consists of six work rolls arranged in three pairs. All six rolls are driven by two identical electric motors through gear box. Rolls are quickly and easily adjusted angularly to give a line contact between turn roll over the masimum effective roll profile, precisely made on CNG Machine. ITL has also developed 10 roll design precision Tube Straightening Machines to achieve 1 to 3000 straightness accuracy. Unique Features : Fully stress relieved fabricated frame. Work rolls made from HCHCr steel hardened for longer roll life. Roll mounted in anti-friction spherical roller bearings. Entire roll adjustment mechanism independent of all other components. All gears manufactured from alloy steel and are hardened. All gears shafts are mounted in bearings. Universal propeller shaft driven. Easy to read dial type indicator. Simple initial machine setting. Specific design applications to suits your requirement.

K S ELECTROMECH offers SixTen driven Cross Roll Type Tube Straightening Machines based on well proven rotary pressure and deflection principal of straightening with hyperbolic profiled rolls mounted in pairs, which gives very high degree of straightness upto 1 in 3000.These machines are based on well proven rotary pressure and deflection principle of straightening, which gives very high degree of straightness ranging 1 mm. to 0.3 mm. in 1000 mm. The rolls are mounted in pairs and are driven.

We manufacture tube straightening machine using ms of supreme quality. The tube straightening machine offered by us is made up of ac motor, gear box system with manual operating for pressure.

We are a notable name in the domain offering the best in class and quality Tube Straightening Machine. With us, clients can stay assured for the quality of the products as we make use of the first class raw material that is tested on several measures prior to product manufacturing. Features : Accurate Tube Straightening without surface blemishes. Fixed/Variable Speed. Hydraulic lift in entry bottom roll for smooth entry of tube. No guides required to control tube passing. Built-in indicators for accurate roll setting. Easy and quick changeover from one tube size to another. Pressure sensing unit with digital display for thin wall Tubes. U-Type inlet and L-Type Outlet semi automatic tube handling system. Totally enclosed vanishing roller type automatic tube handling system.

FEATURES: - Machines comprise of six / ten work rolls arranged in pairs - Rolls quickly and easily adjustable angularly to give perfect contact between the tube and the roll, over the maximum effective roll profile - Simple setting of the machine for different sizes of tubes - All rolls driven by two identical electric motors  - Machines fitted with indicators for vertical and angular setting of rolls - Machines available in Single Speed and Variable Speed Options To obtain best results from the machine, correctly designed inlet and outlet through are essential because the tube rotates at high speed and must be controlled before and after straightening.     ROLLS: Made from Alloy Steel, Hardened, Hyperbolic Profile Ground and Lapped. Hyperbolic Profiles designed to accept wide range of tube diameters ROLL CARRIERS: Designed to give maximum Roll Stability even when fully extended MAIN DRIVE: Drive to the rolls by two totally enclosed gear boxes, each having three/five output shafts, connected by universal joints. Bottom rolls and Upper Rolls driven independently. Gears are single helical made from Alloy Steel, hardened & ground. Motors connected to the input shaft of the gear boxes by flexible coupling / ‘V’ belts ENTRY GUIDES: Entry guides made from Special Elastomer provided for the entire range GUARDS: Perspex transparent screen guard provided in front of the rolls. CONTROL PANEL: A control panel housing all electrical controls for running the machine provided.

Our straightening machine are of CROSS ROLL design and the principal of straightening is of rotary and deflection pressure.It’s of 6 roll design machine with high degree of accuracy level to 1:1000 to 1:3000mm. Our range of production is form outer dia 6mm to 114.3mm.

Cross Roll Type   GMT 6/10 DRIVE CROSS ROLL tube straightening Machines are designed to handle tube of Outer Dia from 6 mm to 170 mm in different models. These machines are based on well proven rotary pressure and deflection principle of straightening, which gives very high degree of straightening ranging from 1 mm to 0.3 mm in 1000 mm. The rolls are mounted in pairs  and are drive by two identical motors through totally enclosed gear boxes and box and universal spindel couplings.   Features   6/10 work rolls arranged in pairs. Two identical motors driving top and bottom rolls, fixed/variable speed. The Machine can easily and quickly be set when changing from one size of tube to another. Tube can be straightened accurately without surface blemishes. As the tube is retained between each pair of rolls no guides pairs of rolls no guides are required to control the pass of the tube. Machines can be supplied with manual, semi automatic and automatic handling system. Machines can be supplied with pressure sensing unit.

Tube Straightening Machine, End Facing Machines, Roll Forming Machin

Tube Straightening Machine, Tube Squeeze Pointing Machin

Tube Straightening Machine, Cut To Length Machine, Horizontal Accumulato

Tube Straightening Machine, BILLET CUTTING MACHINE, Pointing Machin

Our steel tube straightening machine is specialized in straightening carbon steel tubes, stainless steel tubes, alloy steel tubes in the tube production. Each steel tube straightening machine can be adjusted in rotation and screw up and down, it is driven by its power motor, and the tubes processed by it shall get excellent straightness. Steel tube straightening machine is accurately designed to give flawless service. attributes easy to operateexcellent straighteningprecisely designedflawless service
