Tyre Couplings Dealers

Design Features Highly flexible & resilient Absorbs Large Misalignment Low Torsional Stiffness Dampens shock & Vibration Flexible element easily replaceable No lubrication , Minimum Maintenance Custom Design for special requirements Type They are available in PH, PX, TC Series. Applications Ideally suitable for Diesel Engine Drives, Fans, Mills, Compressors, Rolling Mills, Pumps, Conveyors, DG Sets etc.

Taper lock bush fittings,Parallel misalignment up to 4 mm,Angular misalignment up to 4",Used in diesel engines and compressors in automobile industriesMaterial : rubber

The company is engaged as a Manufacturer, Supplier and Exporter of very efficient Tyre Couplings. We make Tyre Couplings available at the best prices in the market. Tyre Couplings provided by us are manufactured using the highest quality raw materials and the most developed technology. We make Tyre Couplings available in desired quantities through quick deliveries. Highlights Well-designedLow maintenanceHighly efficientReasonably priced

Size : More than 75 sizes for Power Transmission / Generation Material: Natural, Nitrile, Fibre Implegnated

We are offering Tyre Coupling to our customers. Features: •The couplings are highly elastic, backlash free, absorb shocks and dampen vibrations. • Inherent Overload Protection and high misalignment capacity. • Choice of tyres - standard, Neoprene or Fire Resistant Anti-static (FRAS) • Range of 17 sizes, with power rating from 0.22 Kw to 132 Kw at 100 rpm • Spacer tyre couplings for DBSE of 80 mm, 100 mm, 140 mm & 180 mm • Available as through bore or with taper lock bushes • Range of FTC Series Tyres and Steel cord tyres are also available

We are Manufacturers and Suppliers of high quality rubber Tyre Couplings. We are a Delhi based company that provides tailor-made Tyre Couplings to its customers. Our Tyre Couplings are known for their durability, hardness and flexible misalignment. You can buy these Tyre Couplings from us at market leading prices. Features : It provides parallel Misalignment up to 4 mm. It also offers Angular misalignment up to 4 Deg. It can withstand Temp up to 70 Deg.C Natural graded rubber. MRF ply used Standard size Proper flexibility Size (06 to 23).

Tyre couplings, Flexocon Pin bush type flexible Couplings are of the cushioned drive type, transmitting the torque, through high Tensile bolts to the machine input shafts. Special Rubber Compounds are used in bushes so that it can absorb slight misalignments, tensional vibration and shock loads. The flanges are made of high grade cast iron. For special applications cast steel flanges are also manufactured. Features No lubrication required. Accommodates misalignments. Damps out vibration. Reversing resiliency against shocks. Easy installation and removal. Inexpensive.

hi-class is one of the sterling names in diesel generator spares.hi-class leads on the platforms of teamwork, commitment for excellence and determination to provide the best of all products to our valuable clients.

Tyre Coupling from Shree Shakti Industries is highly flexible, proven and tested range of options in a methodically conventional design. Our standard size, full range covers continuing torque ratings. Presence of heating oil resistant properties ensures a wide range of applications across industries and makes them durable and long lasting. We have made it a point to manufacture lubrication free, elastic couplings to ensure the complete satisfaction of operators.

The Flexocon Tyre coupling is primarily designed to allow for misalignment both angular and parallel and compensates for end float. Torsional vibration is reduced and shock loads minimized by the flexing body. The Flexocon Tyre coupling has been successfully subjected, under normal circumstances, to angular misalignment up to 4째, parallel misalignment up to 3mm and end float up to 8mm. The design of the Flexocon Tyre coupling having a flexing member with remarkable durability suppresses the Initial shock load and eliminates to a marked degree the stresses common to power driven machinery.     Features   Highest Misalignment tolerance     Parallel : 3 mm.      Angular : Max 4 degree     End float : Max 8 mm.  Better protection in impact loads & heavy shocks.  Easy to assemble & dissemble.  No need for lubrication.

TYRE COUPLING tyre material is made from neoprene/ natural/synthetic rubber compounds reinforced with Rayon/ Nylon/ Polyester Cord to give superior rating & durability

First introduced in the country in late 6qs-now available in a vast range of sizes for nominal torque ratings upto 145000 nm, also available in flange mounting design for direct attachment to flywheels of all well known makes in models of diesel engines and in spacer design.   Key Features   Highly Flexible and resilient Absorbs large Misalignment Low torsional stiffness Dampens shock & Vibration Flexible element easily replaceable in site Ideally suitable for Diesel Engine Drives , Fans , Mills , Compressors ,Rolling Mills Pumps, conveyors , DG Sets. Available for reputed makes of Diesel Engines and compressors. Custom Design for special Requirements Torsional Vibration Calculation on request No Lubrication . Minimum Maintenance No expensive downtime. Flexible element is made of Rubber reinforced with Nylon Chords. Available in Series PH, PX, TC & U PH Series has largest range. These have flexible member firmly bolted to clamping elements. There is no possibility of Tyre slipping out even in case of imperfect installation. Available for Maximum torques upto 420000 Nm Coupling Diameter upto 1250 mm. Couplings with Brake Drum available. Also available with magic Grip Bushing for Quick fitment & removal.

We are offering flexible tyre couplings . We are instrumental in offering high quality flexible tyre couplings. our flexible tyre couplings are resistant to abrasion and corrosion due to the incorporation of the best quality raw materials in the production process. Our flexible tyre couplings offer great performance at a low cost. These flexible tyre couplings can also be customized as per the clients’ specifications. available in different : sizesdesigns why our flexible tyre couplings? abrasion resistantcorrosion freeperfect makehigh performancedurability

Following are some of the characteristics of Tyre Coupling:   Power is transmitted by a Rubber with superior elasticity Possible transmit the power fully under misalignment. Be smoothly Transmitted the Power Low noise and High durability Characteristics & Merit of Type Coupling PARALLEL The movement of the grid in the lubricated grooves in Tyre Coupling accommodates parallel misalignment and steel permits full functioning of the grid-groove action in damping out shock and vibration.   ANGULAR Under angular misalignment, the grid groove design permits a rocking and sliding action of the lubricated grid and hubs without any loss of power through the resilient grid.   AXIAL End Float for both driving and driven members is permitted because the grid slides freely in the lubricated grooves.  TORSIONAL FLEXIBILITY Torsional flexibility is the advantage of WCC Taper Grid Coupling, providing flexible accommodation to changing load conditions.

We are offering brake drum tyre coupling, brake drum tyre coupling, brake drum tyre coupling, brake drum tyre coupling, brake drum tyre coupling, brake drum tyre coupling, etc.

  tyre couplings     tyre couplings   we have installed various latest machinery and tools to manufacture tyre coupling. Precision-engineered, these products are developed at our sophisticated infrastructure unit with the aid of advance machinery and technology by employing high-grade raw material. The raw material used in manufacturing these products are obtained from accredited vendors, who are well known names of the industry.   listed below are the features :    dimensional accuracy    high performance    longer working life

Inherent Overload Protection and high misalignment capacity. Choice of tyres - standard, Neoprene or Fire Resistant Anti-static (FRAS) Range of 17 sizes, with power rating from 0.22 Kw to 132 Kw at 100 rpm Spacer tyre couplings for DBSE of 80 mm, 100 mm, 140 mm & 180 mm Available as through bore or with taper lock bushes
