Working PrincipleFluid Flow Raises The Float In A Tapered Tube, Varying With Flow Rate.
Measurement UnitsLPM (Liters Per Minute)
we are acknowledged as one of reputed rotameter suppliers in the national market. A variable area flow meter that is rotameter is highly efficient and offers consistent performance. It is appreciated by the clients for its high performance.
working principle
the fluid flow increases the float to pass through the tapered tube. Greater the flow, the higher the float is raised. In liquid service, the float increases due to an amalgamation of the buoyancy of the liquid and the speed head of the fluid. With gases, buoyancy is slight, and the float reacts mostly to the speed head.
specifications
flow rates of waterliquid : 30 lh up to 150,000 lh. (special ranges on request)flow rates of air : 0.1 nm³ h up to 450 nm³ h. (special ranges on request)connection size : 12" ~ 6"mounting length : 250 mm, standard 350 mm, explosion prooftemperature : 200°c(300°c option)
applications
chemical industrieslaboratory purpose
