MaterialGalvanized Iron, Aluminium and Copper Conductor
Number Of FlowerManual
ApplicationUsed for Travelling of Overhead Crane
Brand NameMultitech Systems
Usage/ApplicationUsed in Long and Cross Travel for Travelling of EOT ( Electrically Operated Overhead Crane)
CurrentGI Conductor (100 Amps and 125 Amps), Copper Conductor ( 160 Amp, 250 Amp and 400 Amp) Aluminium Con
No. of Conductors4
Conductor TypeGi , Aluminium , Copper and SS
Insulation MaterialPVC
MOUNTING
Insulated hanger clamps supportconductor, standard mounting brackets available or designed for specific requirement
The Conductor can be mounted horizontally or vertically
No minimun clearance required with other structures
FEED TERMINALS
The power feed point can be at the ends or anywhere along the run. One or more power feed point positions possible to reduce voltage drop
END CAPS
The open ends / end feeds of conductors are covered by end caps
COLLECTOR
A fully articulated sliding type collector assembled from strong, purpose designed, glass filled nylon moulding. This design produces compact unit fully insulated from the support bracket.
S S Spring ensures adequate contact pressure
Additional Information
Item Code: MTS1
Production Capacity: upto 1500 Mtr Per day
Delivery Time: Within 1 Week
Packaging Details: Wooden Box
