Japan Automatic Machine Co., Ltd. Sector 12, Faridabad, Haryana

Light curtain ●It neither bothers an operator nor lower operating efficiency. ●Since it adopts luminous diode, pulse adjustment system, pulse cycle adjustment system, it is not effected by outer light.

HYP 2000P Can be used in wide working application by adjusting the pressing pessure . Mechincal stopper is equiped in as standard and stable button point accuracy is maintained which ever done before by sensor control Both hands operation switch standard equipment Press-stand : option equipment

HYP-EP ●This is the eco-hotpress with the development certificate obtained, based on ‘MF Eco machine authorization standard’ . In comparison with HYPE505H/1000 it is the press with the environment kept in mind,at least 15% curtailment of oil energy consumption and 3dB or more reduction in noise release ●Both-hands operation switch : Standard equipment ●Press stand : Option equipment The eco-certification is given only the main body of press

49kN CRANK SERVO PRESS - SGP 505N ●This post type frame structure is excellent in the rigidity and exercises to highly accurate processing. Wide bolster area is enough to correspond to a large-scale of mold and owns the high flexibility to adapt to various peripheral devices, like a feeder. And also it is able to use partially of the automation line. ● RAM (Slide) can be synchronized with the peripherals by an arbitrary out- put signal. ● Press Capacity : 49 kN ● Activating Point : 1.2mm ● Stroke Length : MAX. 40mm ● No. of Stroke : MAX. 130 S.P.M ● Open Height : 300mm ● Die Height : 260mm ● Shank Hole : Dia25 X 50L ● Max. Upper Die Mass : 20Kgs ● Adjustment : 25mm ● Power Supply : Three Phase 200VAC,50A, 50/60Hz

98kN CRANK SERVO PRESS - SGP 1000N ●This post type frame structure is excellent in the rigidity and exercises to highly accurate processing. Wide bolster area is enough to correspond to a large-scale of mold and owns the high flexibility to adapt to various peripheral devices, like a feeder. And also it is able to use partially of the automation line.   ●RAM (Slide) can be synchronized with the peripherals by an arbitrary out- put signal. ● Press Capacity : 98 kN ● Activating Point : 1.3mm ● Stroke Length : MAX. 40mm ● No. of Stroke : MAX. 100 S.P.M ● Open Height : 300mm ● Die Height : 260mm ● Shank Hole : Dia32 X 60L ● Max. Upper Die Mass : 35Kgs ● Adjustment : 25mm ● Power supply : A.C 200VAC,50A, 50/60Hz
