Automatic Die Machine Dealers in Gurugram (2 products available)

• Country of Origin: India
• Certification: CE Certified, ISO 9001:2008
• Weight: 1000-2000kg, 500-1000kg
• Color: Light White
• Voltage: 220V
• Automatic Grade: Automatic
• Power: 1-3kw, 9-12kw, 7-9kw
• Driven Type: Electric, Hydraulic, Penaumatic
• Brand Name: Lakshya

Insole automatic die cutting machine Range of Application This travel head cutting machine is mainly suitable for die cutting single or multiple layers of nonmetal rolled materials by die cutter. It is widly used in many industries, such as: Automotive interior Abrasives, abrasive paper L eather...     Range of Application  This travel head cutting machine is mainly suitable for die cutting single or multiple layers of nonmetal rolled materials by die cutter. It is widly used in many industries, such as: Automotive interior Abrasives, abrasive paper Leather and leathergoods – shoe uppers, wallets, purses, belts Clothing – components for hats, ties, collars, shoulder pads Cork gaskets and mats Foam and sponge  Footwear components – shoes, insoles, insole socks, uppers, straps Rubber – gaskets, seals, washers Textiles – sample swatches and pattern books, underwear and outerwear components, hats, ties Toys – soft toys, advertising novelties, mini jig-saw puzzles, etc.  Features of Insole Automatic Cutting Machine 1.Thesedie cutting machines are suitable for continuous cutting operation of nonmetal materials. The finished materials are widely used for such products as abrasive, abrasive paper, shoes, sports materials, car interior materials and medical supplies. 2. Servo motor makes accurate feeding possible and controls horizontal movement and rotation of the cutting head. Multilayers of materials can be clamped by the cylinder for stepping feeding. Other feeding methods are also available on request. 3. The distance of cutting head and feeding length can be accurately set, which has solved the problem of inaccurate feeding and layering length of multilayer materials. 4. The die cutting press has various working modes such as inching, manual and automatic etc. The workers need only to pick up the products, with labor intensity reduced and work efficiency enhanced. 5. Special hydraulic system makes low noise possible and saves oil.  High quality and imported oil pump and other parts are available on request. 6. As the machine is controlled by.PLC with high automation degree, only one worker is required for the whole machine,so that the production efficiency can be enhanced for 3-5 times and the power can be almost 1/3 saved. 7. Cutting board micro-movement device is adopted to prolong the service life of the cutting board. 8. Products of special specifications can be customized.   Reference Technical Data (Customizable) Model                                                                                   KT-C  Maximum Cutting Force (ton) 25 25 25 50 50 50 Working Table (mm) 1800*500 2000*500 2200*500 1800*550 2000*550 2200*550 Travel Head Size (mm) 500*500 500*500 500*500 550*550 550*550 550*550 Adjustable Stroke (mm) 5-150 5-150 5-150 5-150 5-150 5-150 Motor Power (kw) 2.2 2.2 2.2 4.0 4.0 4.0 Estimated Machine Dimension (mm) 2200*620*2000 2400*620*2000 2600*620*2000 2200*620*2000 2400*620*2000 2600*620*2000 Estimated G.W (kg) 2300 2800 3500 3500 4200 5000   Option  Rotary head Machine Color Servo Motor Imported oil pump Roll Holding Gantries Bed Size
