Okuma India Pvt. Ltd. Sushant Lok, Gurugram, Haryana

  the v760ex provides a large work envelope with max cutting diameter of ø760 mm and height of 770 mm while maintaining a small footprint. This is large enough even for odd-shaped components (max swing: ø800 mm possible) to accommodate a wide range of applications stable machining achieved even with difficult-to-chuck thin, large-diameter workpieces and unbalanced, odd-shaped components.

A wheelhead traverse structure requires astronger foundation than a table traversestructure. Okuma’s high-rigidity technologymeets the conditions needed for a wheelheadtraverse structure to achieve a compact body. The upper portion of the front door canaccommodate various loader positions. Lineflexibility from the space-saving design alsocontributes to greater automation. An oil pan structure to minimize effects on thecoolant, high following characteristics carefullyfitted with a V-plane slideway, and otherindividual technologies on each part of themachine further improve machining accuracy. “Chatter control function” automaticallychanges wheel speed and controlsregenerative chatter. Stable machiningaccuracies can be maintained at all times.

The ultimate process-intensive machine for process completion from materials to product on one machine

With the ideal, large work envelope for lots of milling of complex parts. The class best Y-axis travel is fully utilized with a highly rigid traveling column, for powerful cutting along the entire Y axis. Turn-Cut is an original Okuma technology that enables turning on a milling spindle. The circular turning of the feed shaft and the spindle indexing angle are simultaneously controlled so that the tool edge is always facing the center of the milling spindle circular turning. Sloped axis turning can be done by sloping the B axis. Moreover, machining of any diameter can be done with a single tool. Inside and outside diameter machining that is larger than the maximum tool diameter can be done. In setting cutting conditions, the Turn-Cut Guide (Optional) advises the best turning speed when the diameter and roundness of the machining area are designated.

Okuma is a leading and the oldest Japanese company in machine tool manufacturing with an impressive line up of accurate and rigid CNC Lathes, Multitasking Machines, Machining Centers and High Precision Grinding Machines with OKUMA control (OSP CNC). Since 1898 Okuma technology has provided customers with the right tactics to innovate.

Highly rigid trunnion table supports high-accuracy 5-axis machining The indexing accuracies that take 5-axis machining to higher accuraciesIndexing accuracy ▪ A-axis indexing accuracy/Indexing return accuracy: ±0.68 sec/±0.40 sec▪ C-axis indexing accuracy/Indexing return accuracy: ±0.78 sec/±0.14 sec Fast operatio (Actual data) ▪ A-axis/C-axis 90°clamp/unclamp indexing time: 1.0 sec/1.2 sec High quality machined surfaces with the high following of 5-axis machiningHighly-rigid trunnion table supports both endsWith ball-screw cooling (Std), reduced following error is achieved while maintaining highly accurate machining. Trunnion table High accuracy maintained over long times in 5-axis machining The synergistic effect between two intelligent technologies—5-Axis Auto Tuning System and the Thermo-Friendly Concept—maintains high-accuracy 5-axis machining over the long term.

The MU-4000V has a very rigid roller gear cam suited to high-speed drive on the trunnion table B-axis, and a direct drive motor that produces high torque even at low speeds on the C-axis. This makes it possible to achieve both high-speed and high-accuracy machining. B axis:50 min-1C axis:120 min-1 (Standard)1,200 min-1 (Optional)[turning mode] B-axis indexing accuracy/repeatability:±1.78 sec/±0.50 sec C-axis indexing accuracy/repeatability:±2.26 sec/±0.12 sec
